  • Page 1 S3-Logger Datalogger User Manual Ginlong Technologies Co., Ltd.
  • Page 2 Modification record Description Version Date Release date Remarks V1.0 21/05/06 First official release...

  • Page 3: Table Of Contents

    Contents S3-Logger Datalogger User Manual ……………………………………………………………………………………………………………………… 1. About this document …………………………………………………………………………………………………………………………………………………………………… 1.1 Target ……………………………………………………………………………………………………………………………………………………………………………………………… 1.2 Note …………………………………………………………………………………………………………………………………………………………………………………………………… 1.3 Symbol Description ……………………………………………………………………………………………………………………………………………………………… 2. Safety Notice ……………………………………………………………………………………………………………………………………………………………………………………… 3. Product Description ……………………………………………………………………………………………………………………………………………………………………… 3.1 Product Introduction …………………………………………………………………………………………………………………………………………………………… 3.2 Application Scenarios Introduction ………………………………………………………………………………………………………………………… 3.3 Appearance ………………………………………………………………………………………………………………………………………………………………………………...

  • Page 4: S3-Logger Datalogger User Manual

    Provide users with detailed product information and installation, operation and maintenance instructions of S3-Logger. 1.2 Note This manual is applicable to the on-site installation and configuration of S3-Logger data logger, and requires professional technicians to operate. 1.3 Symbol Description In order to ensure the safety of users, power grid, and equipment when using this product, the manual provides relevant warning symbols.

  • Page 5: Safety Notice

    2. Safety Notice S3-Logger is designed in accordance with international safety regulations in order to ensure the safety of people, power grid and equipment. As a power electronic product, relevant safety regulations must be followed in the stages of installation, commissioning, operation, and maintenance.

  • Page 6: Product Description

    3. Product Description 3.1 Product Introduction ·S3-Logger is mainly used in industrial and commercial, distributed photovoltaic projects, safe and reliable, easy to install, flexible networking, multi-device access, intelligent operation and maintenance. Easy to install: Desktop installation, rail installation Flexible networking: Support 4 channels of RS485, 1 channel of Ethernet communication...

  • Page 7: Appearance

    3. Product Description 3.3 Appearance DIN-Rail Wall Mount COM Logger 3.4 Power Wiring Diagram PE - +...

  • Page 8: Communication Terminal Description

    3. Product Description 24V power supply COM Logger AC:85-264V DC:120-370V Danger: Please strictly follow the above example for wiring. 3.5 Communication Terminal Description 5.08mm 1*10P Terminals...

  • Page 9: Indicator Light Description

    Port 2 RS-485_A Port 4 RS-485_A Port2 RS-485_A Port 4 RS-485_B WARNING: Follow the wire markings for wiring. 3.6 Indicator Light Description Model S3-Logger Function Color Status Light Always on after power on,the power supply is normal Green Power OFF...

  • Page 10: Installation Process

    4. Installation Process Equipment disassembly and inspection Mechanical installation Electrical Installation Software configuration Data check Reference Chapter Process Equipment disassembly and inspection Mechanical installation Electrical Installation Software configuration Data check...

  • Page 11: Mechanical Installation

    5. Mechanical Installation 5.1 Equipment Disassembly Check that the delivery is complete and undamaged according to the packing list inside the package. Name Comment S3-Logger Datalogger Port 3 RS-485_A Port 3 RS-485_B Power terminal Serial communication With 2*120 ohm terminating resistors...
  • Page 12 1. Fix the guide rail in a suitable position 2. S3-Logger is tilted at a certain angle, so that the upper clip fits into the guide rail 3. Push the lower part of S3-Logger and snap it into the guide rail Warning: Please observe the surrounding environment during installation to avoid hand scratches.

  • Page 13: Electrical Connections

    1. Use a 2.5mm² wire, strip the insulation for 8-10mm. 2. The +V and -V terminals of the power supply are respectively connected to the V+ and V- terminals of the S3-Logger device. Danger: Please be sure to check the corresponding terminal carefully when wiring, so as to avoid injury to personnel and equipment.
  • Page 14 4. If multiple inverters need to be monitored on site, daisy-chain cables can be used for the inverters. Each serial port of S3-Logger can connect 15 inverters. Note: When wiring, RS485A is connected to the A port of the S3-Logger device, and RS485B is connected to the B port of the S3-Logger device. .11.

  • Page 15: Configuration

    firewall allow the following IP and port, so that the data collected can be effectively uploaded. IP: Allocation according to firewall policy, Logger for adaptation. Solis cloud platform: port 1883. IEC104 protocol: 2404-2405 ports. Remote maintenance ports: 1723, 1777 ports.
  • Page 16 7. Configuration 2. Enter 192.168.1.254:1323 in the URL bar of the browser. Account: admin; Password: 123456 .13.
  • Page 17 7. Configuration 3. Configure the RS485 interface in "Interface config", connect COM1 and COM2 to the inverter and EPM, COM3 to the weather station, and COM4 to the electric meter. (If the list of weather stations and electric meters cannot match the actual application on site. Please feedback the equipment model and communication protocol to the local technical support, and we will update it according to the site).
  • Page 18 7. Configuration 5.‘To configure’ allows you to import the configuration file directly. If other brands of weather stations or electricity meters are used on site, please send the communication protocol of the equipment to the local technical support. After we complete the configuration, you only need to import the configuration file and restart it to take effect.
  • Page 19 32-bit short floating point Byte order HH HL LH LL Function code Control Register start address Function code 06 or 10 Tele Data type 16 bit signed integer control Byte order Upload to Solis Cloud MQTT Do not upload to Solis Cloud .16.
  • Page 20 7. Configuration 8. "Account password" allows you to modify the login password. .17.
  • Page 21 7. Configuration 9. Modify the IP address of the network port of the logger device: the datalogger default IP address: 192.168.1.254, click "Original tool", click "Network", and configure the IP, subnet mask, and gateway according to the firewall to ensure that the device can connect to the network smoothly.
  • Page 22 7. Configuration EPM Function Description Data logger with grid point meter can realize the project field station anti-backflow function. It is necessary to obtain in advance the ratio parameters of PT and CT at the site and the communication protocol of the meter. Application Scenarios Brief description of control parameters Allowed feed-in power: The power allowed to be fed into the local grid, which can be configured...

  • Page 23: Routine Maintenance

    Check whether there is electrical interference near S3-Logger Check for corrosive substances near S3-Logger Working environment Check if the S3-Logger ambient temperature is out of range Check if S3-Logger is clean Check whether the S3-Logger power supply is stable and reliable...

  • Page 24: Common Problems

    9. Common Problems Explanation Problems Observe the indicator light of the equipment How to deal with the and check item by item according to the instruction device offline? manual; 1. Debug software to check whether the inverter is normal (excluding inverter hardware problems); 2.

  • Page 25: Appendix

    10.Appendix Model Name S3-Logger Communication Supported device type Solis inverter Number of connected Each RS485 PORT≤ 15 inverter Data collection intervals 5 minutes LED x 2,Power,Run Status indicator COM x 4,1200-19200 bps,communication distance ≤ 1000m RS485 LAN x 1,10 / 100Mbps adaptive,communication distance ≤ 100m...
  • Page 26 Ginlong Technologies Co., Ltd. No. 57 Jintong Road, Binhai Industrial Park, Xiangshan, Ningbo, Zhejiang, 315712, P.R.China. Tel: +86 (0)574 6578 1806 Fax: +86 (0)574 6578 1606...
