- Page 1 KCM series 4K LCD Monitors USER MANUAL V1.3 Shenzhen Konvision Technology Co., Ltd http://www.konvision.com...
- Page 2 Shenzhen Konvision Technology Co,.Ltd www.konvision.com About This Manual The instructions in this manual are for KCM Series 4K LCD monitors. The following description use model KCM-2460W pictures. Please confirm the model number of the device before reading this manual.
-
Page 3: Table Of Contents
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Manual Notes..........................4 Security........................5 Features........................7 Parts and Functions....................10 A．Front View....................10 B．Rear View....................13 OSD Menu.........................16 Menu Operation:....................16 Menu Item Description..................16 1. Main menu:....................17 2. Sub Menu:..................... 17 Status Display:...................17 Function Settings:..................18 Marker Settings:..................20 Waveform:.................... -
Page 4: Notes
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Notes For the safety use of products, please read the following instructions regarding the installation, use and maintenance carefully. . Please read the product safety and operating instructions carefully before the product is operated. . Please keep the safety and operating instructions for future reference. -
Page 5: Security
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 15. Please keep not less than 5cm space around the vents while using the monitor, in order to obtain good heat dissipation effect. Security Screen Maintenance Please follow the below guidelines carefully to prevent discoloration, stains and scratches on the screen: - Avoid striking the screen with any object. - Page 6 Transportation - This monitor is precise equipment and need professional packing materials to transport. So do not to use packing materials provided by suppliers except KONVISION or its authorized packing material suppliers. When the following situations occur, please turn off the power, do not insert the plug and contact a professional service staff to deal with timely.
-
Page 7: Features
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 3. LCD screen may appear tiny spots (red, blue or green), this is not a fault, LCD screens are manufactured with high precision technology, and a small number of pixels may not be able to show intermittent. - Page 8 Shenzhen Konvision Technology Co,.Ltd www.konvision.com - Different color temperatures can be selected freely Image Size Setting - You can set the monitor display mode to full screen, 1: 1, and scale by original image based on the input video signal...
- Page 9 Shenzhen Konvision Technology Co,.Ltd www.konvision.com as not to over-expose the screen. Vector Scope - UV vector analysis can be performed on the input color bar signal. The vector coordinate UV coordinates represent the magnitudes of the U and V components, respectively, and the vector calibration circle indicates the phase (hue) of the chrominance signal.
-
Page 10: Parts And Functions
Tally indicator control in two ways: 1． GPI Interface (see the control method at GPI interface description behind) 2． LAN Interface: via “Konvision Device Controller” software to control the Menu (Please contact the dealer for “Konvision Device Controller” software) (2) Power Button and Indicator When the external AC power supply with electricity, the indicator light is red. - Page 11 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (4) DVI Button and Indicator Press this button to select the current input source for HDMI/DVI signal input, the indicator is blue. (5) LAYOUT Button Press LAYOUT key to switch the screen display mode. When the input signal is SDI signal, press LAYOUT key continuously, SDI signal has the following modes: 4L SDI Square Mode: 4 SDI inputs formed a 4K signal, 4K mode is Square mode..
- Page 12 Shenzhen Konvision Technology Co,.Ltd www.konvision.com indicator is blue. (9) MENU/EXIT Button Press to display the on-screen menu, press it again to clear the on-screen menu. Able to clear the mark display. Able to clear the mode display. Able to turn off the shortcut menu.
-
Page 13: B．rear View
Shenzhen Konvision Technology Co,.Ltd www.konvision.com B．Rear View (1) DC 12V IN 12V DC power supply:... - Page 14 Not connect Not connect GPI4 when connect GND, GPI4 works, GPI4 function can be set in the menu function option Not connect Ground (4) LAN Ethernet port for remote network control. Thought this port, along with software“Konvision...
- Page 15 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Device Controller”, you can achieve remote controlling to the monitor easily. (remote control software & instructions please contact with the dealer) (5) RS422 IN and RS422 OUT RS422 in and out, support dynamic UMD/Tally. RS422 IN Signal name RS422 OUT Signal name (6) SDI1、SDI2、SDI3、SDI4 Input / Loop out...
-
Page 16: Osd Menu
Shenzhen Konvision Technology Co,.Ltd www.konvision.com For HDMI / DVI signal input. Through HDMI to DVI adapter, you can access the HDMI signal. In the HDMI Square Mode display mode, it can display the 4K signal when the 4K signal composed of DVI_IN1, DVI_IN2, DVI_IN3 and DVI_IN4 is input at the same time. -
Page 17: Main Menu
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 1. Main menu: The main menu contains the following items: Main menu options Sub-menu Status Display Function Settings Marker Settings Waveform Aux Settings Color Settings Video Settings Input Settings Audio Settings CC Settings IMD Setting... -
Page 18: Function Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Status Display Menu item Description Input Source Display the current input source Input Format Display the current input format SDI Payload ID SDI Payload ID Brightness Display current image brightness Contrast Display current image contrast... - Page 19 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Function Settings Sub Menu Settings Setting Option Description Undefined The function keys can be set to the following W-Form Mode functions: W-Form Mode, Vector Scope, Vector Scope Histogram, Audio Meter, Focus Assistant, False Histogram Color, Zebra, Blue, Mono, Red, Green, Time...
-
Page 20: Marker Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Static Frame Mute Markup Control Same as above Same as above GPI1 Undefined The function keys can be set to the following Markup Control functions: Markup Control, Red Tally Red Tally, Green Tally, Blue, Mono, SDI, HDMI,... - Page 21 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Marker Settings Sub Menu Settings Setting Option Description Marker Control Turn on all markers Turn off all markers Area Marker No Area Marker Area Marker ratio 4:3 15:9 Area Marker ratio 15:9 14:9 Area Marker ratio 14:9...
- Page 22 Shenzhen Konvision Technology Co,.Ltd www.konvision.com 85％Safety Area 88％Safety Area 90％Safety Area 93％Safety Area Fit Marker Turn off Fit Marker Turn on Fit Marker Marker Mat Turn off Marker Mat Black Turn on Marker Mat as Black Translucency Turn on Marker Mat as Translucency...
-
Page 23: Waveform
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Waveform: Waveform Sub Menu Settings Setting Option Description Waveform Mdoe Turn off waveform LUMA Display LUMA waveform YCbCr Display YCbCr waveform Display RGB waveform Waveform Scale Digital Waveform scale is displayed numerically Waveform scale is displayed as a percentage... - Page 24 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Vector Close vector Vector illustration 100% display Vector reduced to 75% display Histogram Close histogram LUMA Display brightness histogram Display RGB histogram Channel Select Channel 1 Select to display channel 1 waveform Channel 2 separately...
-
Page 25: Aux Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Aux settings: Aux settings Sub Menu Settings Setting Option Description False Color Turn on False Color Turn off False Color Focus Assist Turn on Focus Assist Turn off Focus Assist Focus Gain 0-31 Focus Gain 0-31... -
Page 26: Color Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com occur and the alarm part will be overlaid with a red zebra crossing. H Flip Turn on H Flip Turn off H Flip Time Code Turn on Time Code Turn off Time Code Color Settings:... - Page 27 Shenzhen Konvision Technology Co,.Ltd www.konvision.com 6500K Select Color Temp 6500K 9300K Select Color Temp 9300K User Select User-Defined Color Temp Red Gain 0－255 Red Gain 0－255 Green Gain 0－255 Green Gain 0－255 Blue Gain 0－255 Blue Gain 0－255 Red Bias 0－255...
-
Page 28: Video Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com ST2084 300nit ST2084 500nit ST2084 800nit ST2084 1000nit S-Log3 Ture off HDR Rec.2100 HLG HDR select Rec.2100 HLG User-HDR ST2084 HDR10 mode HDR selectST2084 HDR10 mode Video Settings:... - Page 29 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Video Settings Sub Menu Settings Setting Option Description Aspect Full Screen The screen is displayed in Full Original Ratio Screen The screen is displayed in the original scale of the input signal. The screen is displayed as 1:1...
-
Page 30: Source Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Green Full blue mode display image Full red mode display image Full green mode display image Source Settings: Source Settings Sub Menu Settings Setting Option Description Window Select Window 1 Select window 1 Window 2... -
Page 31: Audio Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com HDMI1 Source Select HDMI1 HDMI2 Source Select HDMI2 HDMI3 Source Select HDMI3 HDMI4 Source Select HDMI4 Audio Settings: Audio Settings Sub Menu Settings Setting Option Description Audio Source Undefined Audio Source Undefined SDI1 Audio Source select SDI1... - Page 32 Shenzhen Konvision Technology Co,.Ltd www.konvision.com HDMI3 Audio Source select HDMI3 HDMI4 Audio Source select HDMI4 Output Channel CH1&CH2 Select audio output CH3&CH4 CH1&CH2 Channel CH5&CH6 Select audio output CH7&CH8 CH3&CH4 Channel CH9&CH10 Select audio output CH11&CH12 CH5&CH6 Channel Select audio output CH13&CH14...
-
Page 33: Cc Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com CH13-16 CH13-14 Select meter channel CH13-16 CC Settings: CC Setting Sub Menu Settings Setting Option Description Channel Select Channel 1 Select single channel SDI1 Channel 2 Channel 3 Select single channel SDI2 Channel 4 4K Mode... - Page 34 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Select 4K mode CC CC Mode Turn off CC Select 708 Mode Select 608 Mode 608 Caption Type CC 1 608 select CC 1 type CC 2 608 select CC 2 type CC 3 608 select CC 3 type...
-
Page 35: Imd Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com IMD Settings: IMD Settings Sub Menu Settings Setting Option Description IMD Display Turn on IMD display Turn off IMD display IMD Color Green IMD character display green IMD character display red White IMD character display white IMD protocol TSL3.1... - Page 36 Shenzhen Konvision Technology Co,.Ltd www.konvision.com the machine when multiple machines are cascaded. This function can be used to distinguish different machines by IMD address when using RS-422 system to remotely control different machines. Baud Rate 38400 Select the baud rate for...
-
Page 37: Osd Settlings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com OSD Settlings: OSD Settings Sub Menu Settings Setting Option Description Language Chinese Menu language selection English Chinese Menu language selection English OSD time 5-60 Setting menu display time OSD Position Top left Menu position is at the top left... -
Page 38: Key Lock
Shenzhen Konvision Technology Co,.Ltd www.konvision.com factory settings Key Lock: Key Lock Sub Menu Settings Setting Option Description Key Lock Turn off Key Lock Turn on Key Lock Factory Settings Use this feature, you can reset this monitor to factory settings. -
Page 39: Remote Control
Remote control the monitor through Ethernet: 1 ． Connected with monitor via LAN, and you can achieve remote controlling by software“Konvision Device Controller”.(Network remote control software and instructions please contact with the dealer) 2．The network cable is a parallel cable connection... -
Page 40: Ac Power Connection
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Parallel line connection: Both ends are 568A standard or both ends are 568B standard. 568A standard: green white, green, orange white, blue, blue white, orange, brown white, brown 568B standard: orange white, orange, green white, blue, blue white, green, brown white,... - Page 41 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Warranty Card Postal User Code Address Product Serial Model Number Purchase Dealer Date Maintenance Record Replacement parts Contents of User Date Repairer Reparation Signature Name This warranty card should be filled in immediately when purchasing Please keep a proper record of this warranty card.
