- Page 1 Welcome MVS Micro Sensor LCLCSENSE/M/EG/B WE’RE HERE TO HELP: 1(844) LIGHTCLOUD 1(844) 544-4825...
- Page 2 Hello The Lightcloud Blue MVS Micro Sensor is a dual-technology motion detector and daylight sensor that can switch and dim both local and remote circuits. The MVS Micro Sensor is compatible with Lightcloud Blue Controllers and fixtures. WE’RE HERE TO HELP: 1(844) LIGHTCLOUD 1(844) 544-4825 support@lightcloud.com...
-
Page 3: Specifications
Specifications OPERATING TEMPERATURE PART NUMBER LCLCSENSE/M/EG/B -4°F to 113°F (-20°C to 45°C) SENSOR COVERAGE MOUNTING HEIGHT 26 ft. diameter at 9 ft. 8 to 12 ft. CONNECTOR INPUT 5VDC RJ09 DIMENSIONS 1.30”W x 1.33”H x 2.64”D... -
Page 4: Setup And Installation
Setup & Installation The MVS Micro Sensor is only compatible with select sensor-ready fixtures. Visit www.rablighting.com to see the full compatibility list. Mount the MVS Micro Sensor with the tape included. Example shown using RAB's SWISH fixture. MVS Micro Sensor SWISH... - Page 5 Setup & Installation (Cont’d) Connect the MVS Micro Sensor to the Lightcloud Blue Controller. Lightcloud Blue Controller: Use the enclosed RJ09 adapter to connect the MVS Micro Sensor to the Controller. ADAPTER MVS MICRO SENSOR CONTROLLER Wire Female to Short, Wire Female RJ09...
- Page 6 Sensor Coverage (LCBS MVS) 9’ 13’ 7.5’ 0’ 7.5’ 13’ 20’ 7.5’ 0’ 40’ 7.5’ 20’...
- Page 7 Configuration All configuration of Lightcloud Blue products may be performed using the Lightcloud Blue mobile app. Learn more at www.rablighting.com 1(844) LIGHTCLOUD 1(844) 544-4825 ©2022 RAB LIGHTING Inc. Custom manufactured in China Pat. rablighting.com/ip...
