1.4.2 Remote Connection
The TIM1500 is capable of supporting both single-line connections and multiple-line loop
bonded connections, as well as any combination of the two. If the distance(s) between the
TIM1500 and any of the remote T1 equipment is greater than 6,000 feet, the line(s) may
require a T1 repeater.
210-0000053 rev02
1.4.1.4.3 B Connector Pinout
(IPD12000E top row and IPD4000E right side)
TIM1500 T1 PORTS
13
Ring
14
TX
Tip
39
RJ21
PINS
Ring
1
RX
Tip
26
(pins 13 and 38 are not used)
IPD12000E
TIM1500 User Guide
B CONNECTORS
14
15
16
17
18
19
15
16
17
18
19
20
40
41
42
43
44
45
2
3
4
5
6
7
27
28
29
30
31
32
20
21
22
23
24
21
22
23
24
25
46
47
48
49
50
8
9
10
11
12
33
34
35
36
37
Page 14 of 21
