Hybrid Power Series
Instruction Manual
855-350-000
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hybrid Power ICT-IPS-DC12-BMM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICT Hybrid Power ICT-IPS-DC12-BMM

Summary of Contents for ICT Hybrid Power ICT-IPS-DC12-BMM

  • Page 1 Hybrid Power Series Instruction Manual 855-350-000...
  • Page 2 Hybrid Power Series SAFETY GUIDELINES Principles of Safe Operation and Maintenance Safety must always be the top priority of all personnel involved in the installation, operation, and maintenance of this unit as it operates at high voltages that could be potentially lethal. Technicians must adhere to the appropriate standards and manufacturer’s recommendations to minimize hazards.
  • Page 3 Hybrid Power Series General Alerts Risk of serious personal injury or damage to equipment and property. Always observe the following: • Install and operate unit in a restricted access location. A restricted access location is an area to which access can be gained only by service personnel using a special tool, lock and key, or other means of security and which is controlled by the authority responsible for the location.
  • Page 4 • Consult with manufacturers of surge suppression devices to select appropriately rated protection device(s) and proper installation methods. • ICT’s product warranty does not cover damage caused by power surges and electrostatic discharge events including lightning. 855-350-000_Rev2.01_Instruction Manual...
  • Page 5 Hybrid Power Series NOTE: Due to the breaker-detection circuitry internal to the unit, it may be possible to measure a voltage on the terminal(s) with no load connected, even if that terminal’s breaker is open circuit. This is normal operation. The breaker-detection circuitry is a high- impedance circuit, and while a voltage may be present on the output terminal, it is a signal voltage and does not support loading.
  • Page 6 Innovative Circuit Technology Ltd. Disclaimer ICT shall not be held liable for any damage or injury involving this product if it has been subjected to misuse and exposure to environmental conditions not conforming to the product’s limits of operation, improper installation, or maintenance.
  • Page 7 Hybrid Power Series ICT LIMITED WARRANTY The warranty period on ICT products is two (2) years from date of purchase from an authorized ICT reseller or OEM with valid proof of purchase, or from date of shipment from the ICT manufacturing facility. The warranty period for a repaired product or part is ninety (90) days or the remainder of the unexpired term of the new product warranty period, whichever is greater.
  • Page 8 Hybrid Power Series In no event shall ICT be liable for any special, indirect, or consequential damages such as, but not limited to, loss of use, business or goodwill, loss of revenue, or loss of profits, which may result, either directly or indirectly, from defects in products provided by ICT.

  • Page 9: Table Of Contents

    Hybrid Power Series TABLE OF CONTENTS 1.0 INTRODUCTION ................... 1 System Components and Features ..........1 1.1.1 Intelligent Control Module (ICM) ........2 1.1.2 Power Module ..............2 1.1.3 Battery Management Module (BMM or BMMD) .... 2 1.1.4 DC-DC Converter Module ..........2 1.1.5 Power Shelf ..............
  • Page 10 Hybrid Power Series 4.0 OPERATION: GRAPHICAL USER INTERFACE ....... 35 Log In/Log Out ................35 System ..................36 4.2.1 STATUS ............... 36 4.2.2 SETTINGS & CONTOL ..........38 Power Modules ................39 DC Converter ................40 4.4.1 STATUS ............... 40 4.4.2 SETTINGS &...
  • Page 11 Hybrid Power Series Figure 5. Installing Power Module in a Hybrid Power Series ......... 11 Figure 6. The DC Output Bus Bars ................ 14 Figure 7. The 24-volt DC-DC Converter Module Output Bus Bars ......14 Figure 8. Primary and Secondary Shelf Connected in Parallel ......15 Figure 9.

  • Page 12: Introduction

    Hybrid Power Series 1.0 INTRODUCTION The Hybrid Power Series is a flexible, N+1 redundant DC power system with intelligent networked control, advanced battery management, and a 12- or 24-volt integrated DC-DC Converter Module in a 1RU rack mount chassis. The power shelf features a factory-installed Intelligent Control Module (ICM) with front graphic display and up to two parallel-connected hot-swappable 700- or 1,500-watt, 24- or 48-volt Power Modules, for a combined 3,000 watts or 108 amps continuous output rating.

  • Page 13: Intelligent Control Module (Icm)

    Hybrid Power Series 1.1.1 Intelligent Control Module (ICM) • High resolution OLED display with intelligent front panel controls fully integrated into power shelf • TCP/IP Ethernet communications port • Embedded web server with easy-to-use graphical user interface (GUI) • Intelligent monitoring, reporting and control of system and all installed modules •...

  • Page 14: Power Shelf

    • Six bolt/washer/nut sets for connections to the output bus bars (in bag) • Remote battery temperature sensor (ICT-TMP) included when a BMM or BMMD is installed in the system (in bag) 2.2.1 Tools and Parts Needed • Two 7/16-inch wrenches •...

  • Page 15: Quick Install Guide

    (negative V output) (positive V output) Intelligent Power Shelf with Control Module, a 700 W 12 V integrated DC-DC Converter Module, and a ICT-IPS-DC12-BMM ICT-IPS-DC12-BMMP single 100 A battery disconnect breaker and 150 A and Low Voltage Disconnect 855-350-000_Rev2.01_Instruction Manual...

  • Page 16: Table 3. Power Module Models

    ICT-IPS-DC24-BMMDP dual 100 A battery disconnect breaker and 150 A and Low Voltage Disconnect NOTE: Contact ICT for other possible Hybrid Power Series configurations. Table 3. Power Module Models Description Model No. 24 V, 700 W Power Module (27.6 V, 25 A) ICT700-24PM 48 V, 700 W Power Module (55.2 V, 12.5 A)

  • Page 17: Rack Mounting

    De-energize the system before making any change to the wiring and connections. WARNING All DC outputs of ICT’s DC power systems are isolated from chassis ground (floating). DC output returns can remain isolated from ground (DC-I) or can be grounded (DC-C), as per site grounding requirements and/or local or national electrical codes.

  • Page 18: Sensor And Alarm Connections

    (ICT-JMP). If the ICT-JMP is connected, both primary shelf contacts and secondary shelf contacts are flagged for all system alarms. If the ICT-JMP is not connected, the primary shelf contacts are flagged for all system alarms while the secondary shelf contacts indicate secondary power module faults only.

  • Page 19: Battery Connections

    Hybrid Power Series Mount the sensor to the mid-level side of the middle battery in a battery bank using the adhesive-backed clip. The rate of voltage compensation can be adjusted through the ICM front display panel interface, or the GUI in the Battery Backup Settings section. The default compensation is 0 mV/C per cell (no compensation).

  • Page 20: Table 7. Default System Output Settings

    Hybrid Power Series • Check shelf model polarity before connecting a battery to the BMM. • Only use the Equalize Charge setting for flooded lead-acid batteries in a well-ventilated location. Do not use Equalize Charge on sealed batteries. Always consult with battery manufacturer observe battery...

  • Page 21: Installation Of The Breakers (Not Applicable)

    Hybrid Power Series 2. Verify the polarity of the BMM installed in the unit by noting the label under the rear BMM BAT bus bar input. The "BAT +" indicates a positive battery voltage system with the LVD contactor and battery breaker internally connecting this terminal to the shelf "+"...

  • Page 22: Installation Of The Power Module

    Power Modules exceeds the total requirement of the planned load by at least 700 watts (or 1,500 watts if using ICT 1500-watt Power Modules). NOTE: N+1 operation requires excess power module capacity to ensure that the load can be fully powered, even if one Power Module should fail or be removed.

  • Page 23: System Wiring Final Verification

    (the shelf may be powered while swapping modules). The latch is located under the module handle (see Figure 5). 4. Install an optional blanking plate (ICT-BPM) into any unused Power Module positions to prevent accidental access to the internal circuitry of the system.

  • Page 24: Software Configuration

    DC-AC inverter in this way may void the product warranty. Do not connect DC-AC inverters to the outputs of the Load Distribution Module of the ICT units. 1. De-energize the unit to allow safe modification of the connections. 2. Make connections to the load using wire and connectors appropriately rated for the maximum output current capability of the unit.

  • Page 25: Figure 6. The Dc Output Bus Bars

    Hybrid Power Series Table 11. Load Connection Points Load Connection Points Features Full current rating of the shelf is available to Directly from main shelf DC output operate the load, limited only by the maximum bus bars output capability of the combined Power Modules Integrated DC-DC Converter Module Fully isolated, 12 V or 24 V, 700 W maximum output bus bars...

  • Page 26: Energize Loads And Battery Connections

    Bars ICT-PAR Cable ICT-JMP Figure 8. Primary and Secondary Shelf Connected in Parallel NOTE: Please review the ICT Hybrid Ultra Series of power systems for the pre-configured 2RU power system with up to 7,500 watts of DC power. 855-350-000_Rev2.01_Instruction Manual...
  • Page 27 1. Install the Shelf Paralleling Bus Bars (ICT-PAR) and plastic bus bar covers using the hardware included with the Hybrid Power Series. 2. Install the Parallel Control Cable (ICT-JMP) connecting the two RJ11 style SHARE ports as shown in Figure 8 to allow the primary ICM to control the secondary shelf.

  • Page 28: Operation: Front Display Panel

    Hybrid Power Series 3.0 OPERATION: FRONT DISPLAY PANEL Switch on the external AC power source circuit breaker; check that the green POWER LED is lit on each power module; and that the Intelligent Control Module (ICM) front graphic display is lit. The Hybrid Power Series will start up and operate at the factory default settings when AC power is connected, generally requiring no other set up or adjustment for basic operation.

  • Page 29: Menu Structure

    Hybrid Power Series 3.2 Menu Structure See the complete menu structure in the following diagram. Navigate through the various screens using the four interface buttons. MAIN SCREEN SYSTEM STATUS SYSTEM SETTINGS INPUT VOLTAGE 120V OUTPUT VOLTAGE 55.2V ADJUST SETTINGS OUTPUT VOLTAGE 55.2V CURRENT LIMIT OUTPUT CURRENT...

  • Page 30: System Status

    Hybrid Power Series ALARM INPUTS ALARM INPUT 1 ALARM ALARM INPUT 2 READY ALARM INPUT 3 READY ALARM INPUT 4 READY ALARM HISTORY ALARM HISTORY MODULE #4 ALARM MODULE #4 ALARM Scrol l through to s ee up to 20 Battery Breaker Open Battery Breaker Open mos t recent a larm events.

  • Page 31: Battery Management Module

    Hybrid Power Series • The Output Current will be flashing if the unit is operating at the set Current Limit. Press Enter to move to the System Settings. System Settings The Output Voltage and Output Current Limit settings come with factory default values that should be adjusted to match the actual system and battery float voltage requirements, as shown below: Scroll to highlight the parameter to change.
  • Page 32 Hybrid Power Series The SOC% is estimated by counting the ampere-hours (Ah) flowing into and out of the battery while knowing the nominal rated capacity of the battery. The system resets the SOC to 100% whenever it detects that the battery is at the rated Float Voltage with minimal charge current for at least 24 hr.

  • Page 33: Table 13. Default Disconnect Voltage Settings

    Hybrid Power Series Scroll to highlight the parameter or sub- menu to change. • LVD Disconnect V • LVD Reconnect V • Charge Current Limit • Overcurrent Alarm level • Battery Type • Battery Capacity (Ah) rating • Battery discharge rate (hrs.) used for capacity spec.

  • Page 34: Table 14. Default Reconnect Voltage Settings

    Hybrid Power Series Table 14. Default Reconnect Voltage Settings Module ICT700-24PM ICT700-48PM ICT1500-24PM ICT1500-48PM Threshold Voltage 25.0 VDC 50.0 VDC Table 15. The Minimum Difference Between Disconnect and Reconnect Voltage 24 VDC Units 48 VDC Units CHARGE CURRENT: Set the "Battery Charge Current Limit" to limit the maximum battery charge current provided, while still allowing the full rated current to be drawn from the main output.
  • Page 35 TEMP-CO/cell (only available for lead-acid batteries): Ensure the Battery Temperature Sensor (ICT-TMP) is installed and connected to the battery case (see Section 2.7) for optimal lead-acid battery charging and best battery life. Set the "Temperature Compensation/°C" level per battery cell to match the recommendation of the battery manufacturer (−4 mV/°C per cell is typical).
  • Page 36 Hybrid Power Series Scroll to highlight parameter in selected sub-menu. • Voltage • Duration • Status (display only) Press Enter to select. Use the Up/Down buttons to adjust setting, press Enter to set value and return to previous screen. Press Back to return to previous screen without saving changes.

  • Page 37: Integrated Dc-Dc Converter Module

    Hybrid Power Series Use the Up/Down buttons to adjust setting, press Enter to set value and return to previous screen. Press Back to return to previous screen without saving changes. NOTE: A Battery Discharge Test of a fully charged battery can be manually initiated by changing the discharge test Status parameter to "Enabled".

  • Page 38: Alarm Inputs

    Hybrid Power Series 3.2.4 Alarm Inputs The Alarm Inputs Status screen displays the status of the four alarm inputs provided on a unit equipped with the ICM. Use these inputs to monitor voltage free external contact closures such as door sensors, smoke alarm outputs or a water sensor.

  • Page 39: Network Status And Advanced Options

    Hybrid Power Series Press Enter to see Alarm History log. Scroll through the history screens to see the 20 most recent Alarm events. Shows the module that raised the alarm, date, and time when set, and cleared. NOTE: The system date and time are normally set by the network. These may be manually set, see GUI, Communications Basic Setup tab (see Section 4.7.1).
  • Page 40 Hybrid Power Series LCD PASSWORD SETUP: Set or clear a 4-digit LCD password to lock out the ICM Display adjustments after the LOCKOUT TIMER has expired. Set the display Lockout Timer duration from 0 to 60 minutes. Once the password has been set, it will be required to access all settings screens.

  • Page 41: Notification Screens

    Hybrid Power Series DEVICE INFORMATION: The Device Information screen displays the part family, installed firmware version, hardware version, and the serial number. Press Enter button. Press Back button or Enter return to the previous screen. 3.2.7 Notification Screens Alarm Notification When the unit triggers an alarm, the front display panel will be over-written by the Alarms Active screen.

  • Page 42: Password Reset

    Hybrid Power Series 3.3 Password Reset NOTE: Always record the LCD password when set, as it must be entered to change any supply settings using the front display panel. Do the following to clear the LCD password in cases where it is lost: 1.

  • Page 43: Table 17. Power Module Alarms

    Hybrid Power Series Table 17. Power Module Alarms Alarm Trigger Condition Module Green Alarm Send Condition Output Relay E-mail Loss of AC power Power Failure Disabled Active to module Module Normal operation Enabled Operating Configuration Different voltage Enabled Error modules installed Current Limit Output current (Warning only,...

  • Page 44: Table 18. Battery Management Module (Bmm) Alarms

    Hybrid Power Series Table 18. Battery Management Module (BMM) Alarms Alarm Alarm Send Trigger Condition Condition Contactor Required Relay E-mail Module Power Loss of AC, and battery Open Failure disconnected No Alarms Normal Operation Closed Battery Low SOC drops below Low Closed Active SOC setting...

  • Page 45: Table 20. Intelligent Control Module (Icm) Alarms

    Hybrid Power Series Alarm Module Green Alarm Send Trigger Condition Condition Output Relay E-mail Input Voltage DC input voltage Disabled Active Failure out of range Internal aux Module Fault voltages out of Disabled Active range Over Temp Internal temp too Disabled Active Shutdown...

  • Page 46: Operation: Graphical User Interface

    NOTE: Take note of the assigned IP address displayed and use this in the browser address field to access the unit remotely. The IP address of any ICT unit on a local network can be found by running the ICT "IP Address Discovery tool", after installing it on a Windows computer connected to the same network (tool available for download from ICT http://www.ict-power.com/resources/tools-...

  • Page 47: System

    Hybrid Power Series 4.2 System Once successfully logged in, the System tab will be shown in the browser. 4.2.1 STATUS This tab provides the operating status of the unit. DC Output Output Status: Shows status of the DC output. Will show Enabled if providing DC output or Disabled if not.
  • Page 48 This number represents both batteries if this is a dual BMM (BMMD). Battery Temperature: Shows the temperature measured on the optional ICT Battery Temperature Probe (ICT-TMP). Net Ah Count: Shows the Ah that have been consumed from the battery. Will display 0 Ah if the batteries are fully charged.

  • Page 49: Settings & Contol

    Hybrid Power Series Module #x: 12/24V DC Converter This section will show the status of the Integrated DC-DC Converter Module — section will be labelled with the module number and output voltage of the DC-DC Converter Module. Output Voltage: Shows the output voltage of the Integrated DC-DC Converter Module.

  • Page 50: Power Modules

    Hybrid Power Series Auto-Restart Button: Use this button to momentarily shut off the main output, and then restart automatically after a time delay (set in the "Auto- Restart Delay" field) This feature can be used to remotely force connected equipment to re-boot. Output Settings Output Voltage: Set the system "Output Voltage"...

  • Page 51: Dc Converter

    Hybrid Power Series The graphic will display green for an installed power module that is working as expected; a red display for an installed power module that has an active alarm; and will be grey when a power module is not installed in that slot. Module Status Shows the slot that the power module is installed in;...

  • Page 52: Settings & Control

    Hybrid Power Series Module #x: 12/24V DC Converter Output Voltage: Shows the output voltage of the Integrated DC-DC Converter Module. Output Current: Shows the output current of the Integrated DC-DC Converter Module. Output Status: Shows the status of the output of the Integrated DC-DC Converter Module.

  • Page 53: Battery Backup

    Hybrid Power Series Table 21. The Default Output Voltage and Current 12 V 24 V DC-DC Converter Module DC-DC Converter Module Default Output Voltage 13.8 V 27.6 V Default Output Current 50 A 25 A Current Limit: Set the integrated DC-DC Converter Module "Current Limit"...

  • Page 54: Status

    This number represents both batteries if this is a dual BMM (BMMD). Battery Temperature: Shows the temperature measured on the optional ICT Battery Temperature Probe (ICT-TMP). If no probe is installed, the unit will default to 25°C. Net Ah Count: Shows the Ah that have been consumed from the battery.

  • Page 55: Settings & Contol

    Hybrid Power Series LVD Reconnect Voltage: Shows the battery voltage when the LVD will reconnect the battery. LVD Status: Shows the status of the LVD (Open or Closed). Alarm Status: Shows status of the batteries (Alarm or OK). 4.5.2 SETTINGS & CONTOL This tab is used to adjust the settings of the BMM.
  • Page 56 The default setting is 0 mV/C. NOTE: The system must have the battery temperature sensor (ICT- TMP) installed on the battery for this setting to have an effect (default setting is 0 mV, assumes 25°C operation).

  • Page 57: Table 22. Default Equalize Voltage Settings

    Hybrid Power Series Risk of serious personal injury or damage to equipment and property! Always observe the following: • Equalize charging is intended for flooded lead-acid batteries only and may produce higher than normal levels of hydrogen gas. • Consult with the battery manufacturer when using SLA batteries.
  • Page 58 Hybrid Power Series Equalize Interval: Set the time in days (0–180 days) between automatic equalize charges. Set this time to 0 to disable the automatic equalize charge. The default setting is 0 (Disabled). Day of Week: Set the day of the week that the automatically recurring equalize charge should take place or select "Any"...

  • Page 59: Table 23. Default Disconnect Voltage Settings

    Hybrid Power Series voltage. The battery is reconnected when AC power is restored or after recharging to a preset threshold. Disconnect Voltage: Set the threshold to a level that will protect the battery from excessive discharge (as recommended by the battery manufacturer).

  • Page 60: Table 26. Deeply Discharged Battery Values (Typical)

    Hybrid Power Series This setting will be used when charging the battery from an external DC source (such as a solar system), otherwise once AC power returns the LVD contactor will automatically close so that the Power Modules can charge the battery directly. NOTE: Deeply discharged batteries will not be reconnected as a safety measure.
  • Page 61 Hybrid Power Series Battery Discharge Test (only available on lead-acid batteries) Configure the Battery Discharge Test settings in this section to either manually or automatically perform a partial discharge test to gauge the relative capacity of the external lead-acid battery. Limit the depth of discharge to no more than 50% of the nominal battery capacity to avoid stressing the battery due to a deep discharge.

  • Page 62: Table 27. Default Discharge Voltage Limit Settings

    Hybrid Power Series This test must only be done when AC power is present during the test and for adequate time after the test to allow for a full recharging of the battery. Otherwise, the battery may not have sufficient remaining capacity to power the load during an AC NOTICE power outage.

  • Page 63: Alarms

    Hybrid Power Series Manual Discharge Test: Press this button to manually initiate a Battery Discharge Test of a fully charged battery. NOTE: System will state that the discharge test is Not Ready if the battery SOC is less than 100%. Last Battery Discharge Test: Shows the date and time that the last discharge test was performed.

  • Page 64: Status

    Hybrid Power Series 4.6.1 STATUS This tab shows all active alarms and up to 32 historic alarms. The history will be cleared after the ICM is rebooted. Active Alarms Shows the module that the alarm is on; the name of the alarm; the time that the alarm started and the status of the alarm (ACTIVE).

  • Page 65: Communications

    Hybrid Power Series Alarm Input # Alarm Name: Set a meaningful name to suit the installation (these will be used for e-mailed alarm messages). Contact Type: Set the form-C behavior for each device to be monitored. (Not Used, Normally Open, Normally Closed) Select Not Used for all unused alarm input channels.
  • Page 66 Hybrid Power Series Model: Shows the model number, series name, and voltage configuration. Hardware: Shows the hardware version. Serial Number: Shows the serial number. Date and Time Settings Current System Time: Shows the current system date and time. Synchronize with NTP Server: Select the check box to synchronize with NTP Server.
  • Page 67 Hybrid Power Series Primary IP Address: Set a primary IP address for the unit to ping to determine whether the network is functioning. Secondary IP Address: Set a secondary IP address for the unit to ping to determine whether the network is functioning. Watchdog Timeout: Set a time in minutes (1–80 minutes) for the unit to wait with no ping response from either IP address before initiating a reset.

  • Page 68: Network Setup

    Hybrid Power Series 4.7.2 NETWORK SETUP Use this tab to configure the unit’s network settings. Saving any changes to the network settings will cause the ICM to re-start, causing momentary loss of communications. NOTICE Network MAC Address: Shows the MAC address assigned to the unit. It is also shown on the LCD Network Status screen.
  • Page 69 The information available from the SNMP agent is described in a MIB (Management Information Base) file, which can be downloaded from the ICT website: https://ict-power.com/resources/tools-utilities/. The MIB file can also be downloaded from within the GUI. There are links in the SNMP section of the Communications Network Setup tab and on the Help tab.
  • Page 70 SNMP. This setting requires a different MIB file which can downloaded from Website: https://www.ict- power.com/resources/tools-utilities/. SNMP Contact Information: Set contact information, such as an operator name and phone number for the unit, which can be read via SNMP queries (this information is optional).
  • Page 71 Hybrid Power Series v1/v2c Settings Read Community: Enter the community string/password here for read- only SNMP access. The default read community string is "public". Write Community: Enter the community string/password here for read/write SNMP access. The default write community string is "write". NOTE: The community strings should be changed to unique passwords before enabling SNMP, as the defaults are well known.

  • Page 72: E-Mail Setup

    Hybrid Power Series Trap User Name: Set the username for SNMPv3 traps. This field is only used for v3 traps. Authentication Protocol: Set the authentication protocol for SNMPv3 traps (None, MD5, or SHA). Authentication Password: If an authentication protocol is selected, set the authentication password for SNMPv3 traps.
  • Page 73 Hybrid Power Series E-mail SMTP Server: Set the name or the IP address of the SMTP server used for sending outgoing e-mail (e.g., “smtp.gmail.com”). SMTP Port: Set the port used by the SMTP server. The default setting is 25. SMTP Server requires SSL: Select this check box if the SMTP server requires an encrypted SSL connection.

  • Page 74: User Setup

    Hybrid Power Series A Power Module failure occurs: Select this check box to receive an e-mail notification when any of the installed Power Modules stop functioning. A Module is offline: Select this check box to receive an e-mail notification when a module loses communication with the ICM. System Current Limit is triggered: Select this check box to receive an e-mail notification when the "Total System Current"...
  • Page 75 Hybrid Power Series Record the new password(s) for future access. If the Administrator password is lost the unit must be reset to return the password to the blank default setting, causing loss of all other NOTICE user settings (see Section 3.3). User Accounts Shows the User Name and Access Level.

  • Page 76: Maintenance

    Hybrid Power Series Add New User User Name: Set user name. Access Level: Set access level. Password: Set password. Password (confirm): Confirm password. Confirm Changes User Name: Enter admin user name to confirm these changes are valid. Password: Enter the password for the admin name to confirm the changes are valid.
  • Page 77 Hybrid Power Series Use this tab to reset the unit (soft reset), restore the factory default settings, or send a test e-mail to verify e-mail functionality. Reset Intelligent Controller Module Select the "Reset" button to restart the ICM. All other settings are maintained during the reset.
  • Page 78 Hybrid Power Series Firmware Update Download the latest Hybrid Power Series firmware file from the ICT website (ict-power.com) to a local computer. Select the "Update Firmware" button to access the Firmware Update page shown below. Use this page to update the firmware on the power system control module by clicking the "Choose...

  • Page 79: Help

    4.8 Help This tab has helpful links to ICT’s website. Instruction Manual Click the "HERE" button to download the ICT Hybrid Power Series Instruction Manual from ICT website. SNMP Click the "HERE" button to download the SNMP MIB file.

  • Page 80: Operation: Parallel (Not Applicable)

    7.3 How do I access the web-based configuration utility? • Check the correct IP address for the system by downloading and running the ICT IP Address Discovery tool from http://www.ict- power.com/tools-utilities/. • Check the network cable connections to the unit and the network.
  • Page 81 Hybrid Power Series 7.4 How do I reset my password? • Reset the GUI password back to the factory default (user: admin, no password) by selecting the RESET COMM SETTINGS in the Network Status front display panel menu (see Section 3.2.6). •...
  • Page 82 Hybrid Power Series Cell address formats for some common North American mobile phone providers: AT&T cellnumber@txt.att.net Verizon cellnumber@vtext.com T-Mobile cellnumber@tmomail.net Virgin Mobile cellnumber@vmobl.com Bell Mobility cellnumber@txt.bell.ca Rogers cellnumber@pcs.rogers.com Telus cellnumber@msg.telus.com Virgin Mobile (Can) cellnumber@vmobile.ca Verify formatting with the mobile provider. NOTICE 7.7 How do I upgrade the firmware? See Section 4.7.5 in the user manual.

  • Page 83: Product Specifications

    Hybrid Power Series 7.11 How do I log out of the GUI? To log out of the ICT Hybrid Power Series GUI, click on the Logout link on the top right of the browser window. The system will also automatically log off the user after 20 minutes of inactivity.

  • Page 84: Table 30. Integrated Dc-Dc Converter Module Specifications

    Hybrid Power Series Power Parameters 700- 700- 1500- 1500- Shelf 24PM 48PM 24PM 48PM Output Current (continuous) 54 A 25 A 12.5 A 32 A 16 A (115 VAC) Output Derating 2% / °C (above 50°C) Efficiency (peak) Output Noise 30 mV 60 mV 40 mV...

  • Page 85: Physical Specifications

    Hybrid Power Series 8.2 Physical Specifications Table 31. Physical Specifications Parameters Configuration Power Modules are floating, may be connected with Positive Output Grounding or Negative ground Alarm Output Form-C contact, 0.5 A 60 VDC max DC Connectors: (Output, Bus Bar, 5/16-inch bolt hole Battery) Alarm Output Connector 3-pin removable plug, cage clamp type 16–24 AWG...

  • Page 86: Mechanical Specifications

    Hybrid Power Series 8.4 Mechanical Specifications Table 33. Dimension and Weight Physical Property Value Dimension - L x W x H 15.3 x 19.0 x 1.7 in. (388 x 483 x 44 mm) Weight 21 lbs. (9.4 kg) maximum Weight of unit as shipped with BMM and DC-DC Converter Module. No Power Modules. Figure 12.

  • Page 87: Glossary

    Hybrid Power Series 9.0 GLOSSARY • One Rack Unit; 1.75-inch (44.55 mm) of rack height • Two Rack Unit; 3.5-inch (89 mm) of rack height • A, amps Amperes • Amperes (Root Mean Square) • Advanced Encryption Standard • Ampere-Hours •...
  • Page 88 Find the latest version of this manual here: https://ict-power.com/product/hybrid-power-series/ INNOVATIVE CIRCUIT TECHNOLOGY LTD. 26921 Gloucester Way Langley, British Columbia, Canada V4W 3Y3 T +1 604.856.6303 (International) T +1 877.930.0717 (North America Toll-free) www.ict-power.com...

This manual is also suitable for:

Hybrid power ict-ips-dc12-bmmpHybrid power ict-ips-dc12-bmmdHybrid power ict-ips-dc12-bmmdpHybrid power ict-ips-dc24-bmmHybrid power ict-ips-dc24-bmmpHybrid power ict-ips-dc24-bmmd ... Show all

Table of Contents
