Kramer EXT3-21-XR-TR Quick Start Manual page 4

Step 5: Connect power
Connect the power cord to EXT3-21-XR-TR
HDBT port or the LAN port.
Safety Instructions (See www.kramerav.com for updated safety information)
Caution:
• For products with relay terminals and GPI\O ports, please refer to the permitted rating for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• Disconnect the power and unplug the unit from the wall before installing.
Step 6: Operate EXT3-21-XR-TR
Operate Product via:
•
Front panel buttons
•
RS-232 serial commands
transmitted by a PC or a serial
controller.
•
Remotely, via LAN using
device embedded web pages.
and plug it into the mains electricity. Alternatively, receive power either from the
RS-232 Control / Protocol 3000
Baud Rate: 115,200
Data Bits: 8
Stop Bits: 1
Example: (flash LEDs on the front panel for 60 seconds): #IDV<CR>
Default IP Parameters (by default, DHCP is ON)
IP Address
Fallback IP Address: 192.168.1.39
Fallback Subnet Mask: 255.255.255.0
Fallback Gateway: 0.0.0.0.
Default Username: admin
Parity: None
Command Format: ASCII
UDP Port #: 50000
TCP Port #: 5000
Default Password: Admin
