- Page 1 KRM series Rackmount LCD Monitors USER MANUAL V2.0 Shenzhen Konvision Technology Co., Ltd http://www.konvision.com...
-
Page 2: Table Of Contents
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Contents Notes...........................3 Safety..........................4 Features........................6 Parts and Functions....................7 A: Front View..................... 7 B: Rear view....................14 Menu Operation Section..................19 Menu Operation:.....................19 Menu Item Description.................. 19 1. Main menu....................19 2. Sub Menu....................20 Status....................... -
Page 3: Notes
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Notes For the safety use of products, please read the following instructions regarding the installation, use and maintenance carefully. Please read the product safety and operating instructions carefully before the product is operated. Please keep the safety and operating instructions for future reference. -
Page 4: Safety
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com outlet. 15. Please keep not less than 5cm space around the vents while using the monitor, order to obtain good heat dissipation effect. Safety Screen Maintenance Please follow the below guidelines carefully to prevent discoloration, stains and scratches... - Page 5 Transportation This monitor is precise equipment and need professional packing materials to transport. So do not to use packing materials provided by suppliers except KONVISION or its authorized packing material suppliers. When the following situations occur, please turn off the power, do not insert the plug and contact a professional service staff to deal with timely.
-
Page 6: Features
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com If this device used in a cold environment, the screen may appear residual image. This is not a product failure, when the monitor temperature changes, screen will return to normal conditions. LCD screen may appear tiny spots (red, blue or green), this is not a fault, LCD screens are manufactured with high precision technology, and a small number of pixels may not be able to show intermittent. -
Page 7: Parts And Functions
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Marker Setting - Show frame borders, center marker, and safety area, etc. Scan mode - Scan mode includes Full Scan, Over Scan. Part Zoom In - Zoom in any part of the picture, to watch picture details more clearly, and assist for focus. - Page 8 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com (Note: same operation for the 2 front panels) KRM-404A and KRM-902A monitor front panel instructions: (1)Tally indicator It is controlled by the tally function of the RS232 port, with two colors red and green.
- Page 9 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Auto: The screen display scale is displayed in the original scale. Full Screen Display: The screen display ratio is displayed in full screen. 16：9：The screen display ratio is displayed as 16: 9. 1：1： The screen display ratio is displayed as 1: 1.
- Page 10 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com (10)Speaker Speaker output. KRM-503A monitor front view: KRM-503A monitor front panel description: (1)Tally light Red and green Tally lamps can be controlled via Ethernet, serial port, GPI. (2)POWER button and lights External power supply, press this button to turn on the monitor, the indicator turns blue.
- Page 11 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Press this button to select the input signal to be displayed. The following changes will occur to the input signal: SDI: Switches the SDI / Video interface to show the SDI signal. HDMI: Switch the HDMI connector to show HDMI signals.
- Page 12 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com function keys can be set in the menu options. (11)ENTER/F3 button Press to select the OK operation. While the menu is operating, press the ENTER button to enter the next menu or to confirm the selected parameter.
- Page 13 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com HDMI: Switch the HDMI connector to show HDMI signals. Video: Switches the SDI / Video interface to show the Video signal. (4)F1 button Function key F1, press main menu Function key to set. (5)F2 button Function key F2, press main menu Function key to set.
-
Page 14: B: Rear View
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com B: Rear view KRM-404A rear view: (Note: 1,2,3,4 each interface part corresponds to a screen) KRM-503A rear view: (Note: 1,2,3 each interface part corresponds to a screen) - Page 15 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com KRM-702A rear view: (Note: 1,2 each interface part corresponds to a screen) KRM-902A rear view: (Note: 1,2 each interface part corresponds to a screen) KRM-404A and KRM-902A rear view of monitor description: (1) SDI/Video input terminal SDI/Video input terminal can be used to input SDI signal or Video signal for monitoring.
- Page 16 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com (3) HDMI input HDMI input interface used to input HDMI signal for monitoring. (4) LAN1/2 Ethernet interface for network remote control. Through this interface, you can control the operation of screen 1 and screen 2 at the same time. You can also upgrade screen 1 and screen 2 programs.
- Page 17 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com the RS232 interface, control the first and the second screen UMD Pin 6 GPI1 Panel 4 Screen 4 corresponds to GPI1, when this pin is connected with GND, GPI1 works, GPI1 function can be set in menu GPI option.
- Page 18 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com be set in menu GPI option. Pin 4 Panel 3 Screen 3 and 4 of the RS232 interface TX, through & 4 the RS232 interface, control the first and the second screen UMD Pin 5...
-
Page 19: Menu Operation Section
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com For AC power input connection. (10) Speaker KRM-702A Monitor 1 Speaker. (11) Speaker KRM-702A Monitor 2 Speaker. Menu Operation Section Menu Operation: Press MENU to enter the main menu, then press UP or DOWN to switch between options in the same menu.Press ENTER to enter the next menu, and then press UP or... -
Page 20: Sub Menu
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Scope Embedded code Layout 2. Sub Menu: Status: Status Menu item Description Source Current window input signal Format Current window input signal format Color Temp Current color temperature Image Size The image size of the current window input signal... -
Page 21: Picture Setting
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Picture Setting: Picture Menu item Setting Description 0－100 Brightness Brightness Adjustment Contrast 0－100 Contrast Adjustment Sharpness 0－100 Sharpness Adjustment Colour 0－100 Saturation Adjustment 0－100 Color Adjustment Img.Adj:... - Page 22 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Img.Adj Menu item Setting Description Image Size FILL ASPECT original ratio of the signal source Full Screen Full screen image 1: 1 At 1:1 pixel-to-pixel display. It is invalid in PIP sub-screen and PBP mode.
-
Page 23: Colour
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Colour: Colour Sub menu items Setting Description Color space Do not choose Color space choice Bypass (KRM-404 no such REC 709 Color space choice REC 709 option) Colour Temp 3200K Color temperature has 4 kinds of 5600K fixed options（3200K，5600K，... -
Page 24: Audio
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Audio: Audio Sub Menu Items Setting Description 0－100 Volume Speaker volume adjustment Audio Level Turn on audio meter display Turn off audio meter display Audio Out channel CH1&CH2 Select SDI audio CH1 and CH2 channel output CH3&CH4... -
Page 25: Marker Setting
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Marker Setting: Marker Setting Sub Menu Items Setting Description Marker Enable All markers on All markers off Marker Select NO marker display Marker display 4:3 16:9 Marker display 16:9 15:9 Marker display 15:9 14:9... -
Page 26: Imd
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com 88% Safety Area display 90% Safety Area display 93% Safety Area display Marker Level White Maker line is white Gray Marker line is gray Dark Marker line is dark Marker Mat Turn off Fill up the background... - Page 27 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com from 0-255. UMD Char xxxxxxxx Static UMD display, UMD characters can be manually set. UMD characters can be arbitrarily set in 8 "xxxxxxxx". The setting process: Select the option to the UMD character option, press the...
-
Page 28: Scope
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Led Tally Turn on/off the LED Tally Tally Source Select GPI control Select TSL protocol control Scope: Scope (only for SDI/HDMI/DVI signal) Sub Menu Items Setting Description Luma Mode Turn on the Y brightness waveform... -
Page 29: Setup
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Vector Turn on/off vector Vector Scale 100% Vector 100% display Vector zoom out to 75% display TC Mode Turn Off TC Mode Time code display as LTC mode VITC1 Time code display as VITC1... - Page 30 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com adjustment Menu V Position 0-100 Menu vertical position adjustment Source Display Turn off Source Display Turn on Source Display Source Char xxxxx Source names can be customized The source name can be set freely in 5 "xxxxx".
-
Page 31: Gpi&Funckey
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com GPI&FuncKey: Sub Menu Items Setting Description AspectKey（F1） Image size ASPECT button can be customized Brightness into other function keys: ASPECT, Vector brightness, vector, TC code mode, TC code mode audio table display, Marker Audio table display... -
Page 32: Factory Reset
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com TC code mode audio table display, Markers Audio table display , color temperature Markers Color temp GPI0 Red Tally GPI0 button can be customized Green Tally into other function keys: Red Tally、 Green Tally 、 SDI 、 HDMI 、... -
Page 33: Product Structure Specification
Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com 1. Press MENU button to enter main menu. 2. Turn VOLUME knob to item Setup and select it. 3. Turn IMAGE ADJ knob to Factory Reset and select it. 4. The screen will refresh after following the instruction of turning the VOLUME knob. - Page 34 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Side view (mm) KRM-503A monitor size: Front view (mm) Top view (mm)
- Page 35 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Side view (mm) KRM-702A monitor size: Front view (mm) Top view (mm)
- Page 36 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Side view (mm) KRM-902A monitor size: Front view (mm)
- Page 37 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Top view (mm) Side view (mm)
- Page 38 Shenzhen Konvision Video Technology Co,.Ltd www.konvision.com Warranty Card User Postal Code Address Product Serial Model Number Purchase Dealer Date Maintenance Record Replacement parts Contents of User Date Repairer Reparation Signature Name This warranty card should be filled in immediately when purchasing Please keep a proper record of this warranty card.
