5 Detail description of controllers | UC20-WL2000-IOT
Technical data UC20-WL2000-IOT (Order No. 1334990000)
Tests
Vibration resistance
Shock resistance
Potential isolation
Currently u-create web does not support retain variables but
variables in the data storage. The values of the variables in the
data storage are stored in the flash memory.
Please observe the release notes for the controller.
36
5 Hz ≤ f ≤ 8.4 Hz: 3.5 mm amplitude as per IEC 60068-2-6
8.4 Hz ≤ f ≤ 150 Hz: 1 g acceleration as per IEC 60068-2-6
15g over 11ms, half sine wave, as per IEC 60068-2-27
Test voltage
Pollution degree
Overvoltage category
Manual u-control
max. 28.8 V inside a channel
500 V DC field/system (according to EN 60079-
15:2010)
2 (according to DIN EN 60664-1:2008)
II (according to DIN EN 50178)
