Trojan POWER GYM 1.0 User Manual
  1. Manuals
  2. Brands
  3. Trojan Manuals
  4. Home Gym
  5. POWER GYM 1.0
  6. User manual

Trojan POWER GYM 1.0 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

POWER GYM 1.0
COMPLETE BODY
STRENGTH
HOME GYM
WORKOUT
& TONING
USER MANUAL
CAUTION
READ ALL PRECAUTIONS AND
Visit facebook.com/trojanhealth
INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUIPMENT.
www.trojanhealth.co.za
KEEP THIS MANUAL FOR
FUTURE REFERENCE.
www.instagram.com/trojanhealth
#19M02T008 Power Gym 1.0 UM VERSION 4.indd 1
29/05/2019 13:29
