5. First release the piston for the memory location (in this example 3) and only then the
SET-piston.
6. 'Close' the memory by turning key switch MEMORY LOCK a quarter of a turn to the left
(taking the key from the switch, if necessary).
7. Write the just programmed capture combination (e.g. M2-3) on the piece of music in
which this registration is to be used.
Your personal registration is now stored in memory group 2 at location 3.

Lighted capture system with 7-segment display

A lighted capture system with 7-segment display is programmed as follows:
1. If you have an instrument with a programmable general crescendo pedal and / or
programmable MIDI, first make certain that the thumb pistons GC and PG(M) are not
pressed. This is to avoid accidentally changing a general crescendo or a programmed
MIDI-stop setting.
2. 'Open' the capture memory by turning key switch MEMORY LOCK a quarter of a turn
to the right. The SET-piston will now light up as a sign that the capture memory is 'open'
3. Select the required registration to be stored into the capture memory.
4. Select a memory group (e.g. memory group M6) by pressing the – or the + piston once
or several times until the display shows the correct memory group (in this example the
number 6).
5. Press SET (hold it) and next select the memory location (press e.g. piston 3). The
display will briefly show the letter P as a sign that the selected registration is being
programmed into the capture memory.
6. First release the piston for the memory location (in this example 3) and only then the
SET-piston.
7. 'Close' the capture memory by turning key switch MEMORY LOCK a quarter of a turn
to the left (taking the key from the switch, if necessary). The lamp in the SET-piston will
go off now, as a sign that the capture memory is 'closed' again.
8. Write the just programmed capture combination (e.g. M6-3) on the piece of music in
which this registration is to be used.
Your personal registration is now stored into memory group 6 at place 3.
