SAW Type 24-pin QFN (4mm×4mm×0.75mm) Outline Dimensions
Symbol
A
A1
A3
b
D
E
e
D2
E2
L
Symbol
A
A1
A3
b
D
E
e
D2
E2
L
Rev. 1.50
BC68F2130/BC68F2140/BC68F2150
Sub-1GHz RF Transmitter Flash MCU with OCDS
Dimensions in inch
Min.
0.028 0.030
0.000 0.001
— 0.008 BSC
0.007 0.010
— 0.157 BSC
— 0.157 BSC
— 0.020 BSC
0.104 0.106
0.104 0.106
0.014 0.016
Dimensions in mm
Min.
0.70
0.00
— 0.203 BSC
0.18
— 4.00 BSC
— 4.00 BSC
— 0.50 BSC
2.65
2.65
0.350 0.400
150
Nom. Max.
0.031
0.002
—
0.012
—
—
—
0.108
0.108
0.018
Nom. Max.
0.75 0.80
0.02 0.05
—
0.25 0.30
—
—
—
2.70 2.75
2.70 2.75
0.450
