SDSL link has been established; the SDSL LK LED for that port will pulse green to indicate the
connection has been made. Link up time can vary from one to five minutes depending on the quality,
gauge and distance of the copper cables.
PORT
Tip
SDSL
Ring 1
(pins 25 and 50 are not used)
1.3.1 Loop Bonded SDSL Connection
Using two SDSL lines for one network connection (loop bonding) will net twice the speed and data
passing capability as a single-line SDSL connection. A second SDSL line can also be considered a
backup for the first, and vice versa, should either line become disabled. Any two SIM2000-24
ports (consecutive or not) may be connected to an SNE2020-S or SNE2020G-S subscriber unit to
establish a loop bonded connection.
N Net to Net Technologies strongly suggests that any ports on the SIM2000-24 intended for a loop bonded
OTE
connection with an SNE2020-S or SNE2020G-S be identically configured prior to connection; bonding ports
with different configurations will likely result in misplaced, misdirected and/or dropped data. See the NMS
Management User Guide and /or the CLI and SNMP Management User Guide for configuration instructions.
If default settings are to be used for both ports, then prior configuration is not necessary and you may
proceed with installation.
1.3.2 Single Line SDSL Connection
A single line connection can be established between a SIM2000-24 and any of Net to Net's SDSL
subscriber units.
1.3.3 Bandwidth and Line Code
There are nine bandwidth options for SIM2000-24 SDSL connections. Distance capabilities vary,
dependent upon the type of line code being utilized. The defaults are TC/PAM line encoding
(G.SHDSL) at 272 kbps. See Section 4.0 SIM2000-24 Parameters for more detailed information
regarding bandwidth and line code.

2.0 DEFAULT SETTINGS

No configuration is necessary for the SIM2000-24 to operate at default settings.
CONFIGURATION
Line Code
Circ. ID (Circuit Indentification) n/a (no default)
IP Range 1
IP Range 2
Speed:
210-0000049 rev 05
1 2 3 4 5 6 7
26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49
2 3 4 5 6 7
DEFAULT
TC/PAM (G.SHDSL)
0.0.0.0 - 255.255.255.255
0.0.0.0 - 0.0.0.0
272 kbps
SDSL RJ21 Port Pinout
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
CONFIGURATION
Protocol
VLAN Ranges (1-10) 0 - 0 (off)
Backbone-VLAN
Pri (VLAN Priority)
Flood
DEFAULT
All
0 (off)
0 (none)
Upl (Uplink)
