  • Page 1 Controllers u-control Manual (Original) Letʼs connect. UC20-SL2000-EC-CAN 2674620000 UC20-WL2000-AC 1334950000 UC20-WL2000-IOT 1334990000 UC20-SL2000-EC 2674520000...

  • Page 2: Table Of Contents

    Feedback energy in DO modules Accessories and replacement parts Detail description of controllers 13.1 Accessories UC20-WL2000-AC 13.2 Replacement parts UC20-WL2000-IOT ANNEX UC20-SL2000-EC UC20-SL2000-EC-CAN Installation Preparations for assembly Assembling the u-control station Wiring Inserting the battery Inserting the SD card Insulation test Manufacturer Weidmüller Interface GmbH &...

  • Page 3: About This Documentation

    1 About this documentation | Symbols and notes About this documentation Symbols and notes The situation-dependent safety notices may contain the fol- lowing warning symbols: The safety notices in this documentation are designed Symbol Meaning according to the severity of the danger. Warning against hazardous electrical DANGER voltage Imminent risk to life!

  • Page 4: Hardware Versions Described

    Hardware versions described The present manual describes the following hardware ver- sions of the controllers: Order No. Controller Hardware version 1334950000 UC20-WL2000-AC 01.22.00 1334990000 UC20-WL2000-IOT 01.22.00 2674520000 UC20-SL2000-EC 01.22.00 2674620000 UC20-SL2000-EC-CAN 01.22.00 Manual u-control 2604080000/03/08.2020...

  • Page 5: Safety

    2 Safety | General safety notice Safety This section includes general safety instructions for handling cal operations rooms. Only trained and authorised personnel the u-control system. Specific warning notices for specific may access the equipment. tasks and situations are given at the appropriate places in For applications requiring functional safety, the surrounding the documentation.

  • Page 6: Intended Use

    2 Safety | Intended use Intended use – If the temperature under rated conditions exceeds 70 °C at the cable or conduit entry point, or 80 °C at the branching point of the conductors, the temperature speci- The products of the UC20 series are intended for use in in- fication of the selected cable shall be in compliance with dustrial automation.

  • Page 7: Legal Notice

    2 Safety | Legal notice Legal notice The u-control series products are CE-compliant in accor- dance with Directive 2014/30/EU (EMC Directive) and Directive 2014/35/EU (Low Voltage Directive). They also meet the requirements of the ATEX Directive 2014/34/EU unless otherwise noted. The results of the measurements according to CISPR 16-2-3 should also be suitable to demonstrate the compliance of the u-control devices to the limits for radiated emissions as defined by CFR 47 Part 15, Subpart B, §15.109, Class A...
  • Page 8 Manual u-control 2604080000/03/08.2020...

  • Page 9: System Overview

    3 System overview System overview Example arrangement of a u-control station The products of the u-control series are programmable logic controllers. The UC20-WL2000 controllers are configured, parameterised and programmed using the integrated en- Height (H) Width (W) Depth (D) gineering tool u-create web via a web browser. The UC20- SL2000 controllers are configured, parameterised and programmed using the separate engineering tool u-create Controller...
  • Page 10 3 System overview Power supply concept The u-control controllers and the u-remote modules use three internal current paths as described in following chapter 4. In- put and output paths are supplied seperately, therefore a cus- tom-fit refreshing by power-feed modules is easyly feasible. The figure shows the general supply concept.

  • Page 11: General Description Of The Controller

    Release lever for the DIN rail fixing Connector frame unlocking device Data line connection (RJ45) LED power supply controller CAN interface (only UC20-SL2000-EC-CAN) Controller status LEDs Seats for module markers 10 Power supply connector for the system and input modules...

  • Page 12: General Technical Data

    3 System overview | General technical data General technical data Type of connection "PUSH IN" solid, fine-wired Wire cross-section 0.14 ... 1.5 mm (AWG 16 – 26) Configuration interface USB 2.0 Dimensions Height 120.0 mm / 4.72" (with release lever: 128.0 mm / 5.04") Width 52.0 mm / 2.05"...

  • Page 13: Connectable U-Remote I/O Modules

    3 System overview | Connectable u-remote I/O modules Connectable u-remote I/O modules Mechanical fixing elements The release notes concerning the controllers The station is fixed in the installation position by an end describe which u-remote modules at which firm- bracket at either side. The last I/O module is protected ware version are supported.

  • Page 14: Type Plate

    3 System overview | Type plate Type plate Battery Each controller features a type plate, which includes iden- The controller can be equipped with a battery (for specifica- tification information and the key technical specifications. tion see technical data). The battery continues to supply the In addition, a QR code allows for direct online access to the integrated real-time clock if the power supply is interrupted.

  • Page 15: Configuration

    4 Configuration | Order and arrangement of the modules Configuration Order and arrangement of the modules Orientation of the station The u-control station is designed to be installed on a DIN rail The u-control station is usually installed on a horizontally (35 × 7.5 mm or 35 x 15 mm) made from steel or galvanised positioned DIN rail.

  • Page 16: Installation Distances

    4 Configuration | Installation distances Installation distances In order to be able to carry out the installation and subse- quent maintenance work and to ensure sufficient ventilation, the u-control station must be installed while observing the following minimum distances (see the following figures). ATTENTION Depending on how the station shielding is implemented, 30 mm...

  • Page 17: Use In A Potentially Explosive Atmosphere

    4 Configuration | Use in a potentially explosive atmosphere Calculation of power loss for the use in a potentially explo- Use in a potentially explosive atmosphere sive atmosphere Please regard the safety notes in section 2.3. You will find the module specific data needed for calculation in the document "WI13ATEX0002_Power_Calc.pdf"...

  • Page 18: Current Demand And Power Supply

    UC20-SL2000-EC < 116 mA – to the right. UC20-SL2000-EC-CAN < 116 mA – The design of the power supply being used must take start-up peaks into account. The current demand of the u-remote I/O-modules can be found in the Remote-I/O-System u-remote Manual.

  • Page 19: Example Calculation For The Power Supply

    4 Configuration | Example calculation for the power supply Example calculation for the power supply Calculation of current demand for the output current The current consumption of each module and the current The power supply must be calculated individually for each demand of the connected actuators must be considered for station installation.
  • Page 20 4 Configuration | Example calculation for the power supply Example calculation for the current demand (all current values in A) Module Product Simultaneity Cumulative Cumulative Cumulative cur- factor current demand current demand rent demand of of the input cur- of the controller the PF-O output rent path output power...

  • Page 21: Calculation Of Power Loss

    4 Configuration | Calculation of power loss Calculation of power loss Feedback energy in DO modules The power loss of the controller is calculated as follows: With digital output modules, power is fed back through the channels when inductive loads are switched off. The respec- + N ...
  • Page 22 Manual u-control 2604080000/03/08.2020...

  • Page 23: Detail Description Of Controllers

    5 Detail description of controllers | UC20-WL2000-AC Detail description of controllers UC20-WL2000-AC Status indicators Up to 64 active u-remote modules can be connected via the u-remote system bus to the UC20-WL2000-AC controller. The controller has two Ethernet connections for integration into the existing network architecture or HMI connections. The integrated engineering tool u-create web can be launched via the USB service interface or over Ethernet.
  • Page 24 5 Detail description of controllers | UC20-WL2000-AC Controller power supply LED Green: supply voltage > 18 V Red: at least one current path < 18 V TD+ 1 TD– 2 RD+ 3 RD– 6 RUN/STOP TD+ 1 L/A X1 TD– 2 L/A X2 RD+ 3 24 V DC IN RD–...
  • Page 25 5 Detail description of controllers | UC20-WL2000-AC Internal from the control card System System System µC card Battery RJ45 24 V/5 A Output RJ45 UC20-WL2000-AC Block diagram UC20-WL2000-AC 2604080000/03/08.2020 Manual u-control...
  • Page 26 5 Detail description of controllers | UC20-WL2000-AC Technical data UC20-WL2000-AC (Order No. 1334950000) System data Connection 2 x RJ-45 Number of modules max. 64 active Configuration interface Micro USB 2.0 Processor Dual Core ARM A9, 624 MHz Memory 512 MB RAM, 4 GB flash Retain memory 128 KB NV-RAM Memory card (not included) microSD (max.

  • Page 27: Uc20-Wl2000-Iot

    5 Detail description of controllers | UC20-WL2000-IOT UC20-WL2000-IOT Status indicators Up to 64 active u-remote modules can be connected via the u-remote system bus to the UC20-WL2000-IOT controller. The controller has two Ethernet connections for integration into the existing network architecture or HMI connections. The integrated engineering tool u-create web can be launched via the USB service interface or over Ethernet.
  • Page 28 5 Detail description of controllers | UC20-WL2000-IOT Controller power supply LED Green: supply voltage > 18 V Red: at least one current path < 18 V TD+ 1 TD– 2 RD+ 3 RD– 6 RUN/STOP TD+ 1 L/A X1 TD– 2 L/A X2 RD+ 3 24 V DC IN RD–...
  • Page 29 5 Detail description of controllers | UC20-WL2000-IOT Internal from the control card System System System µC card Battery RJ45 24 V/5 A Output RJ45 UC20-WL2000-AC Block diagram UC20-WL2000-IOT 2604080000/03/08.2020 Manual u-control...
  • Page 30 5 Detail description of controllers | UC20-WL2000-IOT Technical data UC20-WL2000-IOT (Order No. 1334990000) System data Connection 2 x RJ-45 Number of modules max. 64 active Configuration interface Micro USB 2.0 Processor Dual Core ARM A9, 624 MHz Memory 512 MB RAM, 4 GB flash Retain memory 128 KB NV-RAM Memory card (not included) microSD (max.

  • Page 31: Uc20-Sl2000-Ec

    5 Detail description of controllers | UC20-SL2000-EC UC20-SL2000-EC Status indicators Up to 64 active u-remote modules can be connected via the u-remote system bus to the UC20-SL2000-EC controller. The controller has two Ethernet connections for integration into the existing network architecture or HMI connections. The controller can be configured as a EtherCAT master.
  • Page 32 5 Detail description of controllers | UC20-SL2000-EC Controller power supply LED Green: supply voltage > 18 V Red: at least one current path < 18 V TD+ 1 TD– 2 RD+ 3 RD– 6 RUN/STOP TD+ 1 L/A X1 TD– 2 L/A X2 RD+ 3 24 V DC IN RD–...
  • Page 33 5 Detail description of controllers | UC20-SL2000-EC Internal from the control card System System System µC card Battery RJ45 24 V/5 A Output RJ45 UC20-SL2000-EC Block diagram UC20-SL2000-EC 2604080000/03/08.2020 Manual u-control...
  • Page 34 5 Detail description of controllers | UC20-SL2000-EC Technical data UC20-SL2000-EC (Order No. 2674520000)) System data Connection 2 x RJ-45 Number of modules max. 64 active Configuration interface Micro USB 2.0 Processor Dual Core ARM A9, 624 MHz Memory 512 MB RAM, 4 GB flash Retain memory 128 KB NV-RAM Memory card (not included) microSD (max.

  • Page 35: Uc20-Sl2000-Ec-Can

    5 Detail description of controllers | UC20-SL2000-EC-CAN UC20-SL2000-EC-CAN Status indicators Up to 64 active u-remote modules can be connected via the u-remote system bus to the UC20-SL2000-EC-CAN controller. The controller has two Ethernet connections for SL-EC-CAN integration into the existing network architecture or HMI con- nections.
  • Page 36 5 Detail description of controllers | UC20-SL2000-EC-CAN Controller power supply LED Green: supply voltage > 18 V SL-EC-CAN Red: at least one current path < 18 V TD+ 1 TD– 2 RD+ 3 RD– 6 TD+ 1 L/A X1 TD– 2 L/A X2 RD+ 3 24VDC IN RD–...
  • Page 37 5 Detail description of controllers | UC20-SL2000-EC-CAN Internal from the control card System System System µC card Battery RJ45 RJ45 24 V/5 A Output UC20-SL2000-EC-CAN Block diagram UC20-SL2000-EC-CAN 2604080000/03/08.2020 Manual u-control...
  • Page 38 5 Detail description of controllers | UC20-SL2000-EC-CAN Technical data UC20-SL2000-EC (Order No. 2674520000)) System data Connection 2 x RJ-45, 1 x CAN interface Number of modules max. 64 active Configuration interface Micro USB 2.0 Processor Dual Core ARM A9, 624 MHz Memory 512 MB RAM, 4 GB flash Retain memory 128 KB NV-RAM...

  • Page 39: Installation

    6 Installation | Preparations for assembly Installation Stripping lengths WARNING The required stripping length for every Weidmüller product Explosion risk! is specified in mm. These lengths, e.g. 6 mm ± 0.5 mm, During assembly work, sparks can form and ≥ 10 mm ±1 mm, must be observed. This also applies to surfaces may become excessively hot.
  • Page 40 6 Installation | Preparations for assembly In the case of vertical mounting, the controller must always Use in a potentially explosive atmosphere be arranged as the first module at the bottom and secured Please regard the safety notes in section 2.3. with a reinforced end bracket for vertical mounting (Order no.
  • Page 41 6 Installation | Preparations for assembly For vertical installation interchange height and width. When calculating the width, 4.5 mm for the must be added for the end bracket MEW 35/1 (Order No. 1805610000). 20 mm 0.97" Installation sequence A u-control station may only be installed in this sequence (starting from the left/bottom): –...

  • Page 42: Assembling The U-Control Station

    6 Installation | Assembling the u-control station Assembling the u-control station WARNING Explosion risk! ▶ Prior to starting work, make sure that there is not a potentially explosive atmos- phere! WARNING Dangerous contact voltage! ▶ All work on the u-control station must be Attaching the end bracket carried out with the power supply discon- When installing u-control products and u-remote...
  • Page 43 6 Installation | Assembling the u-control station ▶ Place the controller (module side to the right) on the DIN rail so that it audibly clicks into place. Sliding the module into position ▶ Attach all of the other modules as described above. Attaching the controller to the DIN rail ▶...

  • Page 44: Wiring

    6 Installation | Wiring Wiring Wiring of modules with connectors PG 1.5 mm Only copper wires with a cross section between 0.14 mm² and 1.5 mm² (AWG 16 – 26) may be connected. WARNING Explosion risk! We recommend using the following wire-end ferrules: ▶ Before assembly, make sure that there is Cross-section Weidmüller order no.

  • Page 45: Inserting The Battery

    6 Installation | Inserting the battery Inserting the battery WARNUNG Explosion risk! ▶ Do not use the controller with a battery in a potentially explosive atmosphere. WARNING Inserting the battery Battery may explode if mistreated! Use of a wrong battery type may cause ▶...

  • Page 46: Inserting The Sd Card

    6 Installation | Inserting the SD card Inserting the SD card Insulation test ▶ Unlock the connector frame and open it as far as possible Insulation tests on the u-control station have to be done ac- (at least to an angle of 90°). cording to the national regulations, in any case necessarily before each commissioning.

  • Page 47: Earthing And Shielding

    7 Earthing and shielding Earthing and shielding The terms “earths” and “shields” are classified according to The following figure shows how these two topics relate to their relation to human safety or system safety. An earth is each other in application. installed primarily to protect human life, and for this reason it is referred to as the protective earth (PE) conductor.

  • Page 48: Earthing Of Shielded Cables

    7 Earthing and shielding | Earthing of shielded cables Earthing of shielded cables The best type of shielding consists of a braided mesh sleeve that uses individual wires made of non-magnetic materials (copper, aluminium). The braided mesh should be sufficiently Electrical and electronic systems must be designed such that large and also be as thick as possible.
  • Page 49 7 Earthing and shielding | Earthing of shielded cables In practice, the shield is still often twisted and connected to a terminal point. There is very high attenuation (voltage drop) on these connections, especially for high-frequency interference. Therefore, this type of shielding should not be used, even for short cable lengths.
  • Page 50 7 Earthing and shielding | Earthing of shielded cables For longer lengths of shielded cables, such as if a sensor Effective shielding must be added to a control panel, a potential difference It is important that the shielding is not positioned on the between both end points must not be ignored.
  • Page 51 7 Earthing and shielding | Earthing of shielded cables KLBÜ CO KLBÜ CPF Ø 3-37 mm Ø 3-32 mm KLBÜ SC C-Profil Mounting accessories Ø 3-32 mm TS35 KLBÜ KLBÜ Z/1 Ø 2-32 mm Ø 4-6 mm Carrier systems TS35 Overview of the product line for shielding connections Please refer to our Modular Terminals Catalogue for more information.

  • Page 52: Potential Ratios

    7 Earthing and shielding | Potential ratios Potential ratios Potential-free design In a potential-free design, the reference potentials of control Basic aspects and load circuits are galvanically isolated from each other. A potential-free design is necessary for the following: As regards the potential ratios of a u-control station, the fol- –...
  • Page 53 7 Earthing and shielding | Potential ratios DI/AI DO/AO PF-O DO/AO PF-I DI/AI DIN rail earthing concept: The spring contacts underneath the components snap into the DIN rail to make a connection. 2604080000/03/08.2020 Manual u-control...

  • Page 54: Electromagnetic Compatibility (Emc)

    7 Earthing and shielding | Electromagnetic compatibility (EMC) Electromagnetic compatibility (EMC) PE connection The connection from earth to the PE (protective earth) con- u-control products and u-remote products completely meet nection must be done centrally. EMC requirements. EMC planning, however, is necessary prior to installation. WARNING Possible danger to life! Aspects to consider include all potential interference sources...
  • Page 55 7 Earthing and shielding | Electromagnetic compatibility (EMC) 1 Earthing strips Cabinet design according to EMC guideline: Earthing strips must be used for connecting inactive metal parts if it is not possible to connect two large pieces of met- al. Use short earthing strips with large surfaces. 2 Clamping bracket for signal cables If shielded signal cables are used, the shield must be at- tached to the clamping bracket (KLBÜ...

  • Page 56: Shielding Of Cables

    7 Earthing and shielding | Shielding of cables Shielding of cables ATTENTION Material damage! To prevent the coupling of interference voltages and the de- If it is only possible to have a one-sided shield connection coupling of interference fields in cables, only shielded cables for reasons specific to the circuit or equipment, the second made from well-conducting material (copper or aluminium) side of the cable shield can be routed to the local reference...
  • Page 57 7 Earthing and shielding | Shielding of cables Equipotential bonding 2604080000/03/08.2020 Manual u-control...
  • Page 58 Manual u-control 2604080000/03/08.2020...

  • Page 59: Commissioning Using U-Create Web

    8 Commissioning using u-create web | Requirements Commissioning using u-create web Web browser WARNING u-create web can be used with the following web browsers. Explosion risk! – Mozilla Firefox 61 or higher ▶ Before starting any work, make sure that – Google Chrome 67 or higher there is not a potentially explosive atmos- Screen resolution phere!

  • Page 60: Accessing U-Create Online Help

    8 Commissioning using u-create web | Accessing u-create online help Accessing u-create online help The built-in online help describes how to operate u-create. Login window (Example: Google Chrome) Your login details are requested. Accessing the online help The following login data are then requested: ▶...

  • Page 61: Resetting The Controller To Default Settings

    8 Commissioning using u-create web | Resetting the controller to default settings Resetting the controller to default settings The connection to u-create is interrupted, the controller re- starts and the page SWUpdate is displayed in the browser. The following data are reset: – The current runtime application is removed. –...
  • Page 62 Manual u-control 2604080000/03/08.2020...

  • Page 63: Commissioning Using U-Create Studio Requirements

    – UC20-SL2000-EC With the DevAdmin web application, UC20-SL2000 control- – UC20-SL2000-EC-CAN lers are displayed on a connected PC. With DevAdmin, you can perform the following functions for test purposes, during Before you start the commissioning work, the following re- commissioning or in case of service: –...
  • Page 64 9 Commissioning using u-create studio | Starting „DevAdmin“ ▶ Open a web browser. ▶ In the address bar, enter the IP address of the controller. – Ethernet access: 192.168.101.100 DevAdmin is started. You will be asked to enter your login data. The following login data is valid on delivery: Username: Administrator Password:...

  • Page 65: Replacing Components

    10 Replacing components | Removing/replacing the plug-in unit 10 Replacing components 10.1 Removing/replacing the plug-in unit ▶ Swivel the plug-in unit with the cabling towards the front by 90°. WARNING The plug-in unit can only be removed in this 90° position! Explosion risk! ▶...

  • Page 66: Removing/Replacing Connectors

    10 Replacing components | Removing/replacing connectors 10.2 Removing/replacing connectors WARNING Explosion risk! ▶ Prior to starting work, make sure that there is not a potentially explosive atmos- phere! WARNING Operation of the machine/system can be disrupted! ▶ In the event of the machine/system being put into a dangerous state as a result of the removal of a connector, a replacement can only be made once the machine/sys-...

  • Page 67: Removing/Replacing Cables

    10 Replacing components | Removing/replacing cables 10.3 Removing/replacing cables ▶ Using a 3-mm screwdriver, push in the pusher adjacent to the cable to be removed and pull the wire out. WARNING Explosion risk! ▶ Prior to starting work, make sure that there is not a potentially explosive atmos- phere! WARNING Operation of the machine/system can...

  • Page 68: Replacing The Battery

    10 Replacing components | Replacing the battery 10.4 Replacing the battery WARNING Explosion risk! ▶ Before starting any work, make sure that there is not a potentially explosive atmos- phere! WARNING Operation of the machine/system can be disrupted! ▶ In the event of the machine/system being put into a dangerous state as a result of the removal of the supply voltage, a replacement can only be made once the...

  • Page 69: Replacing The Sd Card

    10 Replacing components | Replacing the SD card 10.5 Replacing the SD card WARNING Explosion risk! ▶ Before starting any work, make sure that there is not a potentially explosive atmos- phere! WARNING Operation of the machine/system can be disrupted! ▶ In the event of the machine/system being put into a dangerous state as a result of the removal of the supply voltage, a replacement can only be made once the...
  • Page 70 Manual u-control 2604080000/03/08.2020...

  • Page 71: Disassembly And Disposal

    11 Disassembly and disposal | Disassembling the u-remote station 11 Disassembly and disposal 11.1 Disassembling the u-remote station 11.2 Disposing of the u-control station WARNING ATTENTION Explosion risk! Products in the u-remote series are subject ▶ Prior to starting work, make sure that to WEEE (EU Directive 2012/19/EU), which there is not a potentially explosive atmos- regulates the collection and recycling of elec-...
  • Page 72 Manual u-control 2604080000/03/08.2020...

  • Page 73: Led Indicators And Troubleshooting

    12 LED indicators and troubleshooting 12 LED indicators and troubleshooting In the event of a malfunction occurring on a u-control prod- uct, carry out the following recommended measures. If the malfunction cannot be fixed, please send the affected prod- uct to Weidmüller. You can find all Weidmüller addresses and your local contact on the Internet at www.weidmueller.com.
  • Page 74 12 LED indicators and troubleshooting Controller/indicator Status Recommended action UC20-WL2000-IOT Power LED green: supply voltage present, firmware is running – System failure red: serious system failure Switch supply voltage off and on again and deploy application again Bus failure green: communication with modules OK –...
  • Page 75 12 LED indicators and troubleshooting Controller/indicator Status Recommended action UC20-SL2000-EC , UC20-SL2000-EC-CAN Power LED green: supply voltage present, bootloader/firmware – is running System failure red: system bus failure Read off the diagnostic message from the engineering tool and determine which further actions to take...
  • Page 76 Manual u-control 2604080000/03/08.2020...

  • Page 77: Accessories And Replacement Parts

    13 Accessories and replacement parts | Accessories 13 Accessories and replacement parts 13.1 Accessories Order No. Designation Purpose 9009030000 Screwdriver SDS 0.4X2.5X75 Unfastening conductors from PUSH IN contacts 9008320000 Screwdriver SDS 0.5X3.0X80 Assembling/disassembling an end bracket 1323700000 PM 2.7/2.6 MC SDR marker Connection marker for a pusher, with custom printing to customer specifica- tions 1323710000 PM 2.7/2.6 MC NE WS marker...

  • Page 78: Replacement Parts

    Order No. UC20-WL2000-AC 1334950000 Plug-in unit 2425170000 UR20-PK-1334940000-SP UC20-WL2000-IOT 1334990000 Plug-in unit 2425170000 UR20-PK-1334940000-SP UC20-SL2000-EC 2674520000 Plug-in unit 2425170000 UR20-PK-1334940000-SP UC20-SL2000-EC-CAN 2674620000 Plug-in unit 2425170000 UR20-PK-1334940000-SP PCB plug-in connector for CAN interface 1278050000 B2CF 3.50/06/180LR SN OR BX Manual u-control 2604080000/03/08.2020...

  • Page 79: Annex

    ANNEX Examples of module position coding Breakdown of Serial Numbers Service 2604080000/03/08.2020 Manual u-control...
  • Page 80 Examples of module position coding The incorrect insertion of electronic units can be pre- Functionally-oriented coding vented if the base modules are given coding elements Coding position KOSM BHZ5.00 (Order No.1483050000) Three coding sockets each with four possible positions can Code Meaning be plugged into every base module.
  • Page 81 Slot-oriented coding Slot-oriented coding Coding position Coding position Code Station slot Code Station slot 2604080000/03/08.2020 Manual u-control...
  • Page 82 Breakdown of Serial Numbers Position Year Code Month Code Code Production Code Product family code Serial numbers plant 2013 January 2014 February 2015 March 2016 April 2017 June 2018 July 2019 2020 August 2021 September 2022 October 2023 November 2024 December 2025 2026...
  • Page 83 Service If you have any questions about u-remote, please contact your responsible country representatives. You can find all Weidmüller addresses and Sales company your local contact on the internet at: www. weidmueller.com/countries Representation abroad without representation abroad Let’s connect. Moldova Netherlands Puerto Rico El Salvador...
