HMS Networks Intesis IN770MIT00XO040 User Manual page 25

Mitsubishi Electric domestic and commercial with KNX, Serial and IP
support
Register name
Vane position
Temperature Setpoint (°C)
Temperature Setpoint (°C)
Ambient Temperature (°C/x10°C)
Operational Status for Lossnay or OA
Group operation time (x100 hours)
Group operation time (%100 hours)
Group error status
Group error code
Group error reset
Group model
Allow ON/OFF control from the local panel
Allow operation mode control from the local panel
Allow set point control from the local panel
Allow filter reset control from the local panel
Allow air direction control from the local panel
Allow fan speed control from the local panel
Allow timer control from the local panel
Setback control
Minimum cool setpoint restriction
Maximum cool setpoint restriction
Minimum heat setpoint restriction
Maximum heat setpoint restriction
Minimum auto setpoint restriction
Maximum auto setpoint restriction
Page 22 of 35
Possible values
0: Auto
1: Horizontal
2: Position 2
3: Position 3
4: Position 4
5: Vertical
6: Swing
Cool or dry: 19 .. 30°C / 66 .. 86°F
Heat or Auto: 17 .. 28°C / 63 .. 82°F
Celsius: 5 .. 90°C
Fahrenheit: 41 .. 194°F
0.0 .. 99.9
0: Off
1: Low
2: High
0 .. 9999
0 .. 99
0: No error
1: Group error
Number of the error code (XXXX)
1: Reset the error
Model of units connected to group
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Disable
1: Enable
Celsius: 4.5 .. 35°C
Fahrenheit: 40 .. 95°F
Celsius: 4.5 .. 35°C
Fahrenheit: 40 .. 95°F
Celsius: 4.5 .. 35°C
Fahrenheit: 40 .. 95°F
Celsius: 4.5 .. 35°C
Fahrenheit: 40 .. 95°F
Celsius: 4.5 .. 35°C
Fahrenheit: 40 .. 95°F
Celsius: 4.5 .. 35°C
Fahrenheit: 40 .. 95°F
Integration into Modbus Systems
Modbus address formula
(((CTRL#-1)*50)+Group#*100)+3
(((CTRL#-1)*50)+Group#*100)+4
(((CTRL#-1)*50)+Group#*100)+4
(((CTRL#-1)*50)+Group#*100)+5
(((CTRL#-1)*50)+Group#*100)+6
(((CTRL#-1)*50)+Group#*100)+7
(((CTRL#-1)*50)+Group#*100)+8
(((CTRL#-1)*50)+Group#*100)+9
(((CTRL#-1)*50)+Group#*100)+10
(((CTRL#-1)*50)+Group#*100)+11
(((CTRL#-1)*50)+Group#*100)+12
(((CTRL#-1)*50)+Group#*100)+13
(((CTRL#-1)*50)+Group#*100)+14
(((CTRL#-1)*50)+Group#*100)+15
(((CTRL#-1)*50)+Group#*100)+16
(((CTRL#-1)*50)+Group#*100)+17
(((CTRL#-1)*50)+Group#*100)+18
(((CTRL#-1)*50)+Group#*100)+19
(((CTRL#-1)*50)+Group#*100)+20
(((CTRL#-1)*50)+Group#*100)+21
(((CTRL#-1)*50)+Group#*100)+22
(((CTRL#-1)*50)+Group#*100)+23
(((CTRL#-1)*50)+Group#*100)+24
(((CTRL#-1)*50)+Group#*100)+25
(((CTRL#-1)*50)+Group#*100)+26
USER MANUAL Version 1.0.1
R/W
R, W
R, W
R, W
R
R, W
R
R
R
R
W
R
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
R, W
