Technical data UC20-WL2000-AC (Order No. 1334950000)
General data
Type of connection
Configuration interface
Degree of protection (IEC 60529)
Flammability rating UL 94
System data
Connection
Number of modules
Processor
Memory
Retain memory
Memory card (not included)
Battery (not included)
Supply
Supply voltage for system and inputs
Supply voltage for outputs
Max. feed-in current for input modules
Max. feed-in current for output modules
Current consumption from system current path I
Mechanical data
Dimensions
Weight (operational status)
Environmental conditions
Temperature data
Humidity
Air pressure
2604080000/08/08.2023
"PUSH IN"
Micro USB 2.0
IP20
V-0
2 x RJ-45
max. 64 active
Dual Core ARM A9, 624 MHz
512 MB RAM, 8 GB flash
128 KB NV-RAM
microSD (max. 32 GB, NTFS not supported)
Lithium button cell CR1220
24 V DC +20%/-15%
24 V DC +20%/-15%
5 A
5 A
< 116 mA
SYS
Height x Width x Depth
223 g
Operation (horizontal installation) at
24 V DC +20%/-15%
Operation (vertical installation) at
24 V DC +20%/-15%
Storage, transport
Operations
Storage, transport
Operations
Storage, transport
Manual u-control
5 Detail description of controllers | UC20-WL2000-AC
solid, fine-wired
Wire cross-section 0.14 ... 1.5 mm
120.0 mm / 4.72" (with release lever: 128.0 mm /
5.04") x 52.0 mm / 2.05" x 76.0 mm / 2.99"
-20°C to +55°C (2×5 A power supply)
-20°C to +50°C (2×5 A power supply)
-40°C to +85°C
95%, non-condensing according to IEC 61131-2
95%, non-condensing according to IEC 61131-2
≥ 795 hPa (altitude ≤ 2000 m) according to IEC
61131-2
≥ 700 hPa (altitude ≤ 3000 m) according to IEC
61131-2
(AWG 16 – 26)
