5. Hardware

5.1. About Mitsubishi Electric Centralized Controller for M-Net

This integration requires the Mitsubishi Electric City Multi AC system to be equipped with a Mitsubishi Electric
Centralized Controller for M-Net. This Centralized Controller offers the signals of the City Multi AC system
through XML protocol to its Ethernet port, which is accessed by the Intesis IN770MIT00xO040 gateway.
IMPORTANT
Most Mitsubishi Electric Centralized Controllers require a PC-Monitoring (SW-Mon) software license,
which must be purchased together with the centralized controller for the XML interface to be active
and used by the Intesis gateway.
IMPORTANT
List of compatible centralized controllers:
• G-50
• G-50A
• GB-50A
• GB-50ADA
• AB-150
• AE-200
• AE-50
• AG-150A
• EW-50
• EB-50GU

5.2. Mounting

IMPORTANT
Before mounting, please ensure that the chosen installation place preserves the gateway from direct
solar radiation, water, high relative humidity, or dust.
IMPORTANT
Maximum mounting height: below 2 meters (6.5 feet).
NOTE
Mount the gateway on a wall or over a DIN rail. We recommend the DIN rail mounting option,
preferably inside a grounded metallic industrial cabinet.
IMPORTANT
Ensure the gateway has sufficient clearances for all connections when mounted. See
(page 19).
