GABLE 10' x 12' (305 x 366 cm)
ACTUAL FLOOR SIZE IS 120 x 144" (304,8 x 365,8 cm)
READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY.
• BUILDING RESTRICTIONS AND APPROVALS
Be sure to check local building department and homeowners association for specific restrictions and/ or requirements before building.
• ENGINEERED DRAWINGS
Contact our Customer Service Team if engineered drawings are needed to pull local permits.
• SURFACE PREPARATION
To ensure proper assembly you must build your shed on a level surface. Recommended methods and materials
to level your shed are listed on page 9.
• CHECK ALL PARTS
Inventory all parts listed on pages 4 - 8.
• ADDITIONAL MATERIALS
You will need additional materials to complete your shed. See page 3 for required and optional materials and quantities.
***CONTACT OUR CUSTOMER SERVICE TEAM
IF ANY PARTS ARE MISSING OR DAMAGED***
Call: 1-877-743-3400 email: customerservice@backyardproductsllc.com
KEEP THIS MANUAL FOR FUTURE REFERENCE
IM P O RTA NT !
BEFORE YOU BEGIN
16519
02/28/2021
PART 1
DOOR LOCATION OPTION

Advertisement

loading
Need help?

Need help?

Do you have a question about the GABLE 10' x 12' and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Products GABLE 10' x 12'

Summary of Contents for Backyard Products GABLE 10' x 12'

  • Page 1 16519 02/28/2021 PART 1 GABLE 10' x 12' (305 x 366 cm) ACTUAL FLOOR SIZE IS 120 x 144" (304,8 x 365,8 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE DOOR LOCATION OPTION IM P O RTA NT ! READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY. BEFORE YOU BEGIN •...
  • Page 2 TOOLS Required Optional ❑ Phillips ❑ ❑ Tool Belt/ Utility Knife Screwdriver Nail Pouch ❑ Shingle Blades ❑ Drill / Driver ❑ Caulk Gun ❑ 1/8" Drill Bit ❑ Tin Snips ❑ 1/4" Drill Bit (for drip edge) ❑ 5/16" Drill Bit ❑...

  • Page 3: Additional Materials

    ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed does not include leveling materials. • See the FLOOR LEVELING section on page 9 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site. COMPLETING YOUR SHED You will need these additional materials: 3-TAB SHINGLES ......

  • Page 4: Parts List

    PARTS IDENTIFICATION AND SIZES Part identification WOOD SIZE CONVERSION CHART letters are stamped on some parts. Treated lumber is stamped: Nominal Board Size Actual Size 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3 ....1-1/2"...
  • Page 5 FLOOR FRAMING 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 45" (5,1 x 10,2 x 114,3 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 93"...
  • Page 6 ROOF PANELS Roof panels are 7/16" (1,1 cm) thick. NOTE: Panel parts are not stamped. 7/16 x 27-1/4 x 96" 7/16 x 7-7/8 x 94-1/2" (1,1 x 69,2 x 243,8 cm) (1,1 x 20 x 240 cm) 7/16 x 32-5/8 x 75-1/4" (1,1 x 82,9 x 191,1 cm) 7/16 x 48 x 96"...
  • Page 7 DORMER WALL PANELS Dormer panels are 3/8" (1,1 cm) thick. NOTE: Panel parts are not stamped. 3/8 x 20 x 94-1/2" (1,0 x 50,8 x 240 cm) DORMER ROOF PANELS Roof panels are 7/16" (1,1 cm) thick. NOTE: Panel parts are not stamped. 7/16 x 3-7/16 x 64-1/2"...

  • Page 8: Fasteners & Hardware

    FASTENERS & HARDWARE NAIL BOXES 3" (7,6 cm) BOXES 2" (5,1 cm) BOXES FASTENER/HARDWARE BAG x140 1-1/2" (3,8 cm) 1-1/4" (3,2 cm) x366 2" (5,1 cm) x195 3" (7,6 cm) 1" (2,5 cm) 2" (5,0 cm) (NOT ACTUAL SIZE) 3/8" x5-1/2" (1 cm x 14 cm) 1-5/8"...
  • Page 9 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS • 3" Screws angled into 4x4. • (2) at each point frame • and 4x4 touch. 12" (30,5 cm) MATERIAL REQUIRED 4 x 4 x 10' (10 x 10 x 304,8 cm) Treated Lumber 12"...
  • Page 10 CONCRETE FOUNDATION Your kit contains all materials to construct a wooden floor. If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4" (10,2 cm) Building Size Actual Size 10'x 12' (243,8 x 365,8 cm) 120" x 144" (304,8 x 365,8 cm) 120"...

  • Page 11: Parts Required

    10' x 8' FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5 x 10 x 183 cm) Treated Wood 2 x 4 x 48" (5 x 10 x 122 cm) Treated Wood Look for TREATED 2 x 4 x 93" (5 x 10 x 236,2 cm) Treated Wood Stamp You will build two foor sections.
  • Page 12 10' x 4' FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 96" (5 x 10 x 243,8 cm) Treated Wood Look for TREATED 2 x 4 x 24" (5 x 10 x 61cm) Treated Wood Stamp Treated Wood 2 x 4 x 45"...
  • Page 13 10' x 4' FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) Fasten floor sections together with 3" nails as shown. Section 2 Section 1 (4) Nails per side, stagger pattern. 120" 144" (305 cm) (365,8 cm) FINISH You have finished your floor frame. Proceed to level and square the floor frame.
  • Page 14 LEVEL AND SQUARE FLOOR FRAME Before attaching floor decking, it is important to level and square the floor frame. A level and square floor frame is required to correctly construct your shed. BEGIN See page 7 for the preferred floor leveling method. Use level and check the frame is level before applying floor panels. Check for frame squareness by measuring diagonally across corners. If the measurements are the same, the frame is square. The diagonal measurement will be approximately 187-7/16" (476,1 cm). When the frame is level and square secure one side of frame to the 4x4 runners using (1) fastener at ends of each runner.
  • Page 15 FLOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 5/8 x 48 x 96" (1,6 x 121,9 x 243,8 cm) Ensure your foor frame is square by installing one panel and squaring the frame. BEGIN Attach the 48" x 96" panel with the rough side up (painted-grid lines side) with the 48" edge and corner flush to the floor frame (Fig A).
  • Page 16 FLOOR PANELS PARTS REQUIRED: x199 2" (5,1 cm) 5/8 x 23-7/8 x 48" (1,6 x 60,6 x 122 cm) 5/8 x 23-7/8 x 96" 5/8 x 48 x 96" (1,6 x 60,6 x 243,8 cm) (1,6 x 122 x 243,8 cm) Continue installing panels with rough side up (painted grid lines).
  • Page 17 IMPORTANT! Check the foor frame is level after installing foor panels. Re-level if needed. • The foor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process to avoid over-handling of the walls. HINT: 12' EAVE WALL BACK WALL...
  • Page 18 MAIN ROOF RAFTER ASSEMBLY PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 4-3/8" (5,1 x 10,2 x 11,1 cm) Build a rafter jig using the gable end of floor and (2) GPC parts as shown. ¸ BEGIN Secure (1) GPC flush to the floor deck with (2) 3" screws. Measure over 120-3/4" and install a second GPC flush to the floor deck. GPC will overhang the floor. Secure with (2) 3" screws. 120"...
  • Page 19 MAIN ROOF RAFTER ASSEMBLY PARTS REQUIRED: 2" (5,1 cm) OSB OR WOOD GRAIN 6" (15,2 cm) Gusset NOTE: 6 x 24" (15,2 x 61 cm) 2 x 4 x 73-3/4" (5,1 x 10,2 x 187,3 cm) ¸ BEGIN Place (2) rafters DPN into the jig as shown. Keep rafters DPN firm against (2) GPC's as shown (Fig.A).
  • Page 20 DORMER RAFTER ASSEMBLY PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 4-3/8" (5,1 x 11,1 x 14,9 cm) Build a rafter jig using the gable end of floor and (2) GPC parts as shown. ¸ BEGIN Measure 120-3/8" (306,7 cm) from the floor edge. Install (1) GPC flush to the floor deck. GPC will overhang the floor. Secure with (2) 3" screws. Measure 17-11/16" (44,9 cm) from the floor edge. Secure (1) GPC flush to the floor deck with (2) 3" screws. 120" Floor Width (304,8 cm) Fig.
  • Page 21 DORMER RAFTER ASSEMBLY (CENTER 3 GUSSETS) PARTS REQUIRED: OSB OR WOOD GRAIN 4-13/16 x 24" (12,2 x 61 cm) 2" (5,1 cm) 4-13/16" (15,2 cm) Gusset NOTE: 2 x 4 x 61-1-4" (5,1 x 10,2 x 155,6 cm) 2 x 4 x 73-3/4" (5,1 x 10,2 x 187,3 cm) ¸...
  • Page 22 DORMER RAFTER ASSEMBLY (RIGHT 1 GUSSET) PARTS REQUIRED: OSB OR WOOD GRAIN 4-13/16 x 24" (12,2 x 61 cm) 2" (5,1 cm) 4-13/16" (15,2 cm) Gusset NOTE: 2 x 4 x 61-1-4" (5,1 x 10,2 x 155,6 cm) 2 x 4 x 73-3/4" (5,1 x 10,2 x 187,3 cm) Place rafters BVT and DPN into the jig as shown.
  • Page 23 DORMER RAFTER ASSEMBLY (LEFT 1 GUSSET) PARTS REQUIRED: TEMPORARY OSB PANEL 2" (5,1 cm) 7/16 x 7-7/8 x 23-7/8" (1,1 x 20 x 60,6 cm) 1-1/4" (3,2 cm) 2 x 4 x 61-1-4" (5,1 x 10,2 x 155,6 cm) OSB OR WOOD GRAIN 4-13/16 x 24"...
  • Page 24 DOOR HEADER PARTS REQUIRED: 3" (7,6 cm) 7/16 x 3-1/4 x 58-3/4" (1,1 x 8,3 x 149,2 cm) 2 x 4 x 59" (5,1 x 10,3 x 149,9 cm) BEGIN Center the 3-1/4" x 58-3/4" OSB filler between (2) parts SX (Fig. A, Fig. B). Ensure ends of KMA are flush (Fig.
  • Page 25 GABLE OR EAVE WALL WINDOW FRAMES PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 22-1/2" (5,1 x 10,2 x 57,1 cm) 2 x 3 x 22-1/2" (5,1 x 7,6 x 57,1 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) BEGIN Orient 2x4 parts on edge on floor. Lay LV on the flat side (Fig.
  • Page 26 STOP CHOOSE YOUR DOOR LOCATION AT THIS TIME AS YOU WILL ASSEMBLE YOUR DOOR WALL FIRST. GABLE END WALL WITH DOOR: IF YOU CHOOSE THE GABLE END WALL FOR DOOR LOCATION GO TO Next Page TO BEGIN BUILDING YOUR WALLS OPTIONAL: DOOR LOCATED ON EAVE SIDE WALL...
  • Page 27 10' GABLE WALL DOOR FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 44-1/2" (5,1 x 10,2 x 113 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) BEGIN HINT: Orient parts on edge on floor. Measure and mark.
  • Page 28 10' GABLE WALL DOOR FRAME PARTS REQUIRED: 3" (7,6 cm) Header Assembly 2 x 4 x 8" 2 x 4 x 59" (5,1 x 10,2 x 149,9 cm) (5,1 x 10,2 x 20,3 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) Orient parts on edge on floor. Measure and mark.
  • Page 29 10' GABLE WALL DOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 11-7/8 x 84" BLOCK (1 x 30,2 x 213,4 cm) Install all panels with the primed side facing up. BEGIN Place 11-7/8 x 84" panel on wall frame flush to top of frame as shown. Use the gauge block to mark the 3/4" measurement on the wall stud. Secure panel with 2"...
  • Page 30 10' GABLE WALL DOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 48" x 84" 3/8 x 48" x 84" BLOCK (1 x 121,9 x 213,4 cm) (1 x 121,9 x 213,4 cm) Place left and right 48" x 84" panels on wall frame flush to top of frame. Ensure the left 48"...
  • Page 31 10' GABLE WALL DOOR PANELS PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) TEMPORARY SUPPORT 3/8 x 11-7/8 x 84" 69" Door Stiffener (175,3 cm) (1 x 30,2 x 213,4 cm) Place 11-7/8 x 84" panel on wall frame flush to top of frame as shown. Secure panel with 2" nails spaced 6" apart apart along edges. Install OO as a temporary support brace to hold the 56"...
  • Page 32 12' EAVE WALL WINDOW FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 60" (5,1 x 10,3 x 152,4 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) Window Frame Assembly 2 x 4 x 84" (5,1 x 10,2 x 213,4 cm) BEGIN Orient parts on edge on floor. Measure and mark.
  • Page 33 12' EAVE WALL WINDOW FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 7-1/2" (5,1 x 10,2 x 35,6 cm) Window Frame Assembly 2 x 4 x 28" (5,1 x 10,2 x 71,1 cm) Position the (2) window frame assemblies flush to the installed window frame. Ensure that part LV is elevated above the floor (Fig. A). Center parts AMA and RR in the middle window frame assembly.
  • Page 34 12' EAVE WALL WINDOW PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK Install all panels with the primed side facing up. BEGIN Place left 48" x 84" panel on wall frame flush to top of frame. Ensure panel maintains flush along edge and flush to top of frame. Use the gauge block to ensure the 3/4" measurement on the wall stud. Secure panel with 2"...
  • Page 35 12' EAVE WALL WINDOW PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK Place right 48" x 84" panel on wall frame flush to top of frame. Ensure panel maintains flush along edge and flush to top of installed panel as shown. Use the gauge block to ensure the 3/4" measurement on the wall stud. Secure panel with 2" nails spaced 6" apart apart along edges and 12" apart inside panel. Flush Flush 6"...
  • Page 36 12' EAVE WALL WINDOW PANELS PARTS REQUIRED: 2" (5,1 cm) 3/8" x 2-1/2 x 23-1/4" (1 x 6,3 x 59,1 cm) 1-1/2" (3,8 cm) 3/8 x 23-7/8 x 84" (1 x 60,6 x 213,4 cm) Place (2) 23-7/8" x 84" panels on wall frame flush to top of frame as shown. Flush panels to edges of installed panels.
  • Page 37 12' EAVE WALL DOOR FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 60" (5,1 x 10,3 x 152,4 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) 2 x 4 x 84" (5,1 x 10,2 x 213,4 cm) BEGIN HINT: Orient parts on edge on floor. Measure and mark.
  • Page 38 12' EAVE WALL DOOR FRAME PARTS REQUIRED: 3" (7,6 cm) Header Assembly 2 x 4 x 8" 2 x 4 x 59" (5,1 x 10,2 x 149,9 cm) (5,1 x 10,2 x 20,3 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) Orient parts on edge on floor. Measure and mark.
  • Page 39 12' EAVE WALL DOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 23-7/8 x 84" BLOCK (1 x 60,6 x 213,4 cm) Install all panels with the primed side facing up. BEGIN Place 23-7/8 x 84" panel on wall frame flush to top of frame as shown. Use the gauge block to mark the 3/4" measurement on the wall stud. Secure panel with 2"...
  • Page 40 12' EAVE WALL DOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 48" x 84" 3/8 x 48" x 84" BLOCK (1 x 121,9 x 213,4 cm) (1 x 121,9 x 213,4 cm) Place left and right 48" x 84" panels on wall frame flush to top of frame. Ensure the left 48"...
  • Page 41 12' EAVE WALL DOOR PANELS PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) TEMPORARY SUPPORT 3/8 x 23-7/8 x 84" (1 x 60,6 x 213,4 cm) 69" Door Stiffener (175,3 cm) Place 23-7/8 x 84" panel on wall frame flush to top of frame as shown. Use the gauge block to mark the 3/4" measurement on the wall stud. Secure panel with 2"...
  • Page 42 10' GABLE WALL WINDOW FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 44-1/2" (5,1 x 10,2 x 113 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) Window Frame Assembly 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) BEGIN Orient parts on edge on floor, stagger placement at seams. Measure and mark.
  • Page 43 10' GABLE WALL WINDOW FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 7-1/2" (5,1 x 10,2 x 35,6 cm) Window Frame Assembly 2 x 4 x 28" (5,1 x 10,2 x 71,1 cm) Position the (2) window frame assemblies flush to the installed window frame. Ensure that part LV is elevated above the floor (Fig. A). Center parts AMA and RR in the middle window frame assembly.
  • Page 44 10' GABLE WALL WINDOW PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 48 x 84" BLOCK (1 x 121,9 x 213,4 cm) Install all panels with the primed side facing up. BEGIN Place left 48 x 84" panel on wall frame flush to top of frame. Ensure panel maintains flush along edge and flush to top of framing as shown. Use the gauge block to ensure the 3/4"...
  • Page 45 10' GABLE WALL WINDOW PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 48 x 84" BLOCK (1 x 121,9 x 213,4 cm) Place right 48 x 84" panel on wall frame flush to top of frame. Ensure panel maintains flush along edge and flush to top of installed panel as shown. Use the gauge block to ensure the 3/4" measurement on the wall stud. Secure panel with 2"...
  • Page 46 10' GABLE WALL WINDOW PANELS PARTS REQUIRED: 2" (5,1 cm) 3/8" x 2-1/2 x 23-1/4" 1-1/2" (3,8 cm) (1 x 6,3 x 59,1 cm) 3/8 x 11-7/8 x 84" (1 x 30,2 x 213,4 cm) Place (2) 11-7/8 x 84" panels on wall frame flush to top of frame. Flush panels to edges of installed panels.
  • Page 47 12' EAVE WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) HINT: BEGIN For easier nailing...
  • Page 48 12' EAVE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 84" BLOCK (121,9 x 213,4 cm) Install all panels with the primed side facing up. Ensure your wall frame is square by installing one panel and squaring frame. BEGIN Place 48 x 84" panel on wall frame flush to top of frame as shown.
  • Page 49 12' EAVE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm) Place center 48" x 84" panel on frame. Flush Flush Flush panel to top of top plate and to installed panel. Secure with 2" nails spaced 6" apart 12"...
  • Page 50 GABLE END WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 80" (5 x 10,2 x 203,2 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) 2 x 4 x 44-1/2" (5,1 x 10,2 x 113 cm) BEGIN HINT: Orient parts on edge on floor. Measure and mark.
  • Page 51 GABLE END WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 84" BLOCK (122 x 213,4 cm) Install all panels with the primed side facing up. Place 48" x 84" panel on frame, flush at top and with a 3/4" gap on right side. Maintain 3/4" measurement along edge. Secure panel to frame with 2" nails spaced 6" apart along edges and 12" inside panel.. BEGIN HERE For squareness maintain fush and Flush...
  • Page 52 GABLE END WALL PARTS REQUIRED: 2" (5,1 cm) 23-7/8 x 84" 48 x 84" (60,6 x 213,4 cm) (122 x 213,4 cm) Install 23-7/8" x 84" and 48" x 84" flush with installed panels as shown. Ensure panels are flush at top. Secure with 2" nails spaced 6" apart on edges and 12" inside panel. For squareness maintain fush along panel edges.
  • Page 53 12' EAVE WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) TEMPORARY SUPPORT 69” (175,3) Door Stiffener 3" (7,6 cm) 2" (5,1 cm) BEGIN Center eave wall assembly on the floor. Use OO as a temporary brace. Secure with (2) 3" screws. 1" panel overlap to foor 3" (7,6 cm) Screws Nail lower edge of panel to floor frame with 2" nails spaced 6" apart.
  • Page 54 10' GABLE END WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 1-1/2" (3,8 cm) 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 2" (3,8 cm) Flush Screw Flush BEGIN Set gable end wall on floor and secure top of wall Fig. A with (1) 2" screw into eave wall top plate (Fig A). 2"...
  • Page 55 12' WINDOW WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) TEMPORARY SUPPORT 2 x 4 x 94-1/2" (5,1 x 10,2 x 240 cm) 1-1/2" (3,8 cm) 2" (5,1 cm) BEGIN Center eave wall assembly on the floor. Flush panels at Use UN as a temporary brace. outside Secure with (2) 3"...
  • Page 56 12' WINDOW WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Nail lower edge of panels to floor frame with 2" nails spaced 6" apart. Angle nails into floor frame (Fig. D). Secure eave wall bottom plates to floor with 3" nails (Fig. D). 6" (15,2 cm) 2" (5,1 cm) Nails Nail 2" nails first. 3" (7,6 cm) Nails 3" (7,6 cm) 2" (5,1 cm) Nails Nails Fig.
  • Page 57 10' DOOR WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) If your door is on the eave wall, install the gable wall with the windows. BEGIN Place 10' gable wall on floor. Secure top of wall to eave wall top plates with (1) 2" screw at each side (Fig A). OPTIONAL GABLE WALL ENSURE TOP WALL FRAMES ARE FLUSH.
  • Page 58 GABLE END WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) Nail lower edge of panels to floor with 2" nails spaced 6" apart. Angle nails into the floor frame (Fig. C). 2" (5,1 cm) Nails 6" (15,2 cm) Angle nail to hit foor Fig. C frame. 6" (15,2 cm) 3" (7,6 cm) Screw Fig.
  • Page 59 Please continue to the included booklet PART 2 to complete your shed.
