User Manual
3

INTRODUCTION

3.1

SYSTEM DESCRIPTION

The flow rate indicator / totalizer model F014-P is a microprocessor-driven instrument designed to
show the current flow rate, resettable total and non-resettable accumulated total, as well as to
generate a scaled pulse according to the accumulated total.
This manual describes the daily use, configuration and installation of the F014-P with pulse input
from a flowmeter and its available options.
The following figure shows the F014-P used in a typical application.
3.2

PRODUCT FEATURES

General characteristics
● Ultra-low power consumption to allow for long battery life (Type PB/PC)
● Various mounting possibilities
● A choice of enclosure materials: GRP, aluminum or stainless steel (316L), suitable for every
industrial environment
● Ability to process a broad range of sensor signals
● Simple and standard configuration and operator interface.
● Transmitting possibilities with one configurable pulse output
Page 6
Fig. 1:
The F014
Fig. 2:
Typical application
FW_F014-P_M_v0501-03_EN
F014-P
