F&F BIS-419 Manual

Bistable relay, sequential, 4-functions

Advertisement

Quick Links

BIS-419
Bistable relay,
sequential, 4-functions
Do not dispose of this device in the trash along with other waste! According to the Law on
Waste, electro coming from households free of charge and can give any amount to up to
that end point of collecti on, as well as to store the occasion of the purchase of new equip-
ment (in accordance with the principle of old-for-new, regardless of brand). Electro thrown
in the trash or abandoned in nature, pose a threat to the environment and human health.
Purpose
The electronic bistable pulse relay BIS-419 allows lighting or other
appliances to be switched on or off from several different points by
means of parallel connected momentary (bell) control switches.
The relay has 2 switching sections and allows to switch on or off
in sequence 2 lighting circuits or other appliances from several
different points.
Functioning
Power supply to the relay is indicated by the lighting of the green
LED [U]. The sequential relay has 2 separate outputs R1 and R2.
The state of the contacts (closed/open) is enforced sequentially
according to the preset programme. Switching of the contacts to
the next state takes place after another impulse of the control
button. Activation of contacts R1 and R2 is signalled by lighting
of corresponding red LEDs R1 and R2. After the power supply
voltage decay, the contact status is reset. After the power supply
voltage is restored, the relay starts from sequence no. 0.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the BIS-419 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for F&F BIS-419

  • Page 1 Purpose The electronic bistable pulse relay BIS-419 allows lighting or other appliances to be switched on or off from several different points by means of parallel connected momentary (bell) control switches.
  • Page 2 8-9. 6. Set the desired programme (sequence) using the knob on the front of the relay. BIS-419 is compatible with backlit buttons. The maximum total backlight current of all connected buttons must not exceed 5 mA. - 2 -...
  • Page 3: Wiring Diagram

    Wiring diagram Example of connection with control pulse L - 3 -...
  • Page 4 Example of connection with control pulse N - 4 -...
  • Page 5 Diagrams Sequence A » Subsequent pressings of a button repeat the sequence 0-1-2-3. Sequence B » Pressing the button again in less than 5 seconds repeats sequ- ences 1-3. » Pressing the button again aft er more than 5 seconds opens both contacts (sequence 0).
  • Page 6 Sequence C » Subsequent pressings of a button repeat the sequence 0-1-2. Sequence D » Pressing the button again in less than 5 seconds repeats sequ- ences 1-2. » Pressing the button again after more than 5 seconds opens both contacts (sequence 0). »...
  • Page 7: Power Table

    Technical data power supply 165÷265 V AC contact separated 2×NO/NC maximum load current (AC-1) 2×16 A control pulse current <1 mA activation delay 0.1÷0.2 s power indication green LED power activation 2× red LED power consumption standby 0.15 W 0.9 W terminal 2.5 mm²...
  • Page 8: Warranty

    Warranty The F&F products are covered by a warranty of the 24 months from the date of purchase. Effective only with proof of purchase. Contact your dealer or directly with us. CE declaration F&F Filipowski L.P. declares that the device is in conformity with the essential requirements of The Low Voltage Directive (LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC) Directive 2014/30/UE.
