3.2 Via CLI
Interface modules in an IP DSLAM with a Command Line Interface (CLI) compatible MUM (select
models only) can be managed with a Terminal Emulator program (loaded onto your PC) via a set of
commands and sub-commands/qualifiers.
3.2.1 Establish a Connection with the IP DSLAM MUM
Establish a direct connection with the MUM through the RS232 COM Port on the MUM faceplate.
3.2.2 Launch a Terminal Emulator
Launch a Terminal Emulator program on your PC. Net to Net Technologies copyright information
will appear on your screen followed by a request for username.
3.2.3 Log in
Log in with your assigned username*. Once your username has been entered, a request for
password* will appear. Please note that for SIM2000-24 configuration you must log in as a
Superuser (General Users have read only access).
*If your username and/or password are unknown, contact your System Administrator or
Information Technology Manager for assistance.
Once you have logged in as a Superuser, you may make configuration changes to the SIM2000-24, and
any other interface modules installed in the IP DSLAM, as desired. For more detailed information
regarding SIM2000-24 parameters and configuration, refer to Section 4.0 of this manual and/or the
CLI and SNMP Management User Guide.

3.3 Via SNMP

Simple Network Management Protocol (SNMP) is the standard for management of Transmission
Control Protocol/Internet Protocol (TCP/IP) networks and network devices. Interface modules in an IP
DSLAM with an SNMP compatible MUM can be managed with a MIB Browser program (loaded onto
your PC) via a set of Object Identifiers (OIDs). OIDs are strings of numbers specifying various
configuration commands and requests for data.
N If your IP DSLAM is newly installed and has not yet been set up for management access, you must configure the IP
OTE
Address, Subnet Mask and Gateway (via either NMS or CLI) before you will be able to utilize SNMP. See the NMS
Management User Guide or CLI and SNMP Management User Guide for initial configuration instructions.
3.3.1 Establish a Connection with the IP DSLAM MUM
Establish a connection with the MUM either directly (through the Ethernet RJ45 MGMT port on the
MUM faceplate) or, if the system has been so configured, from a PC on your local network. For
direct connections verify that the MGMT LNK LED on the MUM faceplate is illuminated (indicating
the connection has been established).
