10 Commissioning using u-OS | Requirements

10 Commissioning using u-OS

Explosion risk!
▶ Before starting any work, make sure that
there is not a potentially explosive atmos-
phere!
Manipulation of the control unit!
During commissioning, the system may be
manipulated to such an extent that can result
in risks to life and material damage.
▶ Make sure that system components can-
not start up unintentionally!
The product can be destroyed!
▶ Before commissioning each time, perform an insulation
test of the station (see section 6.6).
▶ Observe the built-in online help in u-OS.

10.1 Requirements

The controllers can be commissioned using u-OS.
Before you start the commissioning work, the following re-
quirements must be fulfilled:
– The u-control station must be completely assembled and
wired up.
– PC or laptop and u-control station are connected via USB
or Ethernet.
– The power supply must be turned on.
If these requirements are fulfilled, the following LEDs light
up:
– on the controller
– The PWR LED lights up green.
– The upper LED at the connected interface lights up
green for connection to the network.
– On the modules, the Status LED lights up green.
62
WARNING
WARNING!
ATTENTION
Web browser
u-OS can be used with the following web browsers.
– Mozilla Firefox 102 or higher
– Google Chrome 114 or higher
– Microsoft Edge 115 or higher
Screen resolution
For u-OS we recommend a screen resolution of 1280 x 800
or higher. The user interface is displayed optimally when the
browser window is maximised.

10.2 Starting u-OS

You can access u-OS via the USB interface or Ethernet.
▶ For USB access, connect the PC to the controller using a
USB cable. The USB connection socket is located under
the service flap on the front.
The USB cable should be a maximum of 2 m long
(type USB-A to USB-C, for example Weidmüller
Order No. 2838380020). Extension cables must
not be used!
▶ For Ethernet access, connect the PC to the controller
using a LAN cable or a network switch.
▶ Open one of the browsers listed in section 8.1.
▶ In the address line, enter the IP address of the controller.
– USB access X3: 192.168.10.202
– Ethernet access X1: 192.168.0.101
The browser warns you of an insecure connection when
u-OS is launched for the first time.
▶ Click Advanced and continue the insecure connection.
u-OS is started.
The licence terms are displayed when u-OS is launched for
the first time.
▶ Read the licence terms carefully.
▶ Confirm that you agree to the licence terms
▶ Click on Accept license agreement, to proceed to the
login page.
The dialogue Create the initial Admin User is opened.
Manual u-control 2604080000/08/08.2023
