3. Product Description
NO.
1
2
3
4
5
WARNING:
Follow the wire markings for wiring.

3.6 Indicator Light Description

Model
Color
Light
PWR Green
RUN Green
F1 Green
F2 Green
definition
Port 1 RS-485_A
Port 1 RS-485_B
Port 2 RS-485_A
Port 2 RS-485_B
GND
Function
Status
ON Always on after power on,the power supply is normal
OFF Power OFF
System running indicator,on/flashing is normal
ON/Blink
Unused
OFF
Module communication status,flashing irregularly
Blink
NO.
Port 3 RS-485_A
6
Port 3 RS-485_B
7
Port 4 RS-485_A
8
Port 4 RS-485_B
9
10
S3-Logger
.6.
definition
GND
