- Page 1 ICT DIN Series Power Supply Instruction Manual 855-361-000...
- Page 2 ICT DIN Series Power Supply SAFETY GUIDELINES Principles of Safe Operation and Maintenance Safety must always be the top priority of all personnel involved in the installation, operation, and maintenance of this unit as it operates at high voltages that could be potentially lethal. Technicians must adhere to the appropriate standards and manufacturer’s recommendations to minimize...
- Page 3 ICT DIN Series Power Supply General Alerts Risk of serious personal injury or damage to equipment and property. Always observe the following: • Install and operate unit in a restricted access location. A restricted access location is an area to which access can be...
- Page 4 • Consult with manufacturers of surge suppression devices to select appropriately rated protection device(s) and proper installation methods. • ICT’s product warranty does not cover damage caused by power surges and electrostatic discharge events including lightning. 855-361-000_Rev2.0_Instruction Manual...
- Page 5 • Lithium-ion battery support is available when the unit is CAUTION connected with an ICT DIN Series Power Distribution Unit. • If a lithium-ion battery is used, it must have an integrated battery management system (BMS) to protect the battery cells from inappropriate voltage or current levels.
- Page 6 Innovative Circuit Technology Ltd. Disclaimer ICT shall not be held liable for any damage or injury involving this product if it has been subjected to misuse and exposure to environmental conditions not conforming to the product’s limits of operation, improper installation, or maintenance.
- Page 7 ICT DIN Series Power Supply ICT LIMITED WARRANTY The warranty period on ICT products is two (2) years from date of purchase from an authorized ICT reseller or OEM with valid proof of purchase, or from date of shipment from the ICT manufacturing facility. The warranty period for a repaired product or part is ninety (90) days or the remainder of the unexpired term of the new product warranty period, whichever is greater.
- Page 8 ICT DIN Series Power Supply In no event shall ICT be liable for any special, indirect, or consequential damages such as, but not limited to, loss of use, business or goodwill, loss of revenue, or loss of profits, which may result, either directly or indirectly, from defects in products provided by ICT.
-
Page 9: Table Of Contents
ICT DIN Series Power Supply TABLE OF CONTENTS 1.0 INTRODUCTION ................... 1 Features ..................2 2.0 INSTALLATION ..................2 Unpacking and Inspection ............2 Package Contents ............... 2 2.2.1 Tools and Parts Needed ..........3 Quick Install Guide ..............3 System Configuration .............. - Page 10 ICT DIN Series Power Supply LIST OF FIGURES Figure 1. ICT DIN Series Power Supply ............. 1 Figure 2. Mounting unit on DIN Rail ............4 Figure 3. Demounting unit from DIN Rail ............ 4 Figure 4. Dual Load Output ................. 6 Figure 5.
-
Page 11: Introduction
ICT DIN Series Power Supply 1.0 INTRODUCTION The ICT DIN Series Power Supply is a DIN-rail mount DC power supply with integrated battery charging and Low Voltage Disconnect (LVD). The unit provides 360 watts of 48- or 24-volt DC output and features wide-ranging AC input, low-noise emissions, temperature-compensated charging, adjustable charge current, and form-C alarm contacts. -
Page 12: Features
• Form-C alarm contacts • Serial communication port for remote monitoring when used with ICT DIN Series Power Distribution Unit 2.0 INSTALLATION The following is the recommended sequence for the installation process. 2.1 Unpacking and Inspection Perform a physical check of the unit as it is being taken out of the box to ensure it has not been damaged during shipping. -
Page 13: Tools And Parts Needed
• Energize the loads and battery connections. 2.4 System Configuration When combined with the DIN Series Power Distribution Unit, remote monitoring and control of the power supply will be available using the Graphical User Interface (GUI). Table 3. Available Accessories Description Model No. -
Page 14: Figure 2. Mounting Unit On Din Rail
ICT DIN Series Power Supply 1. Push the unit towards the rail to engage the spring-loaded clip. Then push up as illustrated in the first drawing of Figure 2. 2. Pivot the device towards the rail so that the top hook clips into the mounting rail as illustrated in the second drawing of Figure 2. -
Page 15: Ground Connection
1. Install the 5-pin form-C alarm and temperature sensor wire clamp connector. 2. The ALARM connector allows the ICT DIN Series Power Supply to report faults to an external monitoring device through a form-C contact. If needed, connect form-C contact monitoring wiring to the ALARM connector as listed in Table 4. -
Page 16: Load Connections
ICT DIN Series Power Supply compensation can be adjusted through the GUI on the optional ICT DIN Series Power Distribution Unit. The default compensation is 5 mV/°C per cell (no compensation). Adjust this according to the battery manufacturer’s recommendation to enable charge voltage temperature compensation. -
Page 17: Battery Connections
The BATT connector provides a convenient and safe way to connect an external lead-acid or lithium-ion backup battery to the ICT DIN Series Power Supply. An internal 15-amp LVD contactor will disconnect the battery should it discharge below a set voltage level. -
Page 18: Installation Of The Breakers (Not Applicable)
ICT DIN Series Power Supply the optional ICT DIN Series Power Distribution Unit provides a suite of remote battery charge monitoring features. Install the battery as close to the power supply as possible to minimize cable lengths. Use 12–14 AWG wire. -
Page 19: Installation Of The Power Modules (Not Applicable)
2.11 Installation of the Power Modules (not applicable) 2.12 System Wiring Final Verification Check that all connections to the ICT DIN Series Power Suply are correct and properly tightened and all terminal blocks are firmly installed. 2.13 AC Power Source Connections... -
Page 20: Software Configuration (If Applicable)
ICT DIN Series Power Supply 2.14 Software Configuration (if applicable) Applicable when ICT DIN Series Power Supply is used with ICT DIN Series Power Distribution Unit. 2.15 Energize Loads and Battery Connections 1. De-energize the unit to allow safe modification of the connections;... -
Page 21: Operation: Standard Power Supply
Figure 5. Selector Dial and LEDs When AC power is present, the ICT DIN Series Power Supply will provide DC voltage to the connected loads and battery. In the event of an AC power... -
Page 22: Status Indicators And Alarms
ICT DIN Series Power Supply 6.2 Status Indicators and Alarms The two LEDs on the front of the unit, and the form-C alarm contact indicate the status of the power supply. The form-C alarm contact will be triggered for any condition that lights the red "FAULT" LED or shuts down the output of the unit. -
Page 23: Faqs
Section 4.0). 7.3 Can I mount the unit sideways? The ICT DIN Series Power Supply is convection cooled and is designed for maximum thermal performance when mounted upright where air vents are located at the top and bottom of the unit. Mounting the unit in other configurations is not recommended and may void the warranty. -
Page 24: Product Specifications
ICT DIN Series Power Supply 8.0 PRODUCT SPECIFICATIONS 8.1 Electrical Specifications Table 10. Overall Electrical Specifications Parameters Rating AC Input Nominal Rating 120 / 240 VAC 50 / 60 Hz AC Input Operating Range 108 to 264 VAC AC Input Maximum Range... -
Page 25: Physical Specifications
ICT DIN Series Power Supply 8.2 Physical Specifications Table 12. Physical Specifications Parameters Configuration Output Grounding Floating Alarm Output Form-C contact, 0.5 A 60 VDC max DC Connectors: (Output, 6-pin removable plug, cage clamp type 12–14 AWG Battery) Alarm / Temp Connector 5-pin removable plug, cage clamp type 22–26 AWG... -
Page 26: Figure 6. Dimensions
ICT DIN Series Power Supply Figure 6. Dimensions 855-361-000_Rev2.0_Instruction Manual Page 16 of 17... -
Page 27: Glossary
ICT DIN Series Power Supply 9.0 GLOSSARY • A, amps Amperes • Amperes (Root Mean Square) • Ampere-Hours • ANSI American National Standards Institute • American Wire Gauge • Battery Management System • Deutsche Institut fur Normung • Graphical User Interface •... - Page 28 Find the latest version of this manual here: https://ict-power.com/product/din-series-power-supply/ INNOVATIVE CIRCUIT TECHNOLOGY LTD. 26921 Gloucester Way Langley, British Columbia, Canada V4W 3Y3 T +1 604.856.6303 (International) T +1 877.930.0717 (North America Toll-free) www.ict-power.com...
