- Page 1 KXM/KUM series 4K LCD Monitors USER MANUAL V1.2.2 Shenzhen Konvision Technology Co., Ltd http://www.konvision.com...
- Page 2 Shenzhen Konvision Technology Co,.Ltd www.konvision.com About This Manual The instructions in this manual are for KXM/KUM Series 4K LCD monitors. The following description use model KUM-2710D pictures. Please confirm the model number of the device before reading this manual.
-
Page 3: Table Of Contents
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Manual Notes ......................... 4 Security ........................5 Parts and Functions ....................8 A．Front View ....................8 B．Rear View ....................10 SDI Input Connection and Display Mode ............... 12 HDMI Input Connection and Display Mode ............15 OSD Menu ...................... -
Page 4: Notes
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Notes For the safety use of products, please read the following instructions regarding the installation, use and maintenance carefully. . Please read the product safety and operating instructions carefully before the product is operated. . Please keep the safety and operating instructions for future reference. -
Page 5: Security
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 15. Please keep not less than 5cm space around the vents while using the monitor, in order to obtain good heat dissipation effect. Security Screen Maintenance Please follow the below guidelines carefully to prevent discoloration, stains and scratches on the screen: - Avoid striking the screen with any object. - Page 6 Transportation - This monitor is precise equipment and need professional packing materials to transport. So, do not to use packing materials provided by suppliers except KONVISION or its authorized packing material suppliers. When the following situations occur, please turn off the power, do not insert the plug and contact a professional service staff to deal with timely.
- Page 7 Shenzhen Konvision Technology Co,.Ltd www.konvision.com The following does not belong to failures: 1. If the static image displayed too long, it will have residual image, which should be attributed to the characteristics of LCD display but not a failure. Residual image will disappear automatically after a period.
-
Page 8: Parts And Functions
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Parts and Functions A．Front View (1) Tally Indicator Tally indicator control in two ways: 1． GPI Interface (see the control method at GPI interface description behind) 2． RS422 Port: through TSL3.1 or TSL 4.0 protocol control Tally light (2) Power Button and Indicator When the external AC power supply with electricity, the indicator light is red. - Page 9 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (4) SDI Button and Indicator Press this button to select the current input source for SDI signal input, the indicator is blue. Press the button continuous, can select different SDI port: Single SDI (Port 1): Select SDI 1 video input channel...
-
Page 10: B．rear View
Shenzhen Konvision Technology Co,.Ltd www.konvision.com (13) USB Reserved port. (14) Speaker Speaker out. B．Rear View (1) AC IN AC power supply (2) SDI 1 (IN/OUT) 12G/6G/3G/HD-SDI input, output (3) SDI 2 (IN/OUT) 12G/6G/3G/HD-SDI input, output (4) SDI 3 (IN/OUT) 3G/HD-SDI input, output... - Page 11 Shenzhen Konvision Technology Co,.Ltd www.konvision.com (5) SDI 4 (IN/OUT) 3G/HD-SDI input, output (6) DVI IN (Max 4K/60p) DVI input: through HDMI convert DVI, input HDMI signal, Max support 4096x2160 60Hz (7) RS422 IN and RS422 OUT RS422 in and out. RS422 control adoptive TSL3.1 or TSL4.0 protocol. According to this...
-
Page 12: Sdi Input Connection And Display Mode
Shenzhen Konvision Technology Co,.Ltd www.konvision.com GPI Signal Description GPI1 When connect GND, GPI1 works, GPI1 function can be set in the menu function option GPI2 When connect GND, GPI2 works, GPI2 function can be set in the menu function option... - Page 13 Shenzhen Konvision Technology Co,.Ltd www.konvision.com SDI Port Select: SDI Key: press SDI key continuous, can select different SDI Port Single SDI (Port 1): select single SDI input, SDI 1 Port Single SDI (Port 2): select single SDI input, SDI 2 Port...
- Page 14 Shenzhen Konvision Technology Co,.Ltd www.konvision.com In Dual SDI (Port 1,2): 2-SI: SDI 1, SDI 2 two 6G SDI consist 4K 2-SI mode Quad View: the image displays quad mode. In the mode of two 6G SDI 1, SDI 2 signal input, the first 6G signal will display upper left and upper right of the image, the second 6G signal will display lower left and lower right of the image.
-
Page 15: Hdmi Input Connection And Display Mode
Shenzhen Konvision Technology Co,.Ltd www.konvision.com HDMI Input Connection and Display Mode Display Mode Select: MODE Key: press MODE key continuous, can select different display mode. HDMI: HDMI display full screen. Max support 4096x2160 60Hz resolution Quad View: when the HDMI resolution is 4K, 4K signal divide into four 1080P image display on the screen. - Page 16 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Status Display Menu item Description Input Source Display the current input source Input Format Display the current input format SDI Payload ID1 SDI Payload ID1 (Remark: HDMI without Payload ID) SDI Payload ID2 SDI Payload ID2 (Remark: HDMI without Payload ID)
-
Page 17: Function Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Display selected HDR mode IP Address Display factory default IP address; 192.168.1.155 DSP Version Display machine internal DSP software version information CPU Version Display machine internal CPU software version information Function Settings: Function Settings Sub Menu... - Page 18 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Audio Meter Voice (+) (Pattern Gen: When the function key is set to Voice (-) Pattern Gen, press this function key continuously Focus Assistant to produce solid color screens such as red / green False Color / blue / white.
-
Page 19: Marker Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Marker Settings: Marker Settings Sub Menu Settings Setting Option Description Marker Control Turn on all markers Turn off all markers Area Marker No Area Marker Area Marker ratio 4:3 15:9 Area Marker ratio 15:9 14:9... -
Page 20: Waveform
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 88％Safety Area 90％Safety Area 93％Safety Area Fit Marker Turn off Safety Area Marker Turn on Safety Area Marker Marker Mat Turn off Marker Mat Black Turn on Marker Mat as Black Gray Turn on Marker Mat as Gray... - Page 21 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Waveform Sub Menu Settings Setting Option Description Waveform Mode Turn off waveform LUMA Display LUMA waveform YCbCr Display YCbCr waveform Display RGB waveform Waveform Scale Digital Waveform scale is displayed numerically Waveform scale is displayed as a percentage...
-
Page 22: Aux Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com composed of 4 input channels in 4K mode Aux settings: Aux settings Sub Menu Settings Setting Option Description False Color Turn on False Color Turn off False Color Focus Assist Turn off Focus Assist Turn on Focus Assist as Red... -
Page 23: Color Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com the brightness in the picture reaches or exceeds this percentage, an alarm will occur and the alarm part will be overlaid with a red zebra crossing. H Flip Turn on H Flip Turn off H Flip... - Page 24 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Color Setting Sub Menu Settings Setting Option Description Limited Range（64-940） Select Limited (64-940) Mode Extended Range（64-1023） Select Extended (64-1023) Data Levels Full（0-1023） Mode Custom Select Full (0-1023) Mode Select Custom Mode Bypass Color Table Select Bypass...
- Page 25 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Slog2 to Rec709 Slog3 to Rec709 HDR to SDR Select turn on or turn off HDR Comparison (Note: This function is only HDR Comparison supported in SQD mode of single 12G / 6G-SDI and 4X 3G-SDI.)
-
Page 26: Video Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Temp Red Gain 0－255 Red Gain 0－255 Green Gain 0－255 Green Gain 0－255 Blue Gain 0－255 Blue Gain 0－255 Red Bias 0－255 Red Bias 0－255 Green Bias 0－255 Green Bias 0－255 Blue Bias 0－255 Blue Bias 0－255... -
Page 27: Source Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com original scale of the input signal. The screen is displayed as 1:1 Freeze Turn off Freeze WIN1 Select WIN1 Freeze WIN2 Select WIN2 Freeze WIN3 Select WIN3 Freeze WIN4 Select WIN4 Freeze Scan Mode Turn off Scan mode... -
Page 28: Audio Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Source Settings Sub Menu Settings Setting Option Description Window Select Quad Mode Win1 When SDI set in Quad SDI Quad Mode Win2 (Port 1,2,3,4) and Quad View Quad Mode Win3 at the same time, the users can... - Page 29 Shenzhen Konvision Technology Co,.Ltd www.konvision.com HDMI Audio Source select HDMI Output Channel CH1&CH2 Select audio output CH3&CH4 CH1&CH2 Channel CH5&CH6 Select audio output CH7&CH8 CH3&CH4 Channel CH9&CH10 Select audio output CH11&CH12 CH5&CH6 Channel CH13&CH14 Select audio output CH15&CH16 CH7&CH8 Channel Select audio output CH9&CH10 Channel...
-
Page 30: Cc Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com CH1-4 Select meter channel CH1-4 CH5-6 Select meter channel CH5-6 CH5-8 Select meter channel CH5-8 CH5-10 Select meter channel CH5-10 CH9-12 Select meter channel CH9-12 CH13-14 Select meter channel CH13-16 CH13-14 Select meter channel CH13-16... -
Page 31: Imd Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com 4K Mode Select single channel SDI3 Select single channel SDI4 Select 4K mode CC CC Mode Turn off CC Select 708 Mode Select 608 Mode 608 Caption Type CC 1 608 select CC 1 type... - Page 32 Shenzhen Konvision Technology Co,.Ltd www.konvision.com IMD Settings Sub Menu Settings Setting Option Description IMD Display Turn on IMD display Turn off IMD display IMD Color Green IMD character display green IMD character display red White IMD character display white IMD protocol TSL3.1...
-
Page 33: Osd Settlings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com OSD Tally select RG mode OSD Tally select GR mode OSD Tally select RGY mode LED Tally Source Select GPI Select Select TSL protocol control OSD Settlings: OSD Settings Sub Menu Settings Setting Option Description... -
Page 34: Key Lock
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Key Lock: Key Lock Sub Menu Settings Setting Option Description Key Lock Turn off Key Lock Turn on Key Lock... -
Page 35: Factory Settings
Shenzhen Konvision Technology Co,.Ltd www.konvision.com Factory Settings Use this feature, you can reset this monitor to factory settings. The factory settings can be restored when the following conditions occur on the monitor: 1． When the parameters of the monitors are misadjusted, enter the factory reset option and restore to factory setting 2．When the monitor's screen display or sound is not normal, you can enter the factory reset... -
Page 36: Remote Control
Remote control the monitor through Ethernet: 1. Connected with monitor via LAN, and you can achieve remote controlling by software “Konvision Device Controller”. (Network remote control software and instructions please contact with the dealer) 2．The network cable is a parallel cable connection Parallel line connection: Both ends are 568A standard or both ends are 568B standard. - Page 37 Shenzhen Konvision Technology Co,.Ltd www.konvision.com Warranty Card Postal User Code Address Product Serial Model Number Purchase Dealer Date Maintenance Record Replacement parts Contents of User Date Repairer Reparation Signature Name This warranty card should be filled in immediately when purchasing Please keep a proper record of this warranty card.
