6.0 ADDITIONAL INFORMATION

6.1 LED Indications

LED
PWR (Power)
SDSL LK (Link)
SDSL RX
(Receiving)
SDSL TX
(Transmitting)
(A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more
rapid, less constant rate.)

6.2 Regulatory Compliance for Class A Equipment

6.2.1 US Federal Communications Commission (FCC)
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own
expense.
Caution: Changes or modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment.
210-0000049 rev 05
State Indication
solid green SIM2000-24 is
operational
pulsing SDSL connection is
green established and
active
solid green problematic SDSL
connection
no no SDSL connection
illumination
flashing SDSL activity
amber
solid amber heavy Rx traffic
no no activity
illumination
flashing SDSL activity
amber
solid amber heavy Tx traffic
no no activity
illumination
Additional Information
If the Power LED is not illuminated, it is unlikely
the SIM2000-24 is receiving power and none of
the LEDs will be illuminated.
The SDSL link is operational and traffic is flowing.
A connection exists but there is indication of a
problem with the SDSL line.
The port is receiving either data from the remote
SDSL subscriber unit or statistical packets from
the IP DSLAM management.
The port is receiving large amounts of data from
the remote SDSL subscriber unit.
A link may exist but the port is not receiving any
data from the remote SDSL subscriber unit.
The port is transmitting data to the remote SDSL
subscriber unit.
The port is transmitting large amounts of data to
the remote SDSL subscriber unit.
A link may exist but the port is not transmitting
any data to the remote SDSL subscriber unit.
