Summary of Contents for Konvision KFM-5X series
- Page 1 KFM-5X series / KFM-6X series LCD Monitors USER MANUAL V2.1 Shenzhen Konvision Technology Co., Ltd http://www.konvision.com...
-
Page 2: Table Of Contents
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Contents Notes ........................3 Security ........................4 Features ........................6 Parts and Functions ..................... 10 A: Front View ....................10 B: Rear View ....................14 Menu Operation ....................18 Menu Item Description ................. 19 1. Main menu: ....................19 2. -
Page 3: Notes
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Notes For the safety use of products, please read the following instructions regarding the installation, use and maintenance carefully. . Please read the product safety and operating instructions carefully before the product is operated. . Please keep the safety and operating instructions for future reference. -
Page 4: Security
Shenzhen Konvision Technology Co,.Ltd www.konvision.com cause voltage instability and short-circuit, also can easily cause fires and blackouts. 14. If do not use the device for a long time, please unplug the power cord from the AC outlet. 15. Please keep not less than 5cm space around the vents while using the monitor, in order to obtain good heat dissipation effect. - Page 5 Transportation - This monitor is precise equipment and need professional packing materials to transport. So do not to use packing materials provided by suppliers except KONVISION or its authorized packing material suppliers. When the following situations occur, please turn off the power, do not insert the plug and contact a professional service staff to deal with timely.
-
Page 6: Features
Shenzhen Konvision Technology Co,.Ltd www.konvision.com The following does not belong to failures: 1. If the static image displayed too long, it will have residual image, which should be attributed to the characteristics of LCD display but not a failure. Residual image will disappear automatically after a period of time. - Page 7 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Support Multiformat SDI Signals - The SDI interface supports SD-SDI, HD-SDI, dual link HD-SDI and 3G SDI inputs. SDI Input - Support multi-format SDI input, SD-SDI, HD-SDI, 3G SDI - Support SMPTE425M-A/B 4:4:4 signals. HDMI/DVI/VGA Input...
- Page 8 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Color Space - Color space include: Rec 709、 EBU、 DCI P3 D65、 DCI P3、 Rec 2020、 USER1、 USER2、 USER3. (This function only available to KFM-6X) Color Calibration - This enable to calibrate imported color data of the image being measured by color analyzer.
- Page 9 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Vector scope - Vector UV analysis for color bar signal input. Pixel Measurement - User can measure any pixel’s specific position and RGB value, also can compare the YRGB value between any 2 pixels. Time code - Display SMPTE time code (LTC, VITC1, VITC2) under SDI1 input, it is used for identifying and synchronizing of video data streams.
-
Page 10: Parts And Functions
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Parts and Functions A: Front View (1)Tally Indicator Control method of Tally light GPI port（control method: please look the GPI port description） RS422 Port: support use TSL3.1 or TSL 4.0 protocol control the tally light (2) Speaker Stereo audio output. - Page 11 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (3) Power Button and Indicator When the external AC power supply with electricity, the indicator light is red. Press this POWER button to power on the monitor, and the indicator light turns blue. Press this button for about 2 seconds, can turn off the monitor, the indicator light turn red.
- Page 12 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (11) MENU Button Press this button to display the OSD menu, and press it again to exit the menu. Clear the Marker display. Clear Display mode. Turn off the shortcut menu. (12) UP/IMAGE ADJ Button When in OSD main menu, press this button to select up sub-menus.
- Page 13 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (15) RIGHT/VOLUME Button When entering the main menu operation, press this button to select the sub menu to the right. When entering the sub menu operation, press this button to adjust the parameters of the current sub menu item to the right.
-
Page 14: B: Rear View
Shenzhen Konvision Technology Co,.Ltd www.konvision.com B: Rear View KFM-1753W rear view port KFM-1760D rear view port... - Page 15 In shortcut functions: Turn the knob to adjust the value of Brightness, Contrast and Chroma respectively. Ethernet port for remote network control. Thought this port, along with software “Konvision Device Controller”, you can achieve remote controlling to the monitor easily. (remote control software & instructions please contact with the dealer)
- Page 16 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (4) GPI GPI interface: GPI Signal Description GPI1 when connect GND, GPI1 works, GPI1 function can be set in the menu function option GPI2 when connect GND, GPI2 works, GPI2 function can be set in the menu function option...
- Page 17 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (5) RS422(IN/OUT) RS422 in and out, support dynamic UMD/Tally. RS422 IN Signal name RS422 OUT Signal name (6) VIDEO Video signals input (7) HDMI/DVI/VGA HDMI/DVI/VGA input. DVI input, support DVI signal, HDMI signal (via HDMI-DVI...
-
Page 18: Menu Operation
Shenzhen Konvision Technology Co,.Ltd www.konvision.com (9) SDI2(IN/OUT) SDI2 inputs (3G/HD/SD-SDI auto detect), SDI Reclock loop through output, without enervation. (10) AUDIO(IN/OUT) Audio in used for analog signal input, Audio out used for monitoring with 3.5mm earphone. (11) AC Faucet Using for AC power connect... -
Page 19: Menu Item Description
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Menu Item Description 1. Main menu: The main menu contains the following items: Main menu Menu item Status Function Key Picture Image Audio Marker Scope Embedded code Layout Alarm Setup Key Lock... -
Page 20: Sub Menu
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 2. Sub Menu: Status: Status Menu item Description Source&Format Current window input signal and resolution The current window input signal line frequency The field frequency of the current window input signal Color Temp The current color temperature... -
Page 21: Function Key
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Function Key: Function Key Menu item Setting Description Image Size The Function keys can be set to the No Definition following functions: Image Size, static frame Definition, static frame, Time Code Display, Time Code Display... - Page 22 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Gray Mode Marker Setting Same as above Same as above Same as above Same as above Same as above Same as above Same as above Same as above GPI1 Blue Mode Can be set to the following functions:Blue...
-
Page 23: Picture Setting
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Picture Setting: Picture Menu item Setting Description Backlight 0-100 Backlight Adjustment Standard The parameters of brightness, contrast, Picture Mode Customize sharpness, color, hue in Factory Default. Custom is for user definition Brightness 0-100 Brightness Adjustment... -
Page 24: Image
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Blue Gain 0-255 temperature setting automatically. Red offset 0-255 Green offset 0-255 Blue offset 0-255 Image: Image Menu item Setting Description Image Size FILL ASPECT original ratio of the signal source Full Screen Full screen image 1: 1 At 1:1 pixel-to-pixel display. - Page 25 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Under Scan 5% 105% image display Part Zoom in <Right>Enter, <PIP>Part Zoom in any part of the Zoom in picture, to watch picture details more clearly, and assist for focus. Gray Mode Monochrome mode with...
- Page 26 Select Rec 2020 USER1 Select USER1 USER2 Select USER2 Bypass Select Bypass (Remark 1: KFM-5X series only available Rec2020 and bypass. Remark 2: Users can load their own LUT files through user1 and user2 option. For specific instruction please contact...
-
Page 27: Audio
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Audio: Audio Sub Menu Items Setting Description Volume 0－100 Speaker volume adjustment Headphone Volume 0－100 Headphone volume adjustment Audio Out Mode Normal Left and right channel out (only for SDI and HDMI/DVI Left Channel Mute... - Page 28 Shenzhen Konvision Technology Co,.Ltd www.konvision.com select in CH1&CH2. Audio Level Meter Turn on/off audio level (only SDI/HDMI/DVI meter display signal) Audio Display Channels 1-4 Channel When in SDI Signal: (only SDI/HDMI/DVI 1-8 Channel 1-4 channels: 1-4 channels signal) 1-16 Channel...
-
Page 29: Marker Setting
Shenzhen Konvision Technology Co,.Ltd www.konvision.com (only SDI/HDMI/DVI Meter display signal) Audio Phase Channel CH1&CH2 When in SDI Signal: (only SDI/HDMI/DVI CH3&CH4 SDI Audio Phase Channel signal) CH5&CH6 can be selected in CH1&CH2 、 CH3&CH4 、 CH7&CH8 CH5&CH6、CH7&CH8. When in HDMI Signal:... - Page 30 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Marker Select NO marker display Marker display 4:3 16:9 Marker display 16:9 15:9 Marker display 15:9 14:9 Marker display 14:9 13:9 Marker display 13:9 1.85:1 Marker display 1.85:1 2.35:1 Marker display 2.35:1 Target Marker Turn on target marker...
-
Page 31: Scope
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Scope: Scope (only for SDI/HDMI/DVI signal) Sub Menu Items Setting Description Waveform Mode Turn off the waveform mode Display Y(luminance) waveform Display YCbCr waveform LUMA Display Y (luminance) waveform, one-to-one correspondence be- FULL LUMA tween its horizontal coordinates... - Page 32 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Scope (only for SDI/HDMI/DVI signal) Waveform Scale Digital Display in digital Display in percentage of luminance Histogram Mode Turn off the histogram LUMA mode Display luminance histogram Display R G B histogram Vector Turn on/off vector...
-
Page 33: Embedded Code
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Focus Color Focus color use Red Green Focus color use Green Blue Focus color use Blue White Focus color use White H Flip Turn on horizontal flip Turn off horizontal flip Embedded code: Embedded code (only for SDI signal) -
Page 34: Layout
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Layout: Layout Menu item Setting Description Layout Single Display only a single signal picture on screen Display two signals pictures simultaneously on screen, the sub picture in the main picture. Side by Side Display two signals pictures... - Page 35 Shenzhen Konvision Technology Co,.Ltd www.konvision.com any of other input signals. Can display 2 SDI simultaneously. Main Window Source Video Main Window select signal SDI1 input among SDI2 SDI1/SDI2/VGA/HDMII HDMI Second Window Source Video Main Window select signal (this item shows...
- Page 36 Shenzhen Konvision Technology Co,.Ltd www.konvision.com adjusted by user When the user select this option, it will automatically pop up at the following "horizontal position" and "vertical position" menu items H Position 0－100 Horizontal position (this item shows when PIP adjustment of position select “Custom”)
- Page 37 Shenzhen Konvision Technology Co,.Ltd www.konvision.com display characters can be arbitrarily set in 8 "xxxxxxxx".The setting process: Select the option to the UMD main screen character options, press the ZOOM/SWAP button, the option is displayed as "xxxxxxxx ok". Meanwhile, the first character turned...
- Page 38 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (RIGHT/VOLUME) button, "OK" will turn yellow, then press the MENU button to save and exit can complete the main screen of UMD character set. When setting, only if the character "OK" is yellow, press the...
-
Page 39: Imd
Shenzhen Konvision Technology Co,.Ltd www.konvision.com IMD: Sub Menu Items Setting Description Turn on/off UMD Display display 128-255 UMD ID can be set any value from 128-255. It can be used for multidevice cascading, different different UMD ID devices. In remote control... - Page 40 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Top Center UMD display at Top Center Bottom Center UMD display at Bottom Bottom Right Center UMD display at Bottom Right GREEN UMD character display in green White UMD character display in UMD Local Color...
- Page 41 Shenzhen Konvision Technology Co,.Ltd www.konvision.com second characters turn red, or press the LEFT and (RIGHT/VOLUME) button select desired character. turn, eighth character selection, when eighth characters after selection, and then press the (ZOOM/SWAP) button, "OK" will become red, or press the...
-
Page 42: Alarm
Shenzhen Konvision Technology Co,.Ltd www.konvision.com mode) UMD PROTOCOL TSL3.1 Select TSL3.1 TSL4.0 Select TSL4.0 TSL5.0 Select TSL5.0 OSD Tally Mode Turn off OSD Tally OSD Tally select RG mode OSD Tally select GR mode Tally select mode LED Tally Turn on/off the LED Tally... - Page 43 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Alarm Menu item Setting Description Alarm Display Turn off/on alarm display No Signal Alarm Turn off/on the signal alarm Black Frame Alarm Turn off/on the black frame alarm Static Frame Alarm Turn off/on the static frame...
-
Page 44: Setup
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Setup: Setup Sub Menu Items Setting Description Language Chinese Select Chinese/English in English menu OSD Settings Menu background from 0-100 opaque to completely transparent selection 1-30 Menu disappear time when no button operation 0-100 Menu horizontal position... - Page 45 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Turn on the display info of signal format. Auto Automatically display info of signal format when signal changes, disappear after Power Saving Enter power-saving mode, the system will switch off some functions when the main input is without signal more than 10 minutes.
-
Page 46: Key Lock
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Key Lock: Key Lock Menu item Setting Description Key Lock Key Lock Off When the key lock are turn on,only MENU VOLUME(LETF/RIGHT) knob, IMAGEADJ(UP/DOWN) knob can be operate, the rest can not. -
Page 47: Function Key
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 3. Function Key Function Key Shortcut Menu Set up Setting Description Press main menu Function key Press main menu Function key to to set Press main menu Function key Press main menu Function key to... - Page 48 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Dual picture operation: Continuous press PIP / PBP button, you can quickly from single-picture and dual-picture by the fast switch. In the dual picture, press the SWAP key, you can quickly exchange the left and right pictures. In the dual picture, press the WIN SEL button, you can select the picture window, at the same time, the selected window, you can also adjust the parameters alone, does not affect the other picture.
-
Page 49: Sdi 2K Signal Display Description
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Diff: The difference between the current pixel and the previous pixel Line: The vertical position of the pixel Sample: The horizontal position of the pixel Y: The Y component value of the pixel (range between 0-1023) Y%: The percentage of the Y component of the pixel relative to the maximum, i.e., (Y... - Page 50 Shenzhen Konvision Technology Co,.Ltd www.konvision.com To do factory reset, please follow the below six steps: 1. Press the MENU button to enter the main menu options. 2. Press the DOWN button to select the setting option. 3. Press RIGHT to select the Set Sub menu Options.
-
Page 51: Remote Control
Remote control the monitor through Ethernet: 1. Connected with monitor via LAN, and you can achieve remote controlling by software “Konvision Device Controller”.(Network remote control software and instructions please contact with the dealer) 2. The LAN cable should be parallel connection for both two ends, for example 568B LAN cable, with pin definition: orange-white, orange, green-white, blue, blue-white, green, brown-white, brown. - Page 52 Shenzhen Konvision Technology Co,.Ltd www.konvision.com 2. See Figure 2, when the pull-out monitor is pulled out horizontally, its extracted length L2 is 330mm. Figure 2 3. See Figure 3, when the pull-out monitor stands up, its height H2 is 312mm.
- Page 53 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Warranty Card User Postal Code Address Product Serial Model Number Purchase Dealer Date Maintenance Record Replacement parts Contents of User Date Repairer Reparation Signature Name This warranty card should be filled in immediately when purchasing Please keep a proper record of this warranty card.
