  • Page 1 User manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Product revision Software Revision: 2.0.x Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
  • Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.
  • Page 4 Disclaimer for camera usage Barco provides a kit with a laser range finder and USB camera to help measure the distance from the front of the projector to the projected surface and to help monitor the performance of the projector. Barco disclaims any liability for any use of the USB camera outside this intended use.

  • Page 5: Table Of Contents

    Table of contents 1 Safety information....................................9 General Considerations ................................10 Important safety instructions..............................11 Product safety labels..................................15 High Brightness precautions: Hazard Distance ......................16 HD for fully enclosed projection systems...........................18 HD in function of modifying optics ............................20 Radio equipment (optional) ...............................20 Download Product Manual ................................21 2 Getting Started......................................23 Getting to know the projector ..............................24...
  • Page 6 Pulse Quad Combo input Mk II ...............................45 Pulse Quad Combo input Mk I..............................46 Pulse Quad DP 1.2 input ................................47 Pulse SFP input ....................................48 5 GUI – Introduction ....................................49 Overview......................................50 Navigation ......................................51 Test Patterns......................................53 6 GUI – Source ......................................55 Displaying a single source .................................56 Displaying multiple sources: Stitched layouts.........................56 Connector Settings ..................................58 7 GUI –...
  • Page 7 8.13.4 3D Setup ..................................111 9 GUI – Profiles ......................................113 Profiles introduction ..................................114 Profiles setup parameters ................................114 Create new profile ..................................115 10 GUI – System Settings ..................................119 10.1 Communication, LAN setup ..............................120 10.1.1 Introduction to a Network connection ......................120 10.1.2 Wired IP address set up ............................
  • Page 8 B Video timing tables................................... 173 Overview video timings................................174 Overview video timings SDI Inputs ............................ 175 Overview video timings HDMI 2.0 inputs........................176 Overview video timings DisplayPort 1.2 inputs ......................178 Overview video timings HDBaseT inputs ........................180 C DMX chart......................................... 183 DMX chart input board positioning .............................

  • Page 9: Safety Information

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the UDM projector. Clarification of the term “UDM” used in this document When referring in this document to the term “UDM” means that the content is applicable for following Barco products: •...

  • Page 10: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments must be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals must be adhered to.

  • Page 11: Important Safety Instructions

    See the product safety manual for details. Users definition Throughout this manual, the term SERVICE PERSONNEL refers to Barco authorized persons having appropriate technical training and experience necessary to be knowledgeable of potential hazards to which they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons.
  • Page 12 This product contains no user serviceable parts. Attempts to modify/replace mechanics or electronics inside the housing or compartments will violate any warranties and may be hazardous. This kind of operations shall only be performed by Barco authorized service personnel. •...
  • Page 13 • Max units in hanging configuration, 2 units. • When hanging projectors on a truss with the Barco stacking frame, always secure the stack with safety cables between the projectors and the truss. • When using the projector in a hanging configuration, always mount 2 safety cables. See installation manual for the correct use of these cables.
  • Page 14 For lens cleaning follow the instructions precisely as stipulated in the projector manual. • Only use zoom lenses of the Barco TLD+ series on the 4K models of the projector. Using other lenses will damage the internal optics. For suitable fixed TLD+ lenses contact Barco or see Barco website.

  • Page 15: Product Safety Labels

    Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 16: High Brightness Precautions: Hazard Distance

    Safety information Label image Label description Label location Hazard class 2: laser radiation warning symbol. 0.95 mW - 638 nm. WARNING! DO NOT LOOK INTO THE BEAM NO DIRECT EYE EXPOSURE TO THE PROJECTOR BEAM IS PERMITTED LASER RADIATION - DO NOT STARE INTO LASER RANGING BEAM RG3 IEC EN 62471-5:2015 CLASS 2 IEC EN 60825-1:2014 HAZARD DISTANCE: CONSULT SAFETY MANUAL...
  • Page 17 Safety information For example, projectors that have a HD greater than 1 m and emit light into an uncontrolled area where persons may be present should be positioned in accordance with “the fixed projector installation” parameters, resulting in a HD that does not extend into the audience area unless the beam is at least 2.0 meter above the floor level.

  • Page 18: Hd For Fully Enclosed Projection Systems

    The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.
  • Page 19 Safety information RESTRICTED AREA DIFFUSE REFLECTION Image 1–4 Restricted Access location (enclosed projection area). Restriction Zone. Projector. Projection Distance. Theater (observation area). Separation Width. Must be minimum 1 meter. For this type of setup 3 different HD shall be considered: •...

  • Page 20: Hd In Function Of Modifying Optics

    The UDM is restricted to indoor use only when operating in the 5150 to 5250 MHz frequency range. Hereby, Barco declares that the radio equipment type UDM is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.barco.com/support...

  • Page 21: Download Product Manual

    Max EIRP: 27 dBm 1.8 Download Product Manual Download Product Manual Product manuals and documentation are available online at www.barco.com/td. Registration may be required; follow the instructions given on the website. IMPORTANT! Read Installation Instructions before connecting equipment to the mains power supply.
  • Page 22 Safety information R5911443 /03...

  • Page 23: Getting Started

    Getting Started Getting to know the projector ......................24 Power on the projector ........................26 Start image projection ........................27 Switching to standby ........................29 Power off projector........................29 About this chapter This chapter and by extension this whole document, the user manual, is intended for the user who want’s to operate the projector.

  • Page 24: Getting To Know The Projector

    Getting Started 2.1 Getting to know the projector Orientation convention This manual refers to the left side of the projector as the side at your left hand when standing behind the projector and looking at the projection screen in front of the projector. Image 2–1 Right Left...
  • Page 25 Getting Started 9 10 11 Image 2–3 IR receiver projector rear side Overvoltage status light Mains power input socket (for USB port (to control C19 plug) motorized rigging frame) Power ON/OFF switch For detailed info about the Input & Communication module see chapter “Input & Communication”, page 39. Projector airflow The projector has three air inlets: one at the top, one at the front and one at the right side of the projector.

  • Page 26: Power On The Projector

    Getting Started Image 2–5 For detailed info about the RCU see chapter “Pulse Remote Control Unit”, page 31. 2.2 Power on the projector How to power on Does the OVERVOLTAGE status light (reference 1) lit up? ► If yes, pull out the power cord immediately. Contact a qualified technician to check the power net. Warning: Never switch on the projector if the OVERVOLTAGE status light lit up.

  • Page 27: Start Image Projection

    Getting Started Image 2–8 The background image of the startup screen and info screens can be changed with Projector Toolset with an installed UDM plug-in. 2.3 Start image projection Connect the source Connect the source cable with the appropriate input port on the Input & Communication module. Tip: See chapter “Input &...
  • Page 28 Getting Started Image 2–11 The Source selection menu opens on the LCD display. Image 2–12 Example of the input selection menu Use the arrow keys to select the desired source. • the SEL LED (reference 2) of the selected source lit up GREEN, and •...

  • Page 29: Switching To Standby

    Getting Started Image 2–14 The Test pattern menu opens on the LCD display. Use the arrow keys to select the desired test pattern. 2.4 Switching to standby How to switch to standby Press and hold the Power on/off button for 3 seconds on the local keypad, or press the Power Off button on the remote control.
  • Page 30 Getting Started Image 2–16 Mains switch Unplug the power cord from the projector. R5911443 /03...

  • Page 31: Pulse Remote Control Unit

    Pulse Remote Control Unit Remote control, battery installation ....................32 Remote control, protocol setup ......................33 Remote control, on/off button......................33 Using the RCU ..........................34 Functionality overview........................35 Functions of the “button pressed indicator” ..................35 Function of the RGB filter button ....................35 Displaying and Programming addresses into the RCU..............36 Using the XLR connector of the RCU .....................36 3.10 Using the mini-jack connector of the RCU..................37 3.11 Silicone protection sleeve for the RCU (optional)................37...

  • Page 32: Remote Control, Battery Installation

    Pulse Remote Control Unit 3.1 Remote control, battery installation Where to find the batteries for the remote control ? The batteries are not placed in the remote control unit to avoid control operation in its package, resulting in a shorter battery life time. At delivery the batteries can be found in a separated bag attached to the remote control unit.

  • Page 33: Remote Control, Protocol Setup

    Depending on the projector to control the remote control can be switched between these protocols. Which protocol to use • The NEC protocol has to be used for Barco projectors based on the Pulse platform: F70, F80, F90, HDX 4K, UDX, UDM, XDL, etc. •...

  • Page 34: Using The Rcu

    Using the RCU in combination with a 3D emitter When using a 3D emitter that radiates IR beams (e. g. the optional 3D emitter that Barco provides), the IR beams of the 3D emitter may interfere with the IR communication between projector and the RCU.

  • Page 35: Functionality Overview

    Pulse Remote Control Unit 3.5 Functionality overview Remote Control Unit buttons Image 3–7 Button pressed indicator Backspace (while entering values) Shutter open XLR connector Shutter close Decimal mark (while entering values) LCD panel on / off Macro button Project OSD on / off Menu back Lens zoom Default value button...

  • Page 36: Displaying And Programming Addresses Into The Rcu

    Pulse Remote Control Unit having one projector project a red image and another project a green image, it is easier to spot and adjust the overlap section. By pressing this button multiple times, you will have different active filters, in the following cycle: •...

  • Page 37: Using The Mini-Jack Connector Of The Rcu

    (optional) Introduction Barco offers a silicone form fitting protection sleeve for the Pulse RCU. The silicone material keeps it comfortably, non slip and soft touch. All buttons and holes remain accessible. The sleeve is quick and easy installed. For ordering information see Barco website.
  • Page 38 Pulse Remote Control Unit Image 3–10 Place back side (XLR side) of the RCU into the sleeve and pull the other side of the sleeve over the front side of the RCU. Image 3–11 R5911443 /03...

  • Page 39: Input & Communication

    Input & Communication Introduction ..........................40 Local Keypad and LCD panel ......................40 LCD touch panel...........................41 Communication connections......................42 LED and Button indication chart.....................44 Pulse Quad Combo input Mk II ......................45 Pulse Quad Combo input Mk I .......................46 Pulse Quad DP 1.2 input .......................47 Pulse SFP input..........................48 R5911443 /03...

  • Page 40: Introduction

    Input & Communication 4.1 Introduction General The Input & Communication module consists of a local keypad with LCD panel (1), a communication panel (4) and a Quad Combo input board (5). The free input slot can be used for optional modules (e.g. the Quad DP 1.2 input board).

  • Page 41: Lcd Touch Panel

    Input & Communication Local Keypad The Keypad gives direct access to several functions, in addition to access to the menu system. The keypad has a backlight that can be switched on and off manually. By default the light turns off after 5 minutes.

  • Page 42: Communication Connections

    Input & Communication Image 4–4 4.4 Communication connections Communication Panel Image 4–5 WIFI antenna for wireless IP (optional) RS232 for serial communication 12V 1A output Sync Out 3D Firmware update / USB download log files Sync In 3D 10/100 base-T for external control over IP and Art-Net Status lights DMX interface input IR receive sensor...
  • Page 43 Input & Communication Description Return - (or not used) Return + (or not used) DMX-512 Lighting protocol over RS-485 interface. Carries information of 512 channels from a lighting controller to lighting devices. Standardized by USITT. RS232/RS422 input The communication interface of the UDM series projector supports RS232 and RS422 serial communication on two different types of input connectors, a Sub-D connector and an USB connector acting as RS input when connected to an USB input of a PC.

  • Page 44: Led And Button Indication Chart

    Input & Communication USB port The communication interface is equipped with a master USB port, type “A” connector. This USB port will simplify the service procedures for firmware updates or for downloading the log files without a network connection. If the only file on the USB device is the firmware file (a “*.fw” file), the projector will automatically start one of the following processes.

  • Page 45: Pulse Quad Combo Input Mk Ii

    Input & Communication Description Color status RED toggles on/off Error ORANGE toggles on/off Warning IR signal received GREEN IR signal acknowledged 4.6 Pulse Quad Combo input Mk II Overview Quad Combo Input Mk II SDI IN SDI IN/OUT 3G/12G SYNC SYNC SYNC SYNC...

  • Page 46: Pulse Quad Combo Input Mk I

    Input & Communication HD, 3G & 12G IN 0 OUT 0 IN 1 OUT 1 N.C. HD & 3G IN 0 OUT 0 N.C. IN 1 OUT 1 FPGA IN: HD & 3G SDI IN/OUT OUT 0 OUT: HD, 3G & 12G N.C.

  • Page 47: Pulse Quad Dp 1.2 Input

    Input & Communication Remark concerning the Mk I and Mk II inputs boards The Mk I input board miss functionality that has been implemented on the Mk II input board. These missing features include: • Loop-through functionality • 12G SDI support •...

  • Page 48: Pulse Sfp Input

    Input & Communication 4.9 Pulse SFP input The Barco SFP Input Board has been designed and tested to work alongside the Barco SFP Output Board. However, it is possible that the SFP Input board can also work with other third-party devices that support 12G over fiber.

  • Page 49: Gui - Introduction

    GUI – Introduction Overview .............................50 Navigation............................51 Test Patterns ..........................53 About this chapter This chapter gives an general overview of the Graphic User Interface. R5911443 /03...

  • Page 50: Overview

    GUI – Introduction 5.1 Overview Disclaimer on GUI images used in this manual The GUI images in this manual are example illustrations and should be treated as such. While the name of the projector displayed in the illustrations may be different from the projector model you are currently using, the menu lay-out and functionality is identical.

  • Page 51: Navigation

    GUI – Introduction Image 5–2 Example of a Dashboard status screen GUI – Main Menu overview The projector on-screen display (OSD) is the primary user interface (UI). From here, you can review and adjust all projector and display settings. The OSD interface uses buttons to display the main menu. Each main menu contains submenus. The OSD can be disabled by pressing the OSD on/off button.
  • Page 52 GUI – Introduction Image 5–4 To start up the menu structure, press MENU (1). Use the arrow keys (Menu Navigation buttons) to navigate to the desired menu item (2). The background color changes to light blue. Press the Menu Selection button (center key of the arrow keys), also called OK button, to activate that item and to jump one level deeper (3).

  • Page 53: Test Patterns

    GUI – Introduction To enter values with the local keyboard, use the arrow keys to select the first digit, press OK. Select the second digit and press OK. Continue until all digits are entered. Close the action by selecting the enter (↵) button and press OK.
  • Page 54 GUI – Introduction Image 5–7 Test patterns menu, test pattern off R5911443 /03...

  • Page 55: Gui - Source

    GUI – Source Displaying a single source ......................56 Displaying multiple sources: Stitched layouts ..................56 Connector Settings ........................58 About the Source menu This menu is used to select, review and configure sources into the projector. R5911443 /03...

  • Page 56: Displaying A Single Source

    GUI – Source 6.1 Displaying a single source About selecting a source Before a source can be projected, the source signal must be connected to the source input(s) of the device and a valid synchronization signal must be available along with the source signal on at least one of the input connectors.
  • Page 57 GUI – Source The table below describes the different Stitch Layouts and scan directions. Type of layout Description Available connectors Mode A single source is displayed in Quad Combo input: Mono / Active full screen stereo • SDI (4x) • HDBaseT (2x) •...

  • Page 58: Connector Settings

    GUI – Source Image 6–4 Example of the stitched layout options Select the desired stitched input. Tip: If the Quad DP input board is installed, scroll all the way down the menu for the stitched options on that board. Image 6–5 Example of the stitched input options with the Quad DP board installed 6.3 Connector Settings About Connector Settings The Connector Settings menu allows you to change settings for each input connector of the projector.
  • Page 59 GUI – Source Image 6–6 Main menu, Source Press OK. The Select Source menu is displayed with the actual available sources filled out. Scroll down to the bottom of the list of available sources and select Connector Settings. Image 6–7 Source menu, connector settings The available input connectors are displayed.
  • Page 60 GUI – Source Image 6–9 Example of connector settings for an HDMI connector You can change the following: • To force a limit on the used signal range, select one of the available signal ranges. • To force a limit on the color space, select one of the available color spaces. •...

  • Page 61: Gui - Image

    GUI – Image Setting image levels manually......................62 Adjusting the sharpness ........................63 Adjusting the gamma correction.....................64 Setting the desired Gamma type ....................65 Digital Shift & Zoom ........................67 RealColor P7..........................70 Setting the output resolution ......................72 Displaying HDR content ........................73 R5911443 /03...

  • Page 62: Setting Image Levels Manually

    GUI – Image 7.1 Setting image levels manually Purpose Contrast: Change the contrast of the complete output signal (main and PiP window together) of the projected image. Brightness: Change the brightness of the complete output signal (main and PiP window together) of the projected image.

  • Page 63: Adjusting The Sharpness

    GUI – Image Image 7–4 Example of the image sliders, brightness is the second slider If necessary, use the ▲ or ▼ key to select the other image adjustment options. How to set up Saturation Level In the main menu, select Image → Saturation. Image 7–5 Image menu —...

  • Page 64: Adjusting The Gamma Correction

    GUI – Image Increasing the sharpness will have the best effect in high contrast images, eg a table with text and borders. In a natural picture, high sharpness can be perceived as noise, as all details in the picture will be amplified. Available range: -2 to 8.

  • Page 65: Setting The Desired Gamma Type

    GUI – Image Image 7–10 Image menu – Gamma Use the ▼ key to select the slider. Use the ◄ or ► key to change the gamma value between 1.0 and 2.8 . The default value is 2,2. Tip: The slider can be adjusted with a precision of 0.1. Image 7–11 Example of the gamma menu 7.4 Setting the desired Gamma type About the alternate gamma types...
  • Page 66 GUI – Image Exception when using an HDR source The only alternate color gamma that can not be selected in this menu is PQ/HDR. Because the color output of HDR is dependant on extra factors such as screen luminance, a separate menu has been made available for this (PQ).

  • Page 67: Digital Shift & Zoom

    GUI – Image Tip: If not sure what gamma type to select, keep the default value auto selected. This automatic mode will determine the used gamma type based on the incoming signal. However: keep in mind when using the automatic mode, your media player needs to be configured correctly as well.
  • Page 68 GUI – Image Image 7–16 Picture digitally zoomed in Image 7–17 Picture digitally zoomed out The effect of Digital Shift This function will shift the picture digitally, meaning that the picture will be moved in any direction. As a result, some parts of the picture might be shifted outside the DMD range.
  • Page 69 GUI – Image Image 7–21 Image menu, digital zoom and shift The Digital Zoom Shift menu is displayed. Image 7–22 Example of the digital zoom and shift menu In order to optimize the digital zoom, enable the Zoom slider. In order to optimize the digital shift, enable the Shift slider.

  • Page 70: Realcolor P7

    GUI – Image Image 7–24 Example of the enabled digital zoom mode If digital shift is enabled, you can now do the following: • Use the ◄ or ► key to shift the lens (image) in horizontal direction. • Use the ▲ or ▼ key to shift the lens (image) in vertical direction. •...
  • Page 71 GUI – Image Image 7–26 Example of the RealColor P7 menu, here on a UDX Select the desired Custom Mode. Select one of the following Custom options and confirm: • Custom RGB: 3–point color configuration. In RGB mode, the C, M and Y coordinates will be calculated automatically based on the R, G and B coordinates.

  • Page 72: Setting The Output Resolution

    GUI – Image Image 7–28 Example of the RealColor P7 menu, here on a UDX Select one of the pre-defined presets: • Standard: A color standard for all UDX projectors, which may be considered the new native settings for all UDX projectors. Default for UDX. •...

  • Page 73: Displaying Hdr Content

    GUI – Image How to determine the desired output resolution for my content While the native output resolution of this projector is 4K in Ultra-High Definition (4K-UHD), sometimes it can be better to choose an alternate resolution, depending on the main purpose of the projected content: •...
  • Page 74 GUI – Image When do I know my content is HDR encoded? If the source signal is HDR encoded, an HDR icon will be visible next to the source signal. This is visible both in the Source selection menu, as well as the status menu. Image 7–32 Example of the HDR icon on the status menu How to properly display HDR content? If your provided HDR content has been mastered with PQ (e.g.
  • Page 75 GUI – Image Image 7–34 Example of the HDR menu Select the desired Screen luminance unit (nits or foot-Lambert). Enter the Screen luminance (which is measured in nits or foot-Lambert). Alter the HDR boost if necessary. You can modify this value to somewhere between 0.8 and 1.2. R5911443 /03...
  • Page 76 GUI – Image R5911443 /03...

  • Page 77: Gui - Installation

    GUI – Installation Configuring the lens, optical zoom-focus ..................78 Configuring the lens, shift ......................78 Configuring the lens, dynamic focus ....................79 Configuring the lens, Shift to center....................80 Laser ranging ..........................81 Manipulating the rigging frame ......................82 Manipulating the rigging frame, center position ................84 Orientation ...........................84 Scaling modes..........................85 8.10 Warping ............................86...

  • Page 78: Configuring The Lens, Optical Zoom-Focus

    GUI – Installation 8.1 Configuring the lens, optical zoom-focus What can be done? If a motorized lens has been mounted onto the projector, you can fine-tune the projected image. Zoom - Focus In the main menu, select Installation → Lens → Zoom focus. Image 8–1 Lens menu, Zoom &...

  • Page 79: Configuring The Lens, Dynamic Focus

    GUI – Installation Image 8–3 Lens menu, lens shift The Lens shift menu is displayed. Image 8–4 Example of the lens shift menu Use the ◄ and ► keys to shift the lens (image) in horizontal direction. Use the ▲ and ▼ keys to shift the lens (image) in vertical direction. 8.3 Configuring the lens, dynamic focus About focus drift and dynamic focus Due to the design of ultra-short throw lenses (UST lenses), this type of lens tends to heat up over time when...

  • Page 80: Configuring The Lens, Shift To Center

    GUI – Installation Image 8–5 Example of the Lens menu In the Lens menu, click Dynamic focus to toggle between On and Off. Image 8–6 Lens menu, Image 8–7 Lens menu, Dynamic focus enabled Dynamic focus disabled Note: The Dynamic focus slider is only visible when the light source is on. 8.4 Configuring the lens, Shift to center What can be done? The lens can be forced back to the center position by selecting Shift to center.

  • Page 81: Laser Ranging

    GUI – Installation 8.5 Laser ranging What can be done? When the optional laser range finder is installed on the projector, you can use the laser source to measure the distance between the front of the projector and the surface you are projecting on. This can help you fine-tune the position of the projector.

  • Page 82: Manipulating The Rigging Frame

    GUI – Installation Image 8–11 Example of projected image during laser ranging session with measurement on screen By default the measurement is in meters. If you want the distance projected in feet, you can change the measurement system in the System settings menu. For more info, refer to “Setting the measurement system”, page 134.
  • Page 83 GUI – Installation Image 8–13 Example of the Motorized frame menu Press the OK key or button to activate the frame shift motors. Image 8–14 Example of horizontal and vertical frame shift Use the ▲ or ▼ button to shift the rigging frame (image) in vertical direction. Use the ◄...

  • Page 84: Manipulating The Rigging Frame, Center Position

    GUI – Installation Confirm with the OK button to return to the frame shift menu, or use the Menu back button to return to the Lens menu. 8.7 Manipulating the rigging frame, center position What can be done? The motorized frame can be forced back to the center position by selecting Center motorized frame. How to reset the motorized frame? In the main menu, select Installation →...

  • Page 85: Scaling Modes

    GUI – Installation How to set the correct orientation In the main menu, select Installation → Orientation. Image 8–18 Installation menu, orientation The Orientation menu is displayed. Image 8–19 Example of the orientation menu Use the ◄ or ► keys to select the projector orientation mode and press OK to activate. 8.9 Scaling modes About scaling modes While the default mode of projection is to fill the screen while respecting the aspect ratio (fill aspect), it is also...

  • Page 86: Warping

    GUI – Installation Scaling Mode Explanation Example image Fill screen Fills the screen to the screen size defined in the Screen Size menu, while respecting the original aspect ratio. For more info on adjusting the Screen Size menu, see “Warping – Screen Size”, page 87. Stretch This mode stretches the image to the screen size defined in the Screen Size menu, while ignoring the...

  • Page 87: Warping - On/Off

    GUI – Installation 8.10.1 Warping – On/Off About warping on/off By toggling between on and off the warping functionality can be enabled or disabled. How to toggle In the main menu, select Installation → Warp. Image 8–22 Installation menu, warp The Warp menu is displayed.
  • Page 88 GUI – Installation Image 8–26 Warp outline example How to adjust the image? In the main menu, select Installation → Warp → Screen Size. Image 8–27 Warp menu, screen size The Screen Size menu is displayed. Image 8–28 Example of the screen size menu Select either Screen width or Screen height.

  • Page 89: Warping - 4 Corners Adjustment

    GUI – Installation Tip: A red border will be projected along with the current image. The border is a visual tool, showing the result of the adjusted outline. Image 8–29 Tip: The value can also be entered by the numeric keys on the remote control. Press * to delete existing numbers, and enter the new value by the numeric keys.
  • Page 90 GUI – Installation The 4 corners menu is displayed. Image 8–32 Example of the 4 corners menu To enable 4 Corners warping, enable the 4 corners slider. To have a visual representation of what your warp will look like, enable the Helper lines slider. Image 8–33 Example of 4 corners warping menu, with helper lines active on the edges of the screen To set warping on one of the four corners, select one of the four corners and confirm.

  • Page 91: Warping - Bow

    GUI – Installation Image 8–34 Example of the 4 corners menu, with 4 corner warping and helper lines enabled Repeat from go to step 4 for each corner, until all corners are warped in the desired position. To reset the 4 corner adjustments, select Reset and press the OK button. 8.10.4 Warping –...
  • Page 92 GUI – Installation Definition of angle and linearity (length) in the bow warp procedure Image 8–36 Symmetric bow correction In the main menu, select Installation → Warp → Bow. Image 8–37 Warp menu, Bow The bow menu is displayed. To enable bow correction, make sure the Bow slider is enabled (visible by the blue highlight). To perform a symmetric adjustment , make sure the Symmetric slider is set to On (visible by the blue highlight).
  • Page 93 GUI – Installation Image 8–39 The upper line is colored blue, the other sides are colored white Use the arrow keys to select the side of the picture that needs a correction and confirm. Image 8–40 Symmetric bow correction Use the arrow keys to adjust the angle and linearity (length) of the vectors. Press enter to confirm and switch between angle and length.
  • Page 94 GUI – Installation Asymmetric bow correction In the Bow menu, enable the Bow slider and disable the symmetric slider. Image 8–42 Example of the bow menu, with the Symmetric slider disabled There are now two vectors on each side of the picture that can be adjusted individually. Use the arrow keys to select the helping lines that represent the picture and confirm.

  • Page 95: Warping - Warp Files

    GUI – Installation Adjust angle and linearity (length) individually to obtain the correct correction. Press enter to confirm and to switch between angle and length. Tip: Adjust the angle by using the up and down arrow keys. Adjust the linearity by using the left and right arrow keys.
  • Page 96 GUI – Installation Image 8–46 Installation menu, Warp In the Warp menu, select Warp files. Image 8–47 Warp menu, Warp files The Warp Files menu is displayed. Image 8–48 Example of the Warp files menu Make sure the Enable slider is set to right. Select the desired warp file.

  • Page 97: Warping - Latency Control In A Multi Projector Setup

    GUI – Installation 8.10.6 Warping – Latency control in a multi projector setup Transport latency The added delay in the image processing chain. The value is the number of lines relative to the output resolution. Latency The total time from the first pixel is coming in on an input source, until the first light representing that pixel is visible on the screen.

  • Page 98: Blending & Masking

    GUI – Installation Image 8–52 Warp menu, Transport delay The Transport menu is displayed. Image 8–53 Example of the Transport delay menu Enter the value either by the arrow keys (one step at a time) or directly by the numeric keys on the remote control.

  • Page 99: Basic Blend

    GUI – Installation From the start (mask) position, you can blend zone size per edge (left, top, right, bottom). For each edge there will be a drop-off curve for the blend zone. 8.11.1 Basic blend How to set up a basic blend zone? In the main menu, select Installation →...

  • Page 100: Blend & Blend Mask

    GUI – Installation Image 8–57 Start position (mask) Blending width Select one of the four starting positions values with the arrow keys and confirm. Use the arrow keys or remote digits to change the value of the blend zone and confirm. Repeat this process for all other desired sides.
  • Page 101 GUI – Installation Image 8–58 Blend menu, Blend mask The Blend mask menu is displayed. Image 8–59 Example of the blend mask menu To enable the blend mask, put the Enable slider to the right. The color of the slider becomes blue when enabled.
  • Page 102 GUI – Installation Image 8–60 Start position (mask) Blending width Select one of the four starting positions values with the arrow keys and confirm. Use the arrow keys or remote digits to change the value of the mask and confirm. Repeat this process for all other desired sides.

  • Page 103: Blend Files

    GUI – Installation Image 8–61 Set up for projector 1 Image 8–62 Set up for projector 2 8.11.3 Blend Files About custom Blend Files Next to setting your specific Blending configuration in the GUI, you can also upload or download a custom Blend configuration file in png, jpg or tiff format to/from the projector.

  • Page 104: Basic Black Level Adjustment

    GUI – Installation Image 8–63 Blend and mask menu, Blend files The Blend Files menu is displayed. Image 8–64 Example of the blend files menu If any custom Blend files are available, select the desired file. Image 8–65 To enable the selected blend file, make sure the Enable slider is set to the right. The color of the slider becomes blue when enabled.
  • Page 105 GUI – Installation You can also specify the offsets manually by turning off the automatic calculation. The black level value is adjusted in a 16–bit resolution from 0 to 65535. The following figure shows how this occurs in a side by side configuration without any correction of the black level.

  • Page 106: Rgb Gain Adjustment

    GUI – Installation Move the cursor to Level, press enter and adjust this level until the black level equals the level in the blend zone. This value can also be entered by the numeric keys on the remote control. Repeat the same procedure for any other projector connected to this projector, but on the opposite side. Note: Do not forget to disable the Show lines button after you achieved the desired blend zone.

  • Page 107: Black Level Files

    GUI – Installation Image 8–71 Example of the default black level menu Select one of the three sliders on the bottom of the menu (Red, Green or Blue). Use the left and right arrow keys to modify the gain of the chosen color. Repeat for every slider until the desired result is achieved on screen.

  • Page 108: Illumination

    GUI – Installation Image 8–73 Example of the black level files menu If any custom Black Level adjustment files are available, select the desired file. Image 8–74 Example of custom black level files selected Make sure the Enable slider is set to the right to activate the selected black level file 8.12 Illumination What can be done? Within a certain percentage, the light output of the light source can be reduced by reducing the power slider.

  • Page 109: Projection

    GUI – Installation How to reduce the power In the main menu, select Installation → Illumination. Image 8–75 Installation menu, illumination The Illumination menu is displayed. Image 8–76 Example of the Illumination menu Use the Slider to change the power value. Enable the Constant light output slider if you want to enable CLO mode.

  • Page 110: Setup Process 3D Projection

    GUI – Installation The viewer wears glasses which contain a pair of opposite polarizing filters. As each filter only passes light which is similarly polarized and blocks the opposite polarized light, each eye only sees one of the images, and the effect is achieved.

  • Page 111: Setup

    Why change the 3D setup? While Barco can provide a 3D emitter and active shutter glasses as options to this projector, you are also free to use a 3D emitter and active shutter glasses of your own choice. Since glasses and emitter can have various specifications compared to the ones Barco can provide, the 3D setup menu allows you to configure the output image to the specifications of your glasses and emitter.
  • Page 112 GUI – Installation If a 3D emitter is used that radiates infrared beams (IR beams), the IR beams may interfere with the IR communication between projector and the RCU. If such interference occurs, connect the RCU to the projector using the remote cable. It is also advised to turn the IR receivers on the projector off to avoid the 3D emitter interference.

  • Page 113: Gui - Profiles

    GUI – Profiles Profiles introduction ........................114 Profiles setup parameters......................114 Create new profile ........................115 R5911443 /03...

  • Page 114: Profiles Introduction

    GUI – Profiles 9.1 Profiles introduction About Profiles The Profile function make it possible to store different profiles / projector setups for different use cases, and quickly recall them when needed. This means that there is not necessary to enter a lot of different menus to adjust the projector setup for different user cases.

  • Page 115: Create New Profile

    GUI – Profiles Settings Area of interest • Motorized Frame parameters, if connected Rotate Tilt Skew • Shutter position • Image orientation • Scaling mode Warp settings Note: Only file-based warp supported via profiles • Warp enabled status • Selected warp file •...
  • Page 116 GUI – Profiles Image 9–2 Select the Edit button Image 9–3 The Profile edit menu shows up. Image 9–4 Select New profile R5911443 /03...
  • Page 117 GUI – Profiles Image 9–5 Enter a suitable name for this profile via the pop up keyboard (arrow keys and OK (✓) to select). End the name entry by selecting the “return” key on the pop up keyboard. Select the “Assign to preset slot”. A drop down menu will show up, select the preferred value. Note: The function “Assign to preset slot”...
  • Page 118 GUI – Profiles Image 9–7 Select the numeric shortcut from the remote control. Edit a profile Enter the Menu/Profiles/Edit Select the profile to be edited. Set, or change the “Assign to preset slot” number, or delete the actual profile. It is not possible to add or remove selected features in an stored profile.

  • Page 119: Gui - System Settings

    GUI – System Settings 10.1 Communication, LAN setup ......................120 10.2 IR control ........................... 126 10.3 Setting a custom projector name....................129 10.4 DMX ............................129 10.5 Front XLR output voltage control....................131 10.6 GSM configuration........................132 10.7 Changing the User Interface language ..................133 10.8 Themes .............................

  • Page 120: Communication, Lan Setup

    GUI – System Settings 10.1 Communication, LAN setup About a network connection A network connection can be made via a wired connection or via the optional wireless unit. 10.1.1 Introduction to a Network connection DHCP Dynamic host configuration protocol. DHCP is a communications protocol that lets network administrators manage centrally and automate the assignment of IP addresses in an organization's network.
  • Page 121 GUI – System Settings Image 10–1 Communication menu, LAN The LAN menu is displayed. Image 10–2 Example of the LAN menu To enable Automatic, make sure the Automatic slider is set to the right. The color of the slider will be blue. An IP address will be automatically assigned if it can make a connection to the network..

  • Page 122: Wireless Ip Address Set Up

    GUI – System Settings Image 10–4 Example of the LAN menu Disable the Automatic slider. The slider becomes gray. Use the arrow keys to select Address and press OK button to activate the input box. Image 10–5 Example of entering the IP address Use the arrow keys and enter key to enter in the IP address.
  • Page 123 GUI – System Settings Image 10–6 Communication menu, WiFi The WiFi menu is displayed. Image 10–7 Example of the WiFi menu Make sure the Enable slider is set to the right to enable the WiFi module. The color of the slider becomes blue.
  • Page 124 GUI – System Settings Tip: If the desired wireless network is not in the list or hidden by default, select Other network. A form will pop up, allowing you to fill in the details of the network. Image 10–9 Example of the entry form to search for other wireless networks If required by the chosen wireless network fill in the user name, password and confirm.
  • Page 125 GUI – System Settings Image 10–11 Example of the WiFi menu Make sure the Enable slider is set to the right to enable the WiFi module. The color of the slider becomes blue. Disable the Automatic slider by setting it to the left. The switch becomes gray. Image 10–12 Use the arrow keys to select Address and press OK button to activate the input box.

  • Page 126: Ir Control

    GUI – System Settings Image 10–13 Example of the available networks list. Press Connect to connect to the selected network. If required by the chosen wireless network, fill in the username and password and confirm. When connected to this network, it is indicated in the upper right corner of the menu with the term “connected”.

  • Page 127: Projector Address

    The following choices are possible: • Generic IR (address 0) • Barco broadcast IR (address 1) Select APPLY and click OK to apply the changes. 10.2.2 Projector address About individual projector address As more than one projector can be installed in a room, each projector should be separately addressable with an RCU or with a computer using serial communication.

  • Page 128: Ir Sensors

    GUI – System Settings Image 10–17 Example of the IR control menu Select the current projector address and enter a new address. Select APPLY and click OK to apply the changes. From now on the projector will only listen to this new address and to its broadcast address. 10.2.3 IR sensors What can be done? Each IR sensor can be individually disabled or enabled.

  • Page 129: Setting A Custom Projector Name

    GUI – System Settings To disable an IR sensor, select the slider and drag to the left. A blue slider means an active IR sensor. A gray slider means an inactive IR sensor. Select APPLY and click OK to apply the changes. 10.3 Setting a custom projector name What can be done? The default name of the projector is “Pulse”.
  • Page 130 GUI – System Settings If you are using a DMX console and other automated lighting products compatible with Art-Net, the Ethernet network can serve as the link for DMX control. All DMX controls can be sent over the Ethernet cable. Multiple universes are possible.

  • Page 131: Front Xlr Output Voltage Control

    GUI – System Settings Image 10–23 Example of the DMX menu Choose the desired DMX mode. Choose the desired starting channel. Choose whether or not you want the Auto power-down feature to be enabled. If enabled, determine the time-out. If required, enable Art-Net. If enabled, determine the desired Art-Net Universe and Art-Net channel. If a front XLR connector is available on your projector, you can enable the output voltage on this connector.

  • Page 132: Gsm Configuration

    GUI – System Settings Image 10–25 Example of the DMX menu On the bottom of the DMX menu, Enable the XLR connector slider. Select the desired Output Voltage. 10.6 GSM configuration Only possible when a GSM module with SIM card is installed in the projector. What can be done ? To configure the projector software with the installed SIM card, a correct PIN code (4digits) must be entered.

  • Page 133: Changing The User Interface Language

    GUI – System Settings Image 10–27 Example of the GSM menu once the pin code has been applied 10.7 Changing the User Interface language How to change the language of the user interface In the main menu, select Settings → User interface → Language. Image 10–28 Interface The Language menu is displayed.

  • Page 134: Themes

    GUI – System Settings • Chinese (ZH) 10.8 Themes About Themes Themes are used to apply a predefined functionality to the OSD display. There are two options: light or dark (default). While the default theme is dark, all images in this manual are taken while using the light theme. How to select a different interface theme In the main menu, select Settings →...

  • Page 135: Controlling The Backlight Of The Lcd Display

    GUI – System Settings Image 10–32 Example of the Units menu Select the desired Temperature unit and Length unit and confirm. 10.10 Controlling the backlight of the LCD Display What lighting can be controlled? You can choose how quickly the backlight of the LCD turns off. You can select one of the default values, or enter a custom value.

  • Page 136: Lens Features

    GUI – System Settings Image 10–34 Example of the backlight menu Choose the desired setting for the backlights. Select one of the predetermined options, or a custom value. 10.11 Lens features What can be done? Some lens features can be disabled once they are correctly aligned so that a misalignment during a show is not possible.

  • Page 137: Factory Reset

    GUI – System Settings • Vertical lens shift • Zoom To enable/disable a feature, click on the slider and drag it to the left to disable the feature or the right to enable the feature. When enabled, the slider becomes blue; when disabled, the slider is gray. 10.12 Factory reset What can be done? All settings and values on the projector can be reset to its default values.
  • Page 138 GUI – System Settings Option Setting Factory setting Dark time lowest value available Test patterns Test Pattern Off, none selected Image uniformity Image Warp Screen size 5120x3200 / 2560x1600 4 corner Warp disabled, no warp Warp files Disabled, all warp files deleted Network Communication LAN, Automatic settings...

  • Page 139: Lens Calibration

    GUI – System Settings Image 10–38 Example of the reset menu In the Reset menu, select RESET ALL and confirm with OK. How to reset one or more projector settings In the main menu, select Settings → Maintenance → Reset. Image 10–39 Settings menu, factory reset The Reset menu is displayed.
  • Page 140 GUI – System Settings Image 10–41 Maintenance menu, lens calibration The Lens Calibration menu is displayed, alongside the status of each Image 10–42 Example of the lens calibration menu In the Lens Calibration menu, select the desired calibration action and click OK. You can select one of the following functions, depending on the type of mounted lens: •...

  • Page 141: Flex Brightness

    GUI – System Settings 10.14 Flex brightness This feature is available by default on the following devices: UDM 4k22, UDM W22. This feature is also available as an option on the following devices: UDM 4K15, UDM W19, UDM W15. Overview With the FLEX technology the projector owners can lock the light output to different levels.

  • Page 142: Rigging Frame Calibration

    GUI – System Settings Image 10–44 Maintenance menu, Flex The Flex license menu is displayed. Image 10–45 Example of the Flex license menu Choose the desired Light output (in lumens) for which you have a code available. Enter the code via the OSD menu and confirm. Image 10–46 Example of entering the code in the Flex license menu 10.15 Rigging frame Calibration How to calibrate the motorized rigging frame...

  • Page 143: Electronic Convergence

    GUI – System Settings Image 10–47 Maintenance menu, Frame calibration The Frame calibration menu is displayed. Image 10–48 Example of the Frame calibration menu In the Frame Calibration menu, select the desired calibration action and click OK. You can select one of the following functions: •...
  • Page 144 GUI – System Settings Image 10–50 Maintenance menu, electronic convergence The Electronic Convergence menu is displayed. Image 10–51 Example of the electronic convergence menu Select the desired X or Y value for one of the three colors and confirm. Use the arrow keys to raise or lower the value and confirm. Confirm all changes by pressing Enter.

  • Page 145: List Of Open Source Licenses

    GUI – System Settings 10.17 List of open source licenses About open source licenses Open source licenses are licenses that comply with the Open Source Definition. In brief, they allow software to be freely used, modified, and shared. To be open and transparent about the open source software used on the projector, there is a list of all open source licenses available in the software.

  • Page 146: Advanced Settings - Color

    GUI – System Settings 10.18.1 Advanced Settings – Color CAUTION: The native colors have been measured and set during factory production. Do not change them, unless parts of the optical path have been replaced due to servicing. If you need to change the native colors on the device, make sure to also perform a P7 calibration, using the Projector Toolset and a chroma meter.

  • Page 147: Advanced Settings - Statistics

    GUI – System Settings 10.18.2 Advanced Settings – Statistics What can be seen? The statistics screen shows the general information about the projector, spread over two tab pages. The following items will be displayed: • Laser runtime • Laser Strikes •...
  • Page 148 GUI – System Settings If one or more laser banks have failed of a certain type, you will notice a decreased light input and decrease in color performance. But the projector will keep on playing, unless too many banks of a certain color will have failed.
  • Page 149 GUI – System Settings Image 10–64 Example of the laser bank group menu If you want notifications to be disabled for a specific group of laser banks, disable the Enable notifications for this group slider. R5911443 /03...
  • Page 150 GUI – System Settings R5911443 /03...

  • Page 151: Gui - Status Menu

    GUI – Status menu 11.1 Status menu overview......................... 152 No settings can be modified in the status menu. Its only for consulting. R5911443 /03...

  • Page 152: Status Menu Overview

    GUI – Status menu 11.1 Status menu overview How to access the status menu While in the main menu, press Status. Image 11–1 Main menu, status The status menu is displayed. Image 11–2 Example of a status menu Swipe the screen to switch between the Status and About page. Image 11–3 Example of the About page in the Status menu What can be seen on the Status page? •...
  • Page 153 GUI – Status menu What can be seen on the About page? • Projector information, e.g. firmware version, serial number and projector article number • Mounted lens: Type and description • Basic statistics, e.g. light source run time, projector runtime R5911443 /03...
  • Page 154 GUI – Status menu R5911443 /03...

  • Page 155: Product Maintenance

    Product maintenance 12.1 Software update ......................... 156 12.2 Cleaning the lens........................157 12.3 Cleaning the exterior of the projector .................... 158 About this chapter This chapter contains general maintenance procedures. R5911443 /03...

  • Page 156: Software Update

    Download the latest firmware (format .fw) from Barco's website in the same way as for Projector Toolset. Start Projector Toolset and make a connection with the projector. For more information, see the “Projector Toolset”...

  • Page 157: Cleaning The Lens

    Always contact Barco if you want to make sure a downgrade will not hurt your device.

  • Page 158: Cleaning The Exterior Of The Projector

    Product maintenance Warning: Do not wipe back and forwards across the lens surface as this tends to grind dirt into the coating. Use a dry lens cleaning cloth to remove left liquid or stripes. Polish with small circles. If there are still fingerprints on the surface, wipe them off with lens cleaner together with a clean lens cleaning cloth.

  • Page 159: A Specifications

    Specifications Specifications for UDM 4K22 ....................... 160 Specifications for UDM 4K15 ....................... 161 Specifications for UDM W22 ......................163 Specifications for UDM W15 ......................165 Specifications SDI inputs......................166 Specifications HDMI inputs......................167 Specifications HDBaseT inputs ....................168 Specifications DisplayPort 1.2 inputs.................... 169 Specifications SFP inputs......................

  • Page 160: Specifications For Udm 4K22

    Specifications A.1 Specifications for UDM 4K22 Specifications Projector type 4K UHD 3-chip DLP digital projector Technology 0.9" DMDTM x3 Resolution 3,840 x 2,400 (4K UHD) / 2,560 x 1,600 (native) / 5,120 x 3,200 (processing) Brightness 20,000 (4K UHD) center lumens / 19,000 (4K UHD) ansi lumens* 22,000 ISO lumens* Contrast ratio 2200:1...

  • Page 161: Specifications For Udm 4K15

    3 years *Note *Brightness levels +/- 10% ** Wifi and GSM options are not available in all countries. Check with your Barco representative for more info. ***at higher altitude light output might be dimmed A.2 Specifications for UDM 4K15 Specifications...
  • Page 162 Specifications ScenergiX Horizontal and vertical edge blending Lenses TLD+ 0,37; 0,65-0,85; 0,8-1,16; 1,25 -1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8- 4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1 Optical lens shift Vertical between -100% to +130%, depending on lens Horizontal up to +/- 40%, depending on lens Motorized zoom and focus (with lens memory on TLD lenses) Motorized lens shift (with position memory on all lenses) Color correction...

  • Page 163: Specifications For Udm W22

    3 years *Note *Brightness levels +/- 10% ** Wifi and GSM options are not available in all countries. Check with your Barco representative for more info. ***at higher altitude light output might be dimmed A.3 Specifications for UDM W22 Specifications...
  • Page 164 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years Notes *Brightness levels +/- 10% ** Wifi and GSM options are not available in all countries. Check with your Barco representative for more info. ***at higher altitude light output might be dimmed R5911443 /03...

  • Page 165: Specifications For Udm W15

    Specifications A.4 Specifications for UDM W15 Specifications Projector type WUXGA 3-chip DLP digital projector Technology 0.96" DMDTM x3 Resolution 1,920 x 1,200 Brightness 14,500 center lumens / 14,000 ansi lumens / 15,000 ISO lumens* Contrast ratio 2200:1 Brightness uniformity Aspect ratio 16:10 ScenergiX Horizontal and vertical edge blending...

  • Page 166: Specifications Sdi Inputs

    Notes *Brightness levels +/- 10% ** Wifi and GSM options are not available in all countries. Check with your Barco representative for more info. ***at higher altitude light output might be dimmed A.5 Specifications SDI inputs For readability, the video timings listed are summarized. For the full list of video timings, refer to the appendices.

  • Page 167: Specifications Hdmi Inputs

    Specifications Specification Value For future release • 3D support • Interlaced support • Segmented frame support Video timings Type Port type Format progressive HD-SDI Single link • Up to 1920 x 1080 @24 Hz Quad link • Up to 1920 x 1080 @25 Hz •...

  • Page 168: Specifications Hdbaset Inputs

    Specifications Specification Value Video timings • Up to 4096 x 2160 @24 Hz • Up to 4096 x 2160 @25 Hz • Up to 4096 x 2160 @30 Hz • Up to 2048 x 1080 @48 Hz • Up to 4096 x 2160 @50 Hz •...

  • Page 169: Specifications Displayport 1.2 Inputs

    Specifications CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated electromagnetic interference: radiated electromagnetic interference (e.g. from GSM or switching inductive or capacitive loads) within the limits of electromagnetic compatibility requirements of 3 V/ m can cause random flashes or temporary loss of the projected image.

  • Page 170: Specifications Sfp Inputs

    Specifications • 1920 x 1080 @120 Hz • 1920 x 1200 @120 Hz • 2048 x 1080 @120 Hz 4 column mode (4x1 • 960 x 2160 @120 Hz layout) • 960 x 2400 @120 Hz • 1024 x 2160 @60 Hz Active 3D Standard layout (1x1 •...
  • Page 171 Specifications • Up to 1280 x 720 @30 Hz • Up to 1280 x 720 @25 Hz 3G-SDI Single link 1920 x 1080 @50 Hz and @60 Hz 1920 x 1200 @50 Hz, @59.94 Hz and @60 Hz. 2048 x 1080 @50 Hz and @60 Hz 12G-SDI Single link 3840 x 2160 @50 Hz and @60 Hz...
  • Page 172 Specifications R5911443 /03...

  • Page 173: B Video Timing Tables

    Video timing tables Overview video timings ....................... 174 Overview video timings SDI Inputs ....................175 Overview video timings HDMI 2.0 inputs..................176 Overview video timings DisplayPort 1.2 inputs ................178 Overview video timings HDBaseT inputs ..................180 About this chapter This chapter contains the tables with video timings for video interfaces.

  • Page 174: Overview Video Timings

    B.1 Overview video timings List of compatible signals The following table specifies the video signals that the projector can project. Barco Events projectors supports the signal with “X” in the Compatible signals column. Note: Support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.

  • Page 175: Overview Video Timings Sdi Inputs

    Video timing tables Compatible signal 12G SDI Input on Mk Vertical II Input HDBaseT & refresh rate Resolution HDMI 2.0 3G SDI DisplayPort board & HDMI 1.4 (Hz) Inputs Inputs 1.2 Inputs Fiber Inputs Network Inputs 2048 x 1080 — —...

  • Page 176: Overview Video Timings Hdmi 2.0 Inputs

    Video timing tables Video timing Vertical refresh rate Type Port Type (active pixels x active (Hz) lines) 1280 x 720 HD-SDI Single Link & Quad Link 1920 x 1080 HD-SDI Single Link & Quad Link 1920 x 1080 HD-SDI Single Link & Quad Link 1920 x 1080 HD-SDI Single Link &...
  • Page 177 Video timing tables Video timing Vertical refresh rate (Hz) 3D support? (active pixels x active lines) 1280 x720 Frame packing Top – bottom 1280 x 720 Frame packing Top – bottom 1280 x 800 1280 x 960 1280 x1024 1400 x 1050 1600 x 1200 1920 x 1080 Frame packing...

  • Page 178: Overview Video Timings Displayport 1.2 Inputs

    Video timing tables B.4 Overview video timings DisplayPort 1.2 inputs Overview The following standard video formats are available for the projector. Note: support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates Video timing Available layout modes, Vertical refresh rate other than standard...
  • Page 179 Video timing tables Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 1920 x 1080 1920 x 1080 4 Quadrant mode (2 x 2 Active 3D layout) 1920 x 1200...

  • Page 180: Overview Video Timings Hdbaset Inputs

    Video timing tables Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 B.5 Overview video timings HDBaseT inputs Overview...
  • Page 181 Video timing tables Available layout modes, other Video timing Vertical refresh rate (Hz) than standard layout (1 x 1 (active pixels x active lines) layout) 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 2160 2 Column mode (2 x 1 layout)
  • Page 182 Video timing tables R5911443 /03...

  • Page 183: C Dmx Chart

    DMX chart DMX chart input board positioning ....................184 DMX chart, Basic........................184 DMX chart, Extended........................185 R5911443 /03...

  • Page 184: Dmx Chart Input Board Positioning

    DMX chart C.1 DMX chart input board positioning About the input boards 6 Input selection ranges are reserved in the DMX chart per input board location (named L1 and L2). With the current version of DMX support, it is important to take into account to keep the input boards in their original slots.

  • Page 185: Dmx Chart, Extended

    DMX chart Function Value Default Action 136 - 143 Select input 7: Quad DP board Input A (if held for 1 second) 144 - 151 Select input 8: Quad DP board Input B (if held for 1 second) 152 - 159 Select input 9: Quad DP board Input C (if held for 1 second) 160 - 167...
  • Page 186 DMX chart Function Value Default Actions 128 - 135 Select input 6: Quad SDI input (if held for 1 second) 136 - 143 Select input 7: Quad DP board Input A (if held for 1 second) 144 - 151 Select input 8: Quad DP board Input B (if held for 1 second) 152 - 159 Select input 9: Quad DP board Input C (if held for 1...
  • Page 187 DMX chart Function Value Default Actions 24 - 31 Calibrate lens (zoom, focus and shift) (if held for 5 seconds) 32 - 255 Reserved for future functionality R5911443 /03...
  • Page 188 DMX chart R5911443 /03...

  • Page 189: D Wifi & Gsm Compliance Information

    WiFi & GSM compliance information Compliance FCC ........................190 Compliance IC..........................190 About this chapter This chapter contains important compliance information related to the WiFi and GSM module. Regulatory information for US and Canada can be accessed in the OSD of the projector. In order access it, select System Settings →...

  • Page 190: Compliance Fcc

    WiFi & GSM compliance information D.1 Compliance FCC Federal Communication Commission Interference Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
  • Page 191 WiFi & GSM compliance information These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 192 WiFi & GSM compliance information R5911443 /03...

  • Page 193: E Environmental Information

    Environmental information Disposal information ........................194 Turkey RoHS compliance......................194 China RoHS compliance ......................194 Taiwan RoHS compliance......................196 Contact information........................197 Production address........................197 R5911443 /03...

  • Page 194: Disposal Information

    Electronic Products” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.
  • Page 195 Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products”...

  • Page 196: Taiwan Rohs Compliance

    Environmental information E.4 Taiwan RoHS compliance 限用物質含有情況標示聲明書 (Declaration of the Presence Condition of the Restricted Substances Marking) 設備名稱：　數位投影機，　型號（型式）：　UDM Equipment name: Projector, Type designation: UDM 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 Unit Lead Mercu- Cadmi- Hexava-...

  • Page 197: Contact Information

    Registered office address: President Kennedypark 35, 8500 Kortrijk, Belgium Contact address: Beneluxpark 21, 8500 Kortrijk, Belgium Importers contact information To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com. E.6 Production address...
  • Page 198 Environmental information R5911443 /03...

  • Page 199: Glossary

    Glossary Default Gateway A router that serves as an entry point into and exit point out of a network. For example, a local network (LAN) may need a gateway to connect it to a wide area network (WAN) or to the Internet. DHCP Dynamic host configuration protocol.
  • Page 200 Glossary RS232 An Electronic Industries Association (EIA) serial digital interface standard specifying the characteristics of the communication path between two devices using either D-SUB 9 pins or D-SUB 25 pins connectors. This standard is used for relatively short-range communications and does not specify balanced control lines. RS- 232 is a serial control standard with a set number of conductors, data rate, word length and type of connector to be used.

  • Page 201: Index

    Index Brightness 62 Numbers/Symbols 3D emitter setup 111 3D projection 109 CE Certification 20 3D setup 110 Clean Exterior 155 Filters 155 Lens 155 Cleaning Active 3D 109 Exterior 158 setup 111 Lens 157 Active Stereo 109 Communication 39 Address DMX 42 Program Introduction 40...
  • Page 202 Index Multiple sources 56 Navigation 51 Single source 56 Overview 50 DisplayPort 1.2 inputs Test Patterns 53 Specifications 169 DMX 129 DMX chart 183 Basic 184 Hazard Distance 16, 18 Extended 185 Modifying optics 20 DMX Chart Hazardous Chemicals 15 Input mapping 184 HDBaseT inputs DMX input 42...
  • Page 203 Index Focus drift compensation 79 Profiles Shift 78 Introduction 114 Shift to center 80 Preset variables 113 Zoom 78 Projector Lens adjustment Components 24 Calibration 139 Orientation 24 Lens features 136 Projector control Lens shift 78 DMX 129 Local keypad Network Functionality overview 40 Introduction 120...
  • Page 204 Index Cooling liquid circuit 13 Switching on 26 Environment 9 Switching to standby 29 Hazard Distance 16, 18 System settings Hazardous Chemicals 15 Language 133 Important instructions 11 User interface Safety Data Sheet (SDS) 15 language 133 Servicing 14 System Settings 119, 134 Stacking 15 Advanced settings 145 Safety Data Sheet (SDS) 15...
  • Page 205 Index RCU 36 XLR connector Control 131 Zoom 78 R5911443 /03...
  • Page 206 Index R5911443 /03...

  • Page 207: List Of Tools

    List of tools List of tools Clean cotton cloth Clean micro fiber lens cleaning cloth (e.g. Toraysee® cloth(s)) Compressed air Lens cleaner (e.g. ZEISS lens cleaner, Purosol™ or other water based lens cleaner products) R5911443 /03...
  • Page 208 List of tools R5911443 /03...
  • Page 210 R5911443 /03 | 2020-09-03 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...

This manual is also suitable for:

Udm 4k22Udm 4k15Udm w22Udm w15Udm seriesUdm-w19 ... Show all

Table of Contents
