Installation Manual
The STEALTH 360 is the most reliable
and technically advanced motion-
activated light control ever
produced. This technical manual is
written for electrical professionals
who wish to maximize the
performance and reliability of this
superb sensor.
RAB welcomes your questions or
comments.
Please call 888 722 1000 or email
marketing@rabweb.com.
Thank you for purchasing a RAB sensor.
STL360HBW
STL3FFLED18
STL360H
Specifications:
Switching Capacity:
8 amps
Voltage:
120 volts
Protection Pattern:
180º forward
360º below and to the sides
Time Adjustment:
5 seconds to 12 minutes
Power Consumption:
1 watt
Surge protection:
6000 volts
Cautions:
TURN OFF ALL POWER AT CIRCUIT BREAKER/FUSE PANEL
■ Read entire Installation Manual before proceeding.
■ All wiring should comply with local electrical codes and
requires a qualified electrician.
■ The total lighting load connected to STL360 must not exceed (1000 watts
incandescent, 250 watts fluorescent). To switch more wattage, an electri-
cian can install a relay.
■ Line Carrier Remote Control Systems such as X-10, Leviton or Radio Shack
are incompatible with sensors and may cause false activations.
■ Do not install sensors on a circuit that feeds motor loads such as kitchen
appliances, HVAC equipment, washer/dryer, or garage door openers.
■ Sensor functions best when the direction of expected
movement is across its detection pattern, not towards the sensor.
Mount 6'-10' high for optimum range and detection.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RAB STEALTH 360
Summary of Contents for RAB STEALTH 360
- Page 1 Protection Pattern: 180º forward 360º below and to the sides Time Adjustment: 5 seconds to 12 minutes The STEALTH 360 is the most reliable and technically advanced motion- Power Consumption: 1 watt activated light control ever produced. This technical manual is...
- Page 2 How Does the Super Stealth 360 Work? How long do the lights stay on? The STL360’s infrared sensor “ sees” temperature changes caused by the motion of people or cars within its protection zone and turns on lights Lights remain on as long as there is movement within the protection zone.
- Page 3 Choosing a Location The best location is where the sensor can “see” all paths of movement. The Difficult Locations: sensor may be wall or soffit mounted. Sensor may be triggered by unwant- ed movement or heat source, such As distance from the sensor increases, larger movement will be required for as a swaying tree, road traffic, dryer detection.
- Page 4 Choosing a Location Locations Near Roads Locate for Movement Across Pattern Cars and passing traffic may activate the sensor if it is aimed at the road. Check that movement is not directly towards sensor. Sensor will see To Improve Performance in Difficult Locations: movement ACROSS its pattern move quickly.
- Page 5 STL360HBW erproof box, you must use with the metal mouting plate with gasket. Easy Wiring Tip: STL360 floodlight kits come pre-wired and assemble on the RAB CU4 EZ Hood rests Use the “S” shaped Hands plate, allowing for mounting on round, rectangular or octagonal surface or...
- Page 6 ■ To install STL360 Pre-wired Floodlight Kits, see page 7. Screw the threaded arms of each floodlight into the RAB CU4 EZ Plate. (See diagram on page 7) Screw the threaded arm of the sensor into the bottom hole of the EZ Plate.
- Page 7 Adjusting the Settings TIME EVENING TIMER EVENING TIME SENS EVENING TIME SENS TIMER TIMER – 8 HRS 5 SECS 12 MINS – 8 HRS 5 SECS 12 MINS Sets the time that lights will remain on after the detection zone is vacated. The STL360 provides an alternative to normal motion-activated lighting.
-
Page 8: Automatic Mode
Sensor Modes MANUAL OVERRIDE MODE AUTOMATIC MODE The STL360 has a “protected” Manual Override that requires a double-flip of Lights will turn on when there the light switch so momentary power problems do not interfere with normal is movement within the de- sensor operation. - Page 9 Tech Help Line rabweb.com email ©2014 RAB LIGHTING Inc. Call our experts 888 RAB-1000 Visit our website for product info Answered promptly sales@rabweb.com Northvale, New Jersey 07647 USA STEALTH-IN-1114...
- Page 10 Technical Tips: Technical Tips: Lights Turn On and Off Inappropriately Lights Do Not Turn On Make sure the sensor is installed on its own dedicated circuit, free of Check that lamps and fixtures work. Compare wiring to the wiring dia- motor loads such as HVAC equipment, kitchen appliances or garage gram in this manual.
- Page 11 Technical Tips: Technical Tips: Lights Turn Off too quickly Range Appears Limited 1. Check if sensor is being “tricked” by reflected light. If lights controlled by 1. Check that the sensor is level the sensor shine or reflect into the photocell (located behind the lens) the from side to side and pointed unit will go on briefly, see its own light, and turn off “thinking”...
- Page 12 Before you call, please have the warranties with respect to: • Slotted Screws (4) and RAB shall not be liable for labor or other costs related to following information handy: • Finishing Cap de-installation or re-installation.
