The maximum total backlight current of all connected
buttons must not exceed 5 mA.
Technical data
power supply
contact
maximum load current (AC-1)
control pulse current
activation delay
power indication
signalling indication
power consumption
standby
on
terminal
tightening torque
working temperature
dimensions
mounting
ingress protection
2.5 mm² screw terminals
- 6 -
165÷265 V AC
separated 1×NO
16 A (120 A/20 ms)
0.1÷0.2 s
green LED
red LED
0.15 W
0.4 Nm
-25÷50°C
1 module (18 mm)
on TH-35 rail
5 mA
0.6 W
IP20
