- Page 1 V3.3.4 www.konvision.com USER MANUAL Konvision Monitor KFM-5X / 6X series LCD Monitors w w w k o n v i s i o n c o m...
- Page 2 Catalogue Histogram ........5 Notes..........2 Vector scope ....... 5 Notes 2 Over exposure ......5 Security .......... 2 Pixel Measurement ..... 5 Screen Maintenance ....2 Timecode ........5 Cabinet Maintenance ....2 Remote Control Function ... 5 Installation ........3 Parts and Functions ......
- Page 3 4. Please do not place vessels with liquid Please do not use packing materials provided by fault because of water droplets into the monitor. (such as cups, beverage bottles) on the suppliers except KONVISION or its authorized · Do not write on the screen. monitor.
- Page 4 10BIT Signal Processing PIP/PBP Scan Mode Vector scope - Signal input, signal processing and image - Two SDI inputs signals display simultaneously - Scan mode includes Full Scan, Over Scan, - Vector UV analysis for color bar signal input. output are 10bit data processing, to ensure the under PIP (picture in picture) and PBP(picture Under Scan.
-
Page 5: Parts And Functions
PIP/PBP Button RIGHT/VOLUME Button Parts and Functions Press this button for window layout among single, PIP, When entering the main menu operation, press this PBP mode. In PIP/PBP mode, one of the signals must button to select the sub menu to the right. be SDI1 input, the other can be any of SDI2, HDMI, When entering the sub menu operation, press this PC, Video, YPbPr, etc. - Page 6 KFM-1753W rear view port: Ethernet port for remote network control. Thought this port, along with software “Konvision Device Controller”, SDI2 IN/OUT you can achieve remote controlling to the monitor SDI2 inputs (3G/HD/SD-SDI auto detect), SDI Reclock easily.
- Page 7 Function Key: Picture: 2. Sub Menu: Sub Menu Description Status: Colour Temp Three modes of the fixed color . temperatures selection (5600K, 6500K, 9300K) and a custom selection. "Custom" is for user definition, to adjust the gain value and offset value of Red, Green and Blue.
- Page 8 Sub Menu Description Sub Menu Description Sub Menu Description Sub Menu Description Part Zoom in Zoom in any part of the picture, to Color Space [Bypass]Color Space Choose Headphone Volume Headphone volume adjustment. Audio Display Mode [Horizontal]Audio level meter Bypass. [Rec 709]Color Space watch picture details more clearly, ·...
- Page 9 Scope: Embedded code: (Only for SDI signal) Sub Menu Description Sub Menu Description Marker Enable [ON]All markers on. Vector Scale [100%]Vector 100% display. [OFF]All markers off. [75%]Vector zoom out to 75% · ON display. · OFF · 100% · 75% Marker Select [OFF]NO marker displays.
- Page 10 Sub Menu Description Sub Menu Description Sub Menu Description Sub Menu Description Layout [Single]Display only a single signal PIP position [Left Top]The second window Current Source The current signal rename display UMD Display Turn on/off the UMD display. picture on screen. [PIP]Display two in the left-top corner of screen.
- Page 11 Sub Menu Description Sub Menu Description Sub Menu Description Sub Menu Description Layout [TSL3.1]Select TSL3.1. Static Frame Alarm Turn off/on the static frame alarm. Format Display [OFF]Turn off the display info of Key Lock [OFF]Key Lock Off. [ON]When the key lock is turn on, [TSL4.0]Select TSL4.0.
- Page 12 1. Press the SWAP / 1: 1 button, the image is set IMAGEADJ (UP / DOWN) knob up / down function, “Konvision Device Controller”.(Network to 1: 1 display. then the operation will continue to move with a remote control software and instructions 3.
- Page 13 Note warranty card User Address Postal Code Model. No Serial Number Warranty Date Purchase Date Replacement parts Replacement parts Item Contents of Reparation Remark name quantity Repairer Signature Service hotline User Signature...
