3.0 SIM2000-24 MANAGEMENT

Once the SIM2000-24 has been installed, line code, bandwidth and all other configurations are software
selectable. Dependent upon the MUM model installed in your DSLAM, the SIM2000-24 can be configured via
Command Line Interface (CLI), Simple Network Management Protocol (SNMP) and/or Net to Net
Technologies' web-based Network Management System (NMS). For further information regarding SIM2000-
24 management and configuration please refer to Net to Net Technologies' NMS Management User Guide
and/or CLI and SNMP Management User Guide.
3.1 Via NMS
Net to Net Technologies' Network Management System (NMS) is an embedded web server that resides
within the firmware of IP DSLAM MUMs (select models only). This web server maintains statistical and
configuration data for the SIM2000-24 and includes a scaled-down version of Simple Network
Management Protocol (SNMP v1.0).
N If your IP DSLAM is newly installed and has not yet been set up for management access, you must configure the IP
OTE
Address, Subnet Mask and Gateway (via either NMS or CLI) before you will be able to access data or complete any
other configurations. See the NMS Management User Guide or the CLI and SNMP Management User Guide for initial
configuration instructions.
3.1.1 Establish a Connection with the IP DSLAM MUM
Establish a connection with your IP DSLAM MUM either directly (through the Ethernet RJ45 MGMT
Port on the MUM faceplate) or, if the system has been so configured, from a PC on your local
network. For direct connections, verify that the MGMT LNK LED on the MUM faceplate is
illuminated (indicating the connection has been established).

3.1.2 Launch a Web Browser

Launch a web browser on your PC such as Microsoft Internet Explorer (v4.0 or higher) or
Netscape Navigator (v4.0 or higher).

3.1.3 Enter the IP Address

Enter the DSLAM's IP address* into the address field at the top of your browser window. Press the
Enter key.
3.1.4 Log In
Log in with your assigned username and password.* Please note that General Users have read
only access; for SIM2000-24 configuration you must log in as a Superuser.
*If the IP address, username and/or password are unknown, contact your System Administrator
or Information Technology Manager for assistance.
Once you have logged in as a Superuser, you may make configuration changes to the SIM2000-24, and
any other interface modules installed in the IP DSLAM, as desired. For more detailed information
regarding SIM2000-24 parameters and configuration, refer to Section 4.0 of this manual and/or the
NMS Management User Guide.
210-0000049 rev 05
