KXM/KUM Series 4K/8K LCD Monitors
USER MANUAL
V2.0.1
Shenzhen Konvision Technology Co., Ltd
http://www.konvision.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KXM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konvision KXM Series

Summary of Contents for Konvision KXM Series

  • Page 1 KXM/KUM Series 4K/8K LCD Monitors USER MANUAL V2.0.1 Shenzhen Konvision Technology Co., Ltd http://www.konvision.com...
  • Page 2 About This Manual The instructions in this manual are for KXM/KUM Series 4K/8K LCD monitors. In the following description, two different rear view model pictures are used. Please confirm the model number of the device before reading this manual.

  • Page 3: Table Of Contents

    Contents Notes ..........................4 Security ........................... 5 Parts and Functions ......................7 A．Front View ....................... 7 B．Rear View 1 ......................9 Rear View 2 ......................12 OSD Menu ........................15 Menu Operation: ....................15 Menu Item Description ..................15 Status Display: ....................15 VPID/HDMI Status (SDI): ................17 VPID/HDMI Status (HDMI): ...............18...

  • Page 4: Notes

    Notes For the safety use of products, please read the following instructions regarding the installation, use and maintenance carefully. . Please read the product safety and operating instructions carefully before the product operate. . Please keep the safety and operating instructions for future reference.

  • Page 5: Security

    LOGO or still characters etc. Please use a screen saver or timer to avoid displaying the same images for a long time. Security Screen Maintenance Please follow the below guidelines carefully to prevent discoloration, stains and scratches on the screen: - Avoid striking the screen with any object.
  • Page 6 Transportation - This monitor is precise equipment and need professional packing materials to transport. Please do not to use packing materials provided by suppliers except KONVISION or its authorized packing material suppliers. When the following situations occur, please turn off the power, and do not insert the plug.

  • Page 7: Parts And Functions

    Parts and Functions A．Front View (1) Tally Indicator Tally indicator control in two ways: 1． GPI Interface (see the control method at GPI interface description behind) 2． RS422 Port: control Tally light via TSL 3.1 or TSL 4.0 protocol. RS422 interface, 8Bit data, 1 stop, even parity, 38400 baud.
  • Page 8 S2 button. (5) S3 Button and Indicator Press the S3 button, the indicator will turn blue. Currently, the S3 button switch to the configuration corresponding to the S3 button. (6) S4 Button and Indicator Press the S4 button, the indicator will turn blue. Currently, the S4 button switch to the configuration corresponding to the S4 button.

  • Page 9: B．rear View 1

    B．Rear View 1 (1) AC IN and Switch AC power supply AC power input is powered on, switch to “I” to power on, switch to “O” to power off, and shut down (2) DC IN (Remark: only for a few models)
  • Page 10 Pin 1: GND Pin 2: NC Pin 3: NC Pin 4: +12V (3) AUDIO OUT Analog stereo audio interface output (4) LAN Ethernet port for color correction, upgrading or control UMD via TSL5.0. (For specification instructions please contact with the dealer)
  • Page 11 RS422 IN Signal name RS422 OUT Signal name GND (Power Ground) GND (Power Ground) GND (Power Ground) GND (Power Ground) NC (Not Connect) NC (Not Connect) NC (Not Connect) NC (Not Connect) (7) USB Upgrading the monitor FPGA, OSD, APP EDP software or LUT file with USB port.

  • Page 12: Rear View 2

    Rear View 2 (1) AC IN and Switch AC power supply AC power input is powered on, switch to “I” to power on, switch to “O” to power off, and shut down (2) DC IN (Remark: only for a few models)
  • Page 13 Pin 1: GND Pin 2: NC Pin 3: NC Pin 4: +12V (3) AUDIO OUT Analog stereo audio interface output (4) LAN Ethernet port for color correction, upgrading or control UMD via TSL5.0. (For specification instructions please contact with the dealer)
  • Page 14 RS422 IN Signal name RS422 OUT Signal name GND (Power Ground) GND (Power Ground) GND (Power Ground) GND (Power Ground) NC (Not Connect) NC (Not Connect) NC (Not Connect) NC (Not Connect) (7) HDMI IN HDMI signal input interface, Max support 4096x2160 60Hz...

  • Page 15: Osd Menu

    OSD Menu Menu Operation: Press MENU/EXIT key to enter the main menu, and then spin any knob to switch between options in the same menu. After you find the corresponding option, press the KNOB key to enter the next menu, and then spin the knob to find the corresponding Parameter, press KNOB key first, then spin the knob key to adjust the value of the parameter.
  • Page 16 Status Display Sub Menu Description Input Mode Display the current input mode Input Format Display the current input format and resolution Color Space Display the color space of the signal source Gamma Display the Gamma value of the signal source...

  • Page 17: Vpid/Hdmi Status (Sdi)

    VPID/HDMI Status (SDI): VPID/HDMI Status (Current SDI signal) Sub Menu Description Channel Select Select different channel to view different signal parameter Source Display the current input signal Payload ID Display the Payload ID of the SDI signal SMPTE Standard...

  • Page 18: Vpid/Hdmi Status (Hdmi)

    VPID/HDMI Status (HDMI): VPID/HDMI Status (Current HDMI signal) Sub Menu Description Channel Select Select different channel to view different signal parameter Source Display the current HDMI signal Color Format Display the Color Format of the signal Data Level Display the Data Level of the signal...
  • Page 19 Config Settings Sub Menu Settings Description Load Config Config1-5 Select the Config to load Save Config Config1-5 Users can preset the Config, after saving, users can set the Config to S1-S4 and other keys. Note: After modifying the parameters, be sure to save the Config.

  • Page 20: Function Settings

    Config2 Name Config2 Config2 Name and can rename the Config2 Config3 Name Config3 Config3 Name and can rename the Config3 Config4 Name Config4 Config4 Name and can rename the Config4 Config5 Name Config5 Config5 Name and can rename the Config5...
  • Page 21 Function Settings Sub Menu Settings Description Config1-5 Set the Config of S1 key Config1-5 Set the Config of S2 key Config1-5 Set the Config of S3 key Config1-5 Set the Config of S4 key S Key Info Press S Key, doesn’t display S Key info...

  • Page 22: Source Settings

    Function Reset Reset all the Sub Menu to Factory Settings >> Source Settings Source Settings Sub Menu Settings Setting Option Description Display Mode Single Select Single display Quad Select Quad display...
  • Page 23 Win 1 Win 2 Win 3 Win 4 Input Mode Single Select signal input mode Quad SDI 2SI and SDI SQD are used for 4K or 8K SDI Dual link signal, this signal is composed of 4 links. SDI 2SI...

  • Page 24: Color Settings

    SDI2 SDI2 input, user can select HDMI output SDI3 SDI3 input, user can select HDMI output SDI4 SDI4 input, user can select HDMI output HDMI HDMI input, user can select HDMI output SDP+ input, user can select HDMI output...
  • Page 25 Color Settings Sub Menu Settings Setting Option Description Full Screen Full screen color ctrl unified settings Color Ctrl Zone Ctrl Zone ctrl...
  • Page 26 (Note: this function only available in Quad Mode) Win1 Used for Zoon Ctrl, users can set different Win2 color parameter for each window Win3 Channel Select Win 1 Win 2 Win4 Win 3 Win 4 Auto Reserved function Cross Partition Show...
  • Page 27 27/1.33 ST2084 PQ ST2084 PQ(softroll) Slog/2/3, Clog/2/3, Vlog, Dlog, LogC Auto Select a transfer matrix that matches the input Rec601 signal Transfer Matrix Rec709 Rec2020 0~200 R Saturation Red Saturation, default value: 50 0~200 G Saturation Green Saturation, default value: 50...

  • Page 28: Image Settings

    G Offset 0-1023 Red Offset (only available in Color Temp user mode) B Offset 0-1023 Red Offset (only available in Color Temp user mode) Image Settings: Image Settings Sub Menu Settings Setting Option Description Backlight 0-100 Adjust screen backlight...

  • Page 29: Scope Settings

    Turn on Freeze Over Scan Turn off Over Scan Turn on Over Scan Mirror/Rotation Turn off Mirror/Rotation Mirror Horizontal mirror display Rotation The screen is rotated 180° Blue Mode/Mono Turn off the blue mode Mono Black and white mode display image...

  • Page 30: Assist Settings

    Waveform Turn off waveform LUMA Display LUMA waveform YCbCr Display YCbCr waveform Display RGB waveform Quad Luma Display Quad Luma (Note: this function only available in the Quad-view mode) Waveform Scale Digital Waveform scale is displayed numerically Waveform scale is displayed as a percentage of luminance...
  • Page 31 Assist Settings Sub Menu Settings Setting Option Description False Color Turn on False Color Turn off False Color Turn on False Color with HDR HDR Area Turn on HDR Area function to see the HDR percentage of the input signal...

  • Page 32: Marker Settings

    0%-100%. When the brightness in the picture reaches or exceeds this percentage, an alarm will occur and the alarm part will overlaid with a red zebra crossing. Time Code Turn on Time Code VITC1 Time Code Display as VITC1...
  • Page 33 Marker Settings Sub Menu Settings Setting Option Description Marker Display Turn on all markers Turn off all markers Aspect Marker No Aspect Marker Aspect Marker ratio 4:3 16:9 Aspect Marker ratio 16:9 15:9 Aspect Marker ratio 15:9 14:9 Aspect Marker ratio 14:9...

  • Page 34: Audio Settings

    Box Center Turn off Box Center Turn on Box Center Box Mat The color of the filling outside the box wireframe White Black Translucent Green Blue Box Line Color White The color of the box wireframe Green Blue Cyan...
  • Page 35 Audio Settings Sub Menu Settings Setting Option Description Audio Source Win1 Audio Source select Win1 Win2 Audio Source select Win2 Win3 Audio Source select Win3 Win4 Audio Source select Win4 (Note: this function only available in the Quad-view mode.)

  • Page 36: Cc Settings

    Mute Turn off Audio Mute Turn on Audio Mute Audio Phase Turn off Audio Phase Turn on Audio Phase Audio Level Turn off Audio Meter Meter Turn on Audio Meter Meter Vertical Audio meter vertical display Display Mode Horizontal...

  • Page 37: Umd Settings

    CC Setting (Only available for SDI Signal) Sub Menu Settings Setting Option Description Channel Select Channel 1 Select single channel SDI1 CC Channel 2 Select single channel SDI2 CC Channel 3 Select single channel SDI3 CC Channel 4 Select single channel SDI4 CC...
  • Page 38 UMD Settings Sub Menu Settings Setting Option Description UMD Display Turn on UMD display Turn off UMD display UMD Color Green UMD character display green UMD character display red White UMD character display white Black UMD character display black...
  • Page 39 (TSL5.0 use LAN interface, the default IP address of the monitor: 192.168.1.155) UMD Character Channel UMD name of the single picture mode or Win1 in Quad mode (Note: UMD protocol should select Local) UMD Character Channel UMD name of the Win2 in Quad mode...

  • Page 40: System Settlings

    Select TSL protocol control Port Number 3000 Network Port Number 3000 System Settlings: System Settings Sub Menu Settings Setting Option Description Key Lock Turn off Key Lock Turn on Key Lock Language Chinese Setting the language of the menu...
  • Page 41 OSD Blend 0-30 Setting the transparency of the menu DPMS Always ON Screen backlight is always turn on Light Sleep Screen backlight will turn off if no signal or no operation for 1 minute Deep Sleep The monitor will enter Eco mode if no signal or no...

  • Page 42: Sdi Or Hdmi Input Source Switching

    SDI or HDMI Input Source Switching 一、 S1/S2/S3/S4 Key & Config 1-5 Settings Konvision monitor supports the input of a variety of signals. Since the UHD signals have various formats and need to set parameters such as color gamut, EOTF etc. Therefore, Konvison monitor uses S1/S2/S3/S4 keys to replace SDI &...
  • Page 43 4. After saving, press the S1 key to call Config1. At this time, the screen will display the SDI3 signal 三、Quad Split Mode Win1 Win2 Win3 Win4 Win1 display SDI1, Win2 display SDI2, Win3 display SDI3, Win4 display HDMI. Set it to Config1, S1 to Config1, and quad display.
  • Page 44 3. Then, switch to Config option and select Config1, press the Knob button to save 4. After saving, press the S1 key to call Config1. At this time, the screen will display the quad split mode 四、SDI SQD/2SI display 4K signal...
  • Page 45 Set Quad link SDI SQD display 4K signal to Config1, S1 key to Config1 The steps are as follows: 1. Connect the monitor signal to SDI1/2/3/4 BNC 2. Press MENU/EXIT key, then switch to Source option, select Display Mode to Single, Input Mode to SDI SQD 3.

  • Page 46: Configuration Settings Description

    Configuration Settings Description Except switch to different channels, the Config of the S1/S2/S3/S4 can also set other parameters, such as brightness, contrast, EOTF curve, color gamut and so on. Users can preset 5 config in the menu according to their requirement. After modifying the parameters, be sure to save the Config in the menu.
  • Page 47 4. Switch the menu to Function option and select S2 to Config5 5. After setting, switch the menu to Config option and select the Save Config to Config5, press the Knob button to save.

  • Page 48: Function Keys Description

    After saving, press the S2 key to call Config5. At this time, the screen will display the HDMI single picture mode, color space is U1_User1, and brightness is 80. Function Keys Description 1. User can preset the Function keys F1/F2/F3/F4/F5 in the menu 2.
  • Page 49 Warranty Card Postal User Code Address Product Serial Model Number Purchase Dealer Date Maintenance Record Replacement parts Contents of User Date Repairer Reparation Signature Name This warranty card should filled in immediately when purchasing Please keep a proper record of this warranty card.
