Smartrise C4 Quick Start Manual

Hide thumbs Also See for C4:
Table of Contents

Advertisement

Quick Links

Download this manual
C4
QUICK START GUIDE
VERSION 1.0

Advertisement

Table of Contents
loading

Related Manuals for Smartrise C4

Summary of Contents for Smartrise C4

  • Page 1 QUICK START GUIDE VERSION 1.0...
  • Page 2 ..Document History.. Date Version Summary of Changes March 14, 2024 Initial Release...

  • Page 3: Table Of Contents

    Table of Contents Construction Mode ........................1 Construction Mode Setup ......................1 Drive Setup ..........................1 Fire Service Bypass ........................1 Normal Terminal Stop Bypass ..................... 2 Running the Car on Construction Mode ..................2 Landing System ........................... 4 Speed Control via Feedback from Landing System ..............4 Inspection Mode ...........................
  • Page 4 List of Figures Figure 1: Construction Mode Connections on a C4 Controller ..............1...
  • Page 5 Page intentionally left blank.

  • Page 6: Construction Mode

    Before power can be supplied to the controller, the controller should be placed in Construction Mode. The required temporary connections and jumpers on a C4 controller under Construction Mode is shown in Figure 1. Once the controller is in Construction Mode, it can be powered on.

  • Page 7: Normal Terminal Stop Bypass

    2. Go to FAULTS. 3. Go to ACTIVE FAULTS. See the Fault and Alarm Manual for C4 controllers. If no active faults are detected, a zero-speed test is recommended to verify that the brakes are receiving the right picking voltage.
  • Page 8 ..C4 Quick Start Guide.. 3. Go to SPEEDS. 4. Go to INSPECTION SPEED. 5. Set the speed to 0 FPM. To ensure the brakes are receiving the right picking voltage, follow this procedure: 1. On the controller, hit the SAFE button and CONSTRUCTION UP or CONSTRUCTION DOWN buttons simultaneously.

  • Page 9: Landing System

    ..C4 Quick Start Guide.. 1.6 Landing System Once the car is running smoothly, install the landing system (see the CEDES/ELGO Installation Manual). 1.7 Speed Control via Feedback from Landing System After the landing system has been installed, run the car, and observe the actual vs. demanded speed of the elevator.

  • Page 10: Inspection Mode

    ..C4 Quick Start Guide.. 2 Inspection Mode 2.1 Connecting the Car Top and Car Operating Panel Boards See the Traveler Connections page to know how to connect the machine room controller with the Car Top (CT) and Car Operating Panel (COP) boards. The most common mistake is a miscommunication on the CAN1/2 network (Double/triple check the wirings).

  • Page 11: Automatic Mode

    ..C4 Quick Start Guide.. 3 Automatic Mode 3.1 High Speed Runs Once the hoistway learning is completed, the elevator can start making multiple floor runs. Manual car calls can be placed using the following steps: 1. Navigate to MAIN MENU.
  • Page 12 ..C4 Quick Start Guide.. Induction motors: Try running in Open loop, in other words, no Encoder feedback. Magnetek: Utilities (U0) -> Basics (U9) -> Drive mode -> Open loop KEB: Control Setting -> Control Mode (LC01) -> set parameter to 0 (Open Loop).

  • Page 13: Rollback Mitigation Without The Use Of The Load Weigher

    ..C4 Quick Start Guide.. Control Setting -> LC03 - LC12 -> cut all gains by half and confirm. If the above methods made no difference and the car still vibrates, make sure the vibrations are not mechanical. Drift the car with no power and determine the source of the vibrations, if there are any.

  • Page 14: Full Load Operation Issues

    ..C4 Quick Start Guide.. 3. Go to START TIMERS. 4. Select ACCEL DELAY (AUTO) or (INSP). 5. Gradually increase the time. 3.5 Full Load Operation Issues When having issues running the car with a full weight capacity loaded in, a zero-speed test can help isolate the issue.

  • Page 15: Inconsistent Floor Levels

    ..C4 Quick Start Guide.. 3.6 Inconsistent Floor Levels Inconsistent floor levels may not always be because of the landing system, most of the time the issue stems from poor motor control at low speeds. Try the following solutions: Magnetek: Adjust (A0) -> Drive (A1) -> Inertia -> try using increments of 0.1 from the default (2).

  • Page 16: List Of Abbreviations

    ..C4 Quick Start Guide.. List of Abbreviations Car Top Car Operating Panel Emergency Slowdown Load Weighing Device Normal Terminal Stop 2023 © Smartrise Engineering, Inc. All Rights Reserved...
