Table 1. Features available on the front of the system (continued)
Item
3
4
5
6
Figure 3. Front view of 4 x 3.5-inch drive system
Table 2. Features available on the front of the system
Item
1
10
Dell EMC PowerEdge R640 overview
Ports, panels, and slots
USB port (optional)
VGA port
Right control panel
Drive slots
Ports, panels, and slots
Left control panel
Icon
N/A
N/A
Icon
N/A
Description
NOTE:
DVD devices are
data only.
The USB port is USB 3.0
compliant.
Enables you to connect
a display device to the
system. For more information,
see the
www.dell.com/
poweredgemanuals
section.
Contains the power button,
USB port, iDRAC Direct micro
port, and the iDRAC Direct
status LED.
Enable you to install
drives that are supported
on your system. For
more information about
drives, see the
www.dell.com/
poweredgemanuals
section.
Description
Contains the system health
and system ID, status LED,
and the iDRAC Quick Sync 2
(wireless) indicator.
NOTE:
The iDRAC Quick
Sync 2 indicator is
available only on certain
configurations.
● Status LED: Enables you
to identify any failed
hardware components.
There are up to five
status LEDs and an
overall system health
LED (Chassis health and
system ID) bar. For
more information, see
the
Status LED indicators
section.
● Quick Sync 2 (wireless):
Indicates a Quick Sync
