AL (Alarm) no
illumination
solid amber
pulsing
amber
(A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.)

2.0 T1 PARAMETERS

Parameters common to all of Net to Net's interface modules are defined in Net to Net's management user
guides; refer to the NMS Management User Guide (
0000048 ) and/or the CLI Management User Guide (
0000052 ). Parameters specific to the TIM1500 are outlined below.

2.1 Parameter Defaults

No configuration is necessary for the TIM1500 to operate at default settings.
Parameter

Transmit (Tx) Buildout

Clock Source
Flood
Frame Type
IP Range 1
IP Range 2
Line Code
Priority
Protocol
Speed (Single Line)
VLAN
VLAN Back-bone
210-0000053 rev02
T1 is operational
Yellow Alarm
An outgoing connection has been
lost; the remote T1 modem is
not receiving any data from the
T1 port.
Blue Alarm
An indirect connection has been
lost; the T1 port may no longer
be receiving data from the
remote T1 modem.
Default
0 decibels (dB)
Local - provider mode
Loop - subscriber mode
Uplink
Extended Super Frame (ESF)
0.0.0.0 - 255.255.255.255
0.0.0.0 - 0.0.0.0
Bipolar with 8 Zero Substitution (B8ZS)
0
ALL
1,536 kbps
0 - 0
0
TIM1500 User Guide
An established T1 link has no alarm indications and
is operational UNLESS the LK LED remains unlit as
well, in which case the T1 port is in Red Alarm.
The remote T1 modem has lost its incoming
connection and is in Red Alarm.
The remote T1 modem has lost a connection with
an intermediate device and is in Red or Yellow
Alarm.
http://www.nettonet.com/support/docs/210-
http://www.nettonet.com/support/docs/210-
Page 17 of 21
