- Page 1 V1.0 USER MANUAL NDI Monitors Konvision LCD Monitor w w w k o n v i s i o n c o m...
-
Page 2: Table Of Contents
Catalogue Preset .........12 Notes..........5 Load Preset........12 Safety .........5 Save User Preset ......13 Screen Maintenance ....5 USB Export/Import Preset ..13 LCD and OLED Screen Note ..5 Power On Load ......13 Importance ........5 User Preset Name .....14 Function Keys ......14 Smear .........6 Source ........14 Cabinet Maintenance ....6 Layout Mode ......14... - Page 3 About This Manual UMD Parameter ......32 The manual instruction is for the NDI Tally ..........33 monitor: System ........33 KUM-2410H-NDI Language ........33 Please keep the manual carefully. Please read the manual carefully before Menu Display Time ....33 using the product. Menu Position ......33 Any updating or modification of the manual OSD Blend .........33...
-
Page 4: Notes
Do not spray detergent or other cleaners on the · Notes monitor or LCD panel, as it may cause fault because of water droplets into the monitor. Do not paste or stick any viscous markers on the · screen. For the more difficult cleaning, use lint Safety free cloth that has been very lightly dampened with detergent, then dry any excess moisture from... -
Page 5: Smear
Multi Definition Support Rack mount Installation The KUM-2410H-NDI equips a 23.8 inch 4K For rack mount installation, please keep 1U space definition screen that can support SD, HD and from both top and bottom to make sure, adequate Ultra HD video signal monitoring on the original air circulation, or install an external electric fan. -
Page 6: Shortcuts
Shortcuts Friendly Handles The front panel equips function keys and knobs, The monitor has ergonomic designed handles for easy to select input source, modify backlight fast, user-friendly modification. brightness and sound volume. Only to connect the power and SDI signal can easily start monitoring. IP Streaming Input Wide Color Gamut The monitor can receive NDI|HX IP streaming... -
Page 7: Parts And Functions
Parts and Functions Front View Front View Instruction Tally VOLUME(L/R)Knob Tally indicator control in GPI interface. When in the menu, spin this knob to select L/R operation. When not in the menu, press the knob continuous, will Power Button and Indicator appear following adjustment: When the external AC power supply with electricity, Audio Mute: audio mute on/off... -
Page 8: Rear View
Rear View Rear View Instruction AC IN and Switch HDMI (IN/OUT) AC power supply. HDMI signal input/output interface, maximum supports AC power input is powered on, switch to “I” to power on, 4096x2160 60Hz. switch to “O” to power off, and shut down. USB Type- A DC IN Upgrading the monitor FPGA, OSD, APP, EDP software... -
Page 9: Interface And Pin
RS422 IN Interface and Pin RS422 OUT Signal Name Signal Name GPI Interface: GND(Power GND(Power Ground) Ground) GND(Power GND(Power Ground) Ground) Pin GPI Signal Description When connect GND (or lower level), GPI 1 works, GPI 1 function GPI1 can be set in the menu function NC(Not option. -
Page 10: Remove The Power Cord
Remove the Power Cord 1. For models with AC In port and switch, switch to and the device will be set to standby status,pull out the power cord from the DC SDI 1 No Signal adaptor, then pull out the adaptor form the device. -
Page 11: Vpid/Hdmi Status
Item Description Item Description (Current SDI signal) Layout Mode Display the current input mode. Channel Select different channel to view different signal parameter. Input Format Display the current input resolution and frame rate. Source Display the current input signal. Color Space Display the current color space setting. -
Page 12: Save User Preset
Preset Template1 Template2 Template3 Template4 Template5 Feature (SDR) (2020 HLG1.2) (P3D65 PQ) (Quad) (2SI) Preset Template1 Template2 Template3 Template4 Template5 Feature (SDR) (2020 HLG1.2) (P3D65 PQ) (Quad) (2SI) Layout Single Image & Single Image & Single Image & Quad Image & Single Image &... -
Page 13: User Preset Name
User Preset Name Source Users can set the preset names on demand. Layout Mode How to set User Preset Name: Layout mode can be set on multi-source input Press down key to enter the menu. monitor to assign the image display in order. It is Rotate the knob, select the Preset item to important for professional applications such as open the sub menu. -
Page 14: Output Source
Color Item Description Color Control Serial Digital Interface. Network Device Interface. The color control supports full screen and area control. HDMI High-Definition Multimedia Interface. How to set Window Source: Item Description Press down key to enter the menu. All Screen Adjust the color for the full screen to Rotate the knob, select the Source item to maintain the image color consistency. -
Page 15: Data Level
How to set Cross Partition Show: Item Description Press down key to enter the menu. Extend(64-1019) Extended data range of Limit to increase Rotate the knob, select the Color item to the dynamic range of the image, open the sub menu. especially the highlight and the shadow, Rotate the knob, select Cross Partition compatible for more dynamic range... -
Page 16: Eotf
Item Description Auto(VPID/AVI) Automatically recognizing and setting the color space of the input signal. Auto(Format) Automatically set the color space to Rec2020 when the input signal format is 4K and set the color space to Rec709 when the input signal format is 2K. Bypass Bypass will display the image with the native color display capability of the... -
Page 17: Transfer Matrix
Item Description Item Description Gamma2.4(HDR) This gamma is suitable for HDR Slog Slog, Clog, Vlog are using in camera content that provides wider contrast recording, provides wide dynamic and color depth. It can be selected range for postproduction workflow, Slog2 with BT2020 color space. -
Page 18: Saturation
How to set different Transfer Matrix: How to set Hue: Press down key to enter the menu. Press down key to enter the menu. Rotate the knob, select the Color item to Rotate the knob, select the Color item to open the sub menu. -
Page 19: Contrast
Contrast The Contrast is the definition ratio between the ultra- brightness and black of the monitor. How to set the Contrast: Press down key to enter the menu. Rotate the knob, select the Color item to open the sub menu. Rotate the knob, select Contrast item and press the knob to adjust the volume. -
Page 20: Freeze
How to set Overscan: Item Description Press down key to enter the menu. Full Screen Scale the image to fulfill the screen Rotate the knob, select the Image item and regardless its origin aspect ratio. press the knob to open the sub menu. It may cause deformation of the Rotate the knob, select the Overscan item image. -
Page 21: Mirror/Rotation
Mirror/Rotation Mirror display will flip the image with vertical axis like the reflect in the mirror. Rotation display will rotate the image in 180°. Color Pattern How to set Mirror/Rotation: Color pattern displays various solid color to evaluate and calibrate the monitor. Press down key to enter the menu. -
Page 22: Darkness Check
Darkness Check Scopes Darkness check can review the dark area and Waveform performance of detail to evaluate the visibility of shadow and contrast ratio. The waveform display provides a digitally encoded Note Darkness Check can only activate by F Keys. waveform like traditional luminance waveform monitors, which is used to monitor and adjust the How to set Darkness Check:... -
Page 23: Waveform Scale
Waveform Alarm Waveform Scale Set a safety range of the waveform, when the Waveform Scale is a useful measurement and luminance and chrominance level over the range, monitoring tool for luminance and chrominance the alarm will be activated, a red part display on information in the production and television the waveform. -
Page 24: Vector
Vector Histogram Vectorscope shows the colors in a vector view. Histogram is the instant indicator of luminance and Professionals can assess the color performance. chrominance for adjusting exposure and color. It Vectorscope can indicate the color accuracy. If shows the distribution of whites and blacks of the some areas in the vectorscope had deviated, it video. -
Page 25: Assist
How to set the HDR Area: Press down key to enter the menu. Rotate the knob, select the Assist item and press the knob to open the sub menu. Rotate the knob, select the HDR Area item and press the knob to set on/off. When the EOTF is set to HDR, the account for HDR area can be read. -
Page 26: Focus Peaking Level
Focus Peaking Level Item Description Set the sensitivity of the Focus Peaking detection. VITC1 A kind of Vertical Interval Timecode. VITC2 Another kind of Vertical Interval Timecode. How to set the Focus Peaking Level: Line in Timecode. Press down key to enter the menu. Rotate the knob, select the Assist item and How to set different Timecode: press the knob to open the sub menu. -
Page 27: Marker
How to set different Aspect Marker: Marker Press down key to enter the menu. Marker Display Rotate the knob, select the Marker item and press the knob to open the sub menu. The Marker provides aspect ratio frame guidelines Rotate the knob, select the Aspect Marker overlay on the image. -
Page 28: Safety Area
Safety Area Marker Mat Guidelines for safety area to guarantee the image Marker Mat can set the area outside the marker to area could be displayed on various devices. black or grey. How to set the Safety Area: How to set the Marker Mat: Press down key to enter the menu. -
Page 29: Audio
Audio Audio Channel Each Audio Channel can select CH1 to CH16 for output, when select one channel in the Left Audio Channel, the corresponding number of the channel under the audio meter will turn green, select one channel in the Right Audio Channel, its number will turn purple. -
Page 30: Closed Caption
Closed Caption Closed captioning (CC) is a form of subtitling, a process of displaying text on a television, video screen, or other visual display to provide additional or interpretive information. The term closed indicates that the captions are not visible until activated by the viewer, usually via the remote UMD Protocol control or menu option. -
Page 31: Umd Character And Color
Sub Menu Item Description UMD ID 0-126 Only can be set when UMD Protocol is TSL3.1 or TSL4.0 UMD Screen ID 0-65534 Only can be set when UMD Protocol is TSL5.0 UMD DisplayID 0-65531 Only can be set when UMD Protocol is TSL5.0 Baud Rate 4800bps Only can be set when... -
Page 32: Tally
Tally How to set the Menu Display Time: Press down key to enter the menu. The KRM 4K Monitor supports UMD Tally control by Rotate the Knob, select the System item and TSL3.1 Protocol, the color can be set to Red/Green, press the knob to open the sub menu. -
Page 33: Dmps
DMPS DMPS can save power in the idle time, including NDI Mode Always On, Light Sleep and Deep Sleep. The NDI monitor can provide NDI and NDI|HX Item Description encoder and decoder signal transmission up to UHD 4K60P. Always On Keep the system on. -
Page 34: Ndi Web Control
NDI Web Control The NDI monitor has web control, user can set remote connection, input/output signal and network parameter control through RJ-45 Ethernet. The NDI monitor is set to NDI DHCP to automatically obtain IP address, user can select the NDI item in Status Column the OSD menu to see the NDI IP address. -
Page 35: Ndi Setting
NDI Setting Item Description Codec Supports H.264 and H.265. Item Description De-interlacing Turn on to support interlace signal. Group The group name can be the combination of characters and HX Version Support NDI|HX and NDI|HX3, select numbers. Multiple group names different version in demand. -
Page 36: Discovery Of Ndi Sources
After adding the NDI sources to different preset windows, clicking the preset window and the Discovery of NDI sources monitor will immediately start decoding the NDI source, and finish the switching between The monitor can discover NDI sources on the different NDI sources. -
Page 37: Decoding Parameter Configuration
Decoding parameter configuration Area and Time “Current decoding output” displays the current Modify the system time and area. decoding NDI source name, channel name, resolution/frame rate, audio parameters, source IP address, real time bit rate and frame rate and so on. System Settings General Settings The general settings module provides the ability to... - Page 38 warranty card User Address Postal Code Model. No Serial Number Warranty Date Purchase Date Replacement parts Replacement parts Item Contents of Reparation Remark name quantity Repairer Signature Service hotline User Signature...
