Inserting The Battery - Weidmüller u-control UC20-WL2000-AC-CAN Manual

6.4

Inserting the battery

Explosion risk!
▶ Do not use the controller with a battery in
a potentially explosive atmosphere.
Battery may explode if mistreated!
Use of a wrong battery type may cause
fire or explosion!
▶ Do not recharge, disassemble or dispose
of in fire.
▶ Use only batteries of the specified type
(see technical data).
▶ Unlock the connector frame and open it as far as possible
(at least to an angle of 90°).
Opening the connector frame
▶ Insert the battery with the positive terminal to the left.
2604080000/08/08.2023
WARNUNG
WARNING
+
Inserting the battery
▶ Close the connector frame.
Manual u-control
6 Installation | Inserting the battery
43
