- Page 1 PRT-PSU-DIN-4A Protege DIN Rail 4A Intelligent Power Supply Installation Manual...
- Page 2 Copyright © Integrated Control Technology Limited 2003-2021. All rights reserved. Last Published: 30-Apr-21 3:58 PM PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 3: Table Of Contents
Core Temperature on Output Load Operation Inputs Trouble Inputs Outputs Online Mode Programmable Outputs Offline Mode AC Fail Status Output Battery Fail Status Output Intelligent Monitoring Monitoring Setup Address Configuration LED Indicators PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 4 UL and ULC Installation Requirements UL/ULC Installation Cabinet Options ULC Compliance Requirements CAN/ULC-S304 CAN/ULC-S319 CAN/ULC-S559 UL Compliance Requirements UL1610 UL294 FCC Compliance Statements Industry Canada Statement Disclaimer and Warranty PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 5: Introduction
900M (3000ft). Further span can be achieved with the use of a network repeater module. The current features of the power supply include: ⦁ Secure encrypted RS-485 module communications ⦁ Industry standard DIN rail mounting Online and remote upgradeable firmware ⦁ PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 6: Installation Requirements
The National Electrical Code, ANSI/NFPA 70 ⦁ The Canadian Electrical Code, Part I, CSA C22.1 ⦁ AS/NZS 2201.1 Intruder Alarm Systems ⦁ The Local Authority Having Jurisdiction (AHJ) ⦁ PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 7: Grounding Requirements
(RS-485 N+, N-, NA, NB) DIN Rail Enclosure Additional DIN Rail Enclosure(s) Controller Reader Expander Dialer’s Earth Ground Connection Input Expander Power Supply Output Expander AC Mains Wiring Earth Ground Link Connection PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 8 Sector or Building #3 Note that the DIN rail enclosure earth terminal is connected to the power supply V- terminal. There must be only one single earth grounding point per system. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 9: Mounting
When the tamper input is triggered, trouble input AExxx:01 on the power supply will be opened. Tamper Input Connection: V1+ V1+ V1+ V1+ V1+ Tamper Switch Bracket PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 10: Vibration Sensor
⦁ Terminals 1(V+) and 2(V-). 12V power connection, reverse polarity protected. Terminals 3 and 4. N.C. alarm output contacts, with built in 10 ohm resistor in series. ⦁ PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 11: Modes Of Operation
Make the electrical connections to the Shockgard SS-102, wired in series with the enclosure tamper switch 24HR monitor. If side cable entry is being used, remove the appropriate knockout from the cover and insert a grommet. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 12 Repeat this process until the unit only just responds to the desired impact. Replace the sensor cover, tighten the fixing screw and check its response to the desired impact. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 13: Wiring Diagram
Output current exceeded. Over Current Shutdown Activated. Output current exceeded maximum, approaching Over Current Shutdown. Output Current Green (All) Maximum output current level reached. Green (Partial) Indicated output current level reached. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 14: Mains Power
⦁ Extra care must be taken when wiring the AC inputs. Improper connection will cause permanent damage to the power supply. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 15: Backup Battery
Do not connect the battery wires or B+ and B- plugs of the module to any other ancillary device (siren, lock, mag clamp, etc.). ⦁ An incorrect connection may cause erroneous faults or serious damage to the module and will VOID ALL WARRANTIES OR GUARANTEES. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 16: Backup Battery Thresholds
Backup Battery Thresholds The battery disconnection threshold is 8V. Upon reconnection of mains power the power supply automatically detects the backup battery and begins controlled charging at 500mA (typical). PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 17: Encrypted Module Network
Technical Specifications section of this manual: Maximum total output current, ⦁ AUX DC output current, ⦁ Controller bell DC output current, and ⦁ Total combined current ⦁ PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 18: Module Wiring
NB terminals of the first and last modules on the RS-485 network. These are the modules physically located at the ends of the RS-485 network cabling. First Module on RS-485 Network Last Module on RS-485 Network 330R 330R From Next Previous Module Module PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 19: Output Load Connection
V1+ V1+ V1+ V1+ V1+ Note: The 1N4007 diode shown must be installed across the + and – terminals of any inductive load such as electric locks, magnetic or motorized devices. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 20: Output Current Influence On Output Load Operation
V1 and V2 outputs. Core Temperature Output Load Operation Status <70°C 70-80°C >80°C Outputs Enabled (Mains Power) Outputs Supplied by Battery Output Over-Current Failure Trouble Input Activated Over-Current Output Shutdown Activated PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 21: Inputs
The power supply emulates an analog expander module on the Protege module network. This means that all programming, trouble input and output information is stored in and reported by the analog expander records when programming via a Protege keypad or Protege software. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 22: Outputs
Upon restoring AC power, the output relay will revert back to its default state (normally closed). PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 23: Battery Fail Status Output
These outputs are rated for low power use only (50mA, 12V Max). Incorrect use may cause erroneous faults or serious damage to the power supply and will VOID ALL WARRANTIES OR GUARANTEES. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 24: Intelligent Monitoring
However, this will create a large number of events and should only be used for verifying the reception of data. For more information on programming this feature, see the Protege GX Operator Manual. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 25: Address Configuration
The controller has a set limit on the number of modules of each type that it can support. When adding and configuring modules always refer to the Maximum Module Addresses table in the controller installation manual. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 26: Led Indicators
V1 Output/V2 Output Indicators The V1 and V2 output indicators show the status of the 12VDC output. State Description On (green) 12VDC output operating OK Flashing (red) 12VDC output failure PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 27: Battery Indicator
Output current exceeded. Over Current Shutdown Activated Continuous flash Output current exceeded maximum, approaching Over Current Shutdown Constantly on (all indicators) Maximum output current level reached Constantly on (partial) Indicated output current level reached PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 28: Error Code Indication
The serial number in the device is not valid. Return the unit to the distributor for replacement. Locked Device The module or system controller is a locked device and cannot communicate on the network. Return the unit to the distributor for replacement. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 29: Mechanical Diagram
Mechanical Diagram The mechanical diagram shown below outlines the essential details needed to help ensure the correct installation of the power supply. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 30: Mechanical Layout
The mechanical layout shown below outlines the essential details needed to help ensure correct installation and mounting. All measurements are shown in millimeters. 156.80 Front 156.80 42.40 72.00 42.40 Back 139.18 PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 31: Technical Specifications
Integrated Control Technology continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.ict.co) for the latest documentation and product information. -
Page 32: Maximum Total Output Current: Ul And Ulc Installations
Note: the Maximum Total Output Current Available is the maximum current that can be supplied to the auxiliary and bell DC outputs. These are the maximum current values to ensure compliance with the standby requirements. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 33: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 34: European Standards
Power Supply Type A (EN 50130-4 ed. 2) Mains supply voltage variations (EN 50130-4 ed. 2) Mains supply voltage dips and short interruption (EN 50130-4 ed. 2, EN 61000-4-2 ed. 2) PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 35 To comply with EN 50131-1 only one battery can be connected and monitored per system. If more capacity is required a single larger battery must be used. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 36: Ul And Ulc Installation Requirements
Control units that support auto arming shall provide an audible signal throughout the protected area not less than 10 min prior to the auto arming taking place. The control unit shall allow authorized users to cancel PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 37 The Contact ID Reporting Service must be enabled and the Service Mode must be configured to start with the operating system. Refer to the section Contact ID in the Operator Reference Manual. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
- Page 38 Products or components of products, which perform communications functions only, shall comply with the requirements applicable to communications equipment as specified in CAN/CSA-C22.2 No. 60950-1, Information Technology Equipment Safety - Part 1: General Requirements. Where network interfaces, such PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 39: Can/Ulc-S319
Must be installed with CAN/ULC-S319 listed portal locking device(s) for ULC installations. ⦁ If a flexible cord is used to connect to line voltage, strain relief must be provided for the cord inside the PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 40: Can/Ulc-S559
If a flexible cord is used to connect to line voltage, strain relief must be provided for the cord inside the enclosure or at the knockout. The power supply is not intended to be mounted on the exterior of vault, safe, or stockroom. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 41 TROUxLE Programmable vOM4ST*TUS4r4Fx Output u4The4*v4F*IL4output4on4the4Power4Supply4MUST4be4programmed4to4follow4the4*v4Trouble4Input4as4followsD *v4F*IL4,4OPEN4on4fail u4Fire4areas4shall4be4separated4from4burglar4areas4through4area4partitioningi u4Fire4Inputs4ZoqZm4shall4be4used4exclusively4for4fire4monitoring4and4cannot4be4programmed4to4activate4the4bell4output u4Fire4Input4Z:4NiO4Push4xutton4to4be4used4as4monitoring4reset4switchi Typical4Input4vircuits EOL Resitor Input Configuration Niv4Input4vontact Value4o Value4l Monitored4Status Tamper Value4l Value4o Opene4vlosee4Tampere4Short Opene4vlosee4Tampere4Short Opene4vlosee4Tampere4Short Opene4vlosee4Tampere4Short Opene4vlosee4Tampere4Short Opene4vlosee4Tampere4Short 4uEOL4resistor4must4be4installed4at4the4Fire4*larm4vontrol4Panel4Outputi PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
- Page 42 All fire area inputs must be placed into an area and this area must be armed. Please refer to the section Inputs | Areas and Input Types in the Operator Reference Manual. ⦁ COM Status PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 43: Ul Compliance Requirements
The Contact ID Reporting Service must be enabled and the Service Mode must be configured to start with the operating system. Refer to the section Contact ID in the Operator Reference Manual PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 44: Ul294
If fire resistance is required for door assembly, portal locking device(s) must be evaluated to UL10B or ⦁ UL10C. Must be installed with UL 1034 listed electronic locks for UL installations. ⦁ PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... - Page 45 If a flexible cord is used to connect to line voltage, strain relief must be provided for the cord inside the ⦁ enclosure or at the knockout. ⦁ The power supply is not intended to be mounted on the exterior of vault, safe, or stockroom. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual...
-
Page 46: Fcc Compliance Statements
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 47: Industry Canada Statement
Industry Canada Statement ICES-003 This is a Class A digital device that meets all requirements of the Canadian Interference Causing Equipment Regulations. CAN ICES-3 (A)/NMB-3 (A) PRT-PSU-DIN-4A | Protege DIN Rail 4A Intelligent Power Supply | Installation Manual... -
Page 48: Disclaimer And Warranty
Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice. - Page 49 Disclaimer: Whilst every effort has been made to ensure accuracy in the representation of this product, neither Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
