Wiring diagram

1-3
relay power supply 165÷265 V AC
central control: ������ �� ����������
4
6
local control: ������
9
central control: ������ ��� ����������
7-10
1×NO separated contact
The control inputs may only be powered from the neu-
tral wire (N).
