S3-Logger Datalogger
User Manual
Ginlong Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S3-Logger and is the answer not in the manual?

Questions and answers

Related Manuals for SOLIS S3-Logger

Summary of Contents for SOLIS S3-Logger

  • Page 1 S3-Logger Datalogger User Manual Ginlong Technologies Co., Ltd.

  • Page 2: Table Of Contents

    Contents S3-Logger Datalogger User Manual ……………………………………………………………………………………………………………………… 1. About this document …………………………………………………………………………………………………………………………………………………………………… 1.1 Target ……………………………………………………………………………………………………………………………………………………………………………………………… 1.2 Note …………………………………………………………………………………………………………………………………………………………………………………………………… 1.3 Symbol Description ……………………………………………………………………………………………………………………………………………………………… 2. Safety Notice ……………………………………………………………………………………………………………………………………………………………………………………… 3. Product Description ……………………………………………………………………………………………………………………………………………………………………… 3.1 Product Introduction …………………………………………………………………………………………………………………………………………………………… 3.2 Application Scenarios Introduction ………………………………………………………………………………………………………………………… 3.3 Appearance ………………………………………………………………………………………………………………………………………………………………………………...

  • Page 3: S3-Logger Datalogger User Manual

    Provide users with detailed product information and installation, operation and maintenance instructions of S3-Logger. 1.2 Note This manual is applicable to the on-site installation and configuration of S3-Logger data logger, and requires professional technicians to operate. 1.3 Symbol Description In order to ensure the safety of users, power grid, and equipment when using this product, the manual provides relevant warning symbols.

  • Page 4: Safety Notice

    2. Safety Notice S3-Logger is designed in accordance with international safety regulations in order to ensure the safety of people, power grid and equipment. As a power electronic product, relevant safety regulations must be followed in the stages of installation, commissioning, operation, and maintenance.

  • Page 5: Product Description

    3. Product Description 3.1 Product Introduction S3-Logger is mainly used in industrial and commercial, distributed photovoltaic projects, safe and reliable, easy to install, flexible networking, multi-device access, intelligent operation and maintenance. Easy to install: Desktop installation, rail installation Flexible networking: Support 4 channels of RS485, 1 channel of Ethernet communication...

  • Page 6: Appearance

    3. Product Description 3.3 Appearance 3.4 Power Wiring Diagram...

  • Page 7: Communication Terminal Description

    3. Product Description 24V power supply COM Logger AC:85-264V DC:120-370V Danger: Please strictly follow the above example for wiring. 3.5 Communication Terminal Description 5.08mm 1*10P Terminals...

  • Page 8: Indicator Light Description

    Port 2 RS-485_A Port 4 RS-485_A Port 2 RS-485_B Port 4 RS-485_B WARNING: Follow the wire markings for wiring. 3.6 Indicator Light Description Model S3-Logger Function Color Status Light Always on after power on,the power supply is normal Green Power OFF...

  • Page 9: Installation Process

    4. Installation Process Equipment disassembly and inspection Mechanical installation Electrical Installation Software configuration Data check Reference Chapter Process Equipment disassembly and inspection Mechanical installation Electrical Installation Software configuration Data check...

  • Page 10: Mechanical Installation

    5. Mechanical Installation 5.1 Equipment Disassembly Check that the delivery is complete and undamaged according to the packing list inside the package. Name Comment S3-Logger Datalogger Power terminal Serial communication With 2*120 ohm terminating resistors terminal Power Supply DIN-Rail 5.2 Device Installation...
  • Page 11 1. Fix the guide rail in a suitable position 2. S3-Logger is tilted at a certain angle, so that the upper clip fits into the guide rail 3. Push the lower part of S3-Logger and snap it into the guide rail Warning: Please observe the surrounding environment during installation to avoid hand scratches.

  • Page 12: Electrical Connections

    1. Use a 2.5mm² wire, strip the insulation for 8-10mm. 2. The +V and -V terminals of the power supply are respectively connected to the V+ and V- terminals of the S3-Logger device. Danger: Please be sure to check the corresponding terminal carefully when wiring, so as to avoid injury to personnel and equipment.
  • Page 13 4. If multiple inverters need to be monitored on site, daisy-chain cables can be used for the inverters. Each serial port of S3-Logger can connect 15 inverters. Note: When wiring, RS485A is connected to the A port of the S3-Logger device, and RS485B is connected to the B port of the S3-Logger device. .11.

  • Page 14: Configuration

    firewall allow the following IP and port, so that the data collected can be effectively uploaded. IP: Allocation according to firewall policy, Logger for adaptation. Solis cloud platform: port 1883. IEC104 protocol: 2404-2405 ports. Remote maintenance ports: 47, 1723, 1777 ports.
  • Page 15 7. Configuration 2. Enter 192.168.1.254:1323 in the URL bar of the browser. Account: admin; Password: 123456 .13.
  • Page 16 7. Configuration Func on introduc on Interface config Used to configure device access Device data For device view Forwarding service Used to select forwarding channels Used to configure App Config Zero Injection (datalogger + meter) parameters and select me zone Account password Used for password change Plug-in...
  • Page 17 7. Configuration 4.Interface config The configuration function of S3 logger, you can add inverters, EPM (Solis EPM Device), meteorological meters, meters and other devices through the Add Device. Com1 and Com2 support inverters and EPM devices, Com3 supports meteorological meters, and com4 supports meters (two-way electric meters can be used to meet the zero injection function).
  • Page 18 7. Configuration After the configuration is completed, as shown in Figure: 6. Configure the weather meter and electricity meter in COM3 and COM4. The default device addresses are 1-3. If other addresses are required, configure them like above inverters .16.
  • Page 19 7. Configuration 7. If you want to view Zero Injection (datalogger + meter) data, you need to add the corresponding meter information to COM4; otherwise, the corresponding device information cannot be added to the Zero Injection list. This page is used to display Zero Injection data.
  • Page 20 7. Configuration 8. "Device data" can view the real-time data of the connected device. At the same time, the inverter can be remotely adjusted and controlled by "Control and Telecontrol". Because the meter involves PT/CT ratio and other issues, after adding the meter information in Interface config, you must set the strain ratio parameters in the Device data according to the sequence in below figure.
  • Page 21 32-bit short floating point Byte order HH HL LH LL Function code Control Register start address Function code 06 or 10 Tele Data type 16 bit signed integer control Byte order Upload to Solis Cloud Soliscloud Do not upload to Solis Cloud .19.
  • Page 22 7. Configuration 10. Zero Injection function (datalogger + meter) Note: This function only supports the function judgment based on the total power of the grid point. Configuration: (1) Select the Zero Injection list in the sequence shown in the following figure, and select System Configuration Table to set Zero Injection system parameters .20.
  • Page 23 7. Configuration Meaning Name Backflow power(KW) Backflow power setting value Judgment interval Logic judgment time, the default is 3 seconds, (seconds) Calculate based on the number of inverters * 1.5 seconds Three-phase average power mode (default) Working mode Three-phase minimum power mode Active power value Calculated according to three-phase voltage and current (default) sampling...
  • Page 24 7. Configuration 11. Time zone selection, this time zone involves the timing of the inverter and other functions, please select your own time zone according to the sequence shown in the diagram, and select no for the rest. After the configuration is complete, click Save and restart datalogger 12.

  • Page 25: Routine Maintenance

    Check whether there is electrical interference near S3-Logger Check for corrosive substances near S3-Logger Working environment Check if the S3-Logger ambient temperature is out of range Check if S3-Logger is clean Check whether the S3-Logger power supply is stable and reliable...

  • Page 26: Common Problems

    9. Common Problems Explanation Problems Observe the indicator light of the equipment How to deal with the and check item by item according to the instruction device offline? manual; 1. Debug software to check whether the inverter is normal (excluding inverter hardware problems); 2.

  • Page 27: Appendix

    10.Appendix Model Name S3-Logger Communication Supported device type Solis inverter Number of connected Each RS485 PORT≤ 15 inverter Data collection intervals 5 minutes LED x 2,Power,Run Status indicator COM x 4,1200-19200 bps,communication distance ≤ 1000m RS485 LAN x 1,10 / 100Mbps adaptive,communication distance ≤ 100m...
