Related Manuals for Backyard Products GAMBREL 10' x 12'

Summary of Contents for Backyard Products GAMBREL 10' x 12'

  • Page 1 16922 STOP DO NOT RETURN TO THE STORE! If you discover missing or damaged parts, or if you have questions about the building process, please reach out to us directly for the fastest service. 24/7 Support Business Hours help.backyardproducts.com (734) 242-6900 Answers to frequently Monday - Friday ...

  • Page 2: How To Enter

    $500 gift card. Write a Backyard Products, LLC. product review at backyardreviews.net for a chance to win a $500 Visa gift card. No purchase necessary to enter. Must be legal U.S. resident (including DC & Puerto Rico), 18 or older to participate. Taxes on prize are responsibility of winner. Odds of winning depend on the number...

  • Page 3: Assembly Manual

    03/01/2024 16922 Backyard Products, LLC ASSEMBLY MANUAL 1000 Ternes Drive Monroe, MI 48162 GAMBREL 10' x 12' (304,8 x 365,8 cm) ACTUAL FLOOR SIZE: 120" x 144" (304,8 x 365,8 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE Eave Door with Optional Windows (Instruction for window installation located in window kit.)
  • Page 4 TOOLS Required Optional Phillips Tool Belt/ Utility Knife Screwdriver Nail Pouch Shingle Blades Drill / Driver Caulk Gun 1/8" Drill Bit Tin Snips 1/4" Drill Bit (for drip edge) 5/16" Drill Bit Paint Tools 1/2" Drill Bit #2 Philips Drive Bit Chalk Line Safety Glasses Hammer...

  • Page 5: Optional Materials

    ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • If your purchase comes with a floor system, the materials to construct your floor will be in a separate kit(s). • See the FLOOR LEVELING section on page 15 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site.

  • Page 6: Parts List

    PARTS IDENTIFICATION AND SIZES WOOD SIZE CONVERSION CHART Part identification letters are stamped on some parts. Treated lumber is stamped: Nominal Board Size Actual Size 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3 ....1-1/2"...
  • Page 7 FLOOR (IF DIY FLOOR KIT(S) PURCHASED) 2 x 4 x 48" (5 x 10 x 122 cm) TREATED TREATED 2 x 4 x 45" (5 x 10 x 114,3 cm) 2 x 4 x 72" (5 x 10 x 183 cm) TREATED 2 x 4 x 93"...
  • Page 8 FASTENER/HARDWARE BAG 1-1/2" (3,8 cm) x110 2" (5,1 cm) x200 3" (7,6 cm) NOTE: 2" (5,0 cm) If you are using a nail gun, nails 3/4" (1,9 cm) may be used where screws are x105 shown for quicker assembly. Length of nail must match screw length. NAIL BOXES (Shown Actual Size) BOXES 3"...
  • Page 9 COMPONENT SECTION INDEX Description Section Page Floor 9-17 Walls 20-42 Rafters 43-44 Gable Units 45-47 Roof Panels Fascia Trim Doors Corner Trim Collar Ties Windows Shingles...

  • Page 10: Actual Size

    CONCRETE FOUNDATION If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4" (10,2 cm) Building Size Actual Size 10' x 12' (304,8 x 365,8 cm) 120"...
  • Page 11 BUILD YOUR OWN WOOD FLOOR OPTION (Materials not included.) 144" 117" (365,8 cm) (297,2 cm) 120" (304,8 cm) 16" (40,6 cm) 16" (40,6 cm) MATERIAL REQUIRED 2 x 4 x 12' (5,1 x 10,2 x 365,8 cm) MUST be treated lumber 2 x 4 x 10' (5,1 x 10,2 x 304,8 cm) MUST be treated lumber 4 x 4 x 12' (10,2 x 10,2 x 365,8 cm)
  • Page 12 BUILD YOUR OWN WOOD FLOOR OPTION LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 15 for the preferred fl oor leveling method.

  • Page 13: Parts Required

    FLOOR FRAME (if diy floor kit(s) purchased) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 45" (5 x 10 x 114,3 cm) TREATED NOTE: Look for Stamp. 2 x 4 x 48" (5 x 10 x 122 cm) TREATED 2 x 4 x 72"...
  • Page 14 FLOOR FRAME (IF DIY FLOOR KIT(S) PURCHASED) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5 x 10 x 122 cm) TREATED NOTE: Look for Stamp. 2 x 4 x 72" (5 x 10 x 183 cm) TREATED 2 x 4 x 93"...
  • Page 15 FLOOR FRAME (IF DIY FLOOR KIT(S) PURCHASED) PARTS REQUIRED: 3" (7,6 cm) Fasten fl oor sections together, as shown. Secure with 3" nails. Flush Flush Stagger nail 144" (365,8 cm) pattern. 120" (305 cm) FINISH Your fl oor frame is now assembled. Proceed to level and square frame.
  • Page 16 LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 15 for the preferred fl oor leveling method. Use a level to ensure that the fl oor frame is level before installing fl oor panels.
  • Page 17 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS • 3" Screw angled into 4x4. • (2) at each point frame Measurements to centers of 4x4's.
  • Page 18 FLOOR PANELS (IF DIY FLOOR KIT(S) PURCHASED) PARTS REQUIRED: 2" (5,1 cm) 5/8 x 48 x 96" 3/4" GAUGE (1,6 x 121,9 x 243,8 cm) BLOCK Install floor panels with the rough side facing up (painted grid lines). BEGIN Install (1) 48" x 96" panel on the96" x 120" floor frame section, edge flush to the seam between the floor frames and 3/4"...
  • Page 19 FLOOR PANELS (IF DIY FLOOR KIT(S) PURCHASED) PARTS REQUIRED: x257 3/4" GAUGE 2" (5,1 cm) BLOCK 5/8 x 23-7/8 x 96" 5/8 x 23-7/8 x 48" 5/8 x 48 x 96" (1,6 x 60,6 x 243,8 cm) (1,6 x 60,6 x 121,9 cm) (1,6 x 121,9 x 243,8 cm) Continue installing the remaining panels in the following order: 1.
  • Page 20 IMPORTANT! Ensure that the floor frame is level after installing floor panels. Re-level if necessary. • The floor should used as a stable work surface for wall construction. • Organize your assembly procedure during the build process to avoid over-handling of the walls. HINT: GABLE WALL EAVE WALL...

  • Page 21: Window Installation

    WINDOW INSTALLATION If you purchased a shed with one or more windows, please see instructions located in the window kit for installation. You will install windows after your shed is assembled.
  • Page 22 WALL INDEX Create your own style of shed. Choose your door location. Use this guide to find the corresponding wall construction and installation pages. IMPORTANT! Build your door header before building any walls (see next page). After assembling the walls for your 10' x 12' shed, go to page 38 for wall installation.
  • Page 23 DOOR FRAME UNIT Assemble the door frame unit before building any walls! Any wall with a door will require this assembly. PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 67" (5,1 x 10,2 x 170,2 cm) 7/16 x 3-1/4 x 66-3/4" (1,1 x 8,3 x 170,2 cm) Pre-assemble the door header.
  • Page 24 WALL PANEL INSTALLATION HINTS & EXAMPLES PARTS REQUIRED: 2" (5,1 cm) TEMP. SPACER 3/4" GAUGE BLOCK 3/8 x 48 x 84" (1 x 121,9 x 213,4 cm ) Ensure your wall is square by installing one panel and squaring frame. Install all wall panels with the primed side facing up.
  • Page 25 DOOR FRAME UNIT PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 7" (5,1 x 10,2 x 17,8 cm) 3" (7,6 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) Assembled Header 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) Arrange parts on edge on fl oor, as shown.
  • Page 26 10' WALL A PARTS REQUIRED: 3" (7,6 cm) x2 QS 2 x 4 x 32-1/2" (5,1 x 10,2 x 82,5 cm) 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) Assembled Door Frame Unit 2 x 4 x 80-1/2" (5,1 x 10,2 x 204,5 cm) BEGIN Arrange parts on edge on floor, as shown.
  • Page 27 10' WALL A PARTS REQUIRED: 3" (7,6 cm) x158 2" (5,1 cm) 11-7/8" x 84" (30,2 x 213,4 cm) Temporary Brace 69" (75,3 cm) Door Stiffener Install the left panel 1-1/2" 1-1/2" Flush from the top plate. (3,8 cm) 3/4" BEGIN HERE Use a 2x4 spacer for (1,9 cm)
  • Page 28 10' WALL B PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 20-1/2" (5,1 x 10,2 x 52,1 cm) 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) 2 x 4 x 92-1/2" (5,1 x 10,2 x 235 cm) BEGIN Arrange parts on edge on floor.
  • Page 29 10' WALL B PARTS REQUIRED: x136 2" (5,1 cm) 48 x 84" 23-7/8" x 84" (121,9 x 213,4 cm ) (60,6 x 213,4 cm ) 1-1/2" (3,8 cm) 3/4" BEGIN HERE Install 48" x 84" panel 1-1/2" (1,9 cm) from the top plate. Use a 2x4 spacer for consistent measurement.
  • Page 30 12' WALL C PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) 2 x 4 x 96"...
  • Page 31 12' WALL C PARTS REQUIRED: x172 2" (5,1 cm) 48 x 84" 23-7/8" x 84" (121,9 x 213,4 cm ) (60,6 x 213,4 cm ) 3/4" Install the fi rst 48" x 84" BEGIN HERE (1,9 cm) panel 1-1/2" from the 1-1/2"...
  • Page 32 12' WALL D PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) 2 x 4 x 96"...
  • Page 33 12' WALL D PARTS REQUIRED: x150 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm ) 3/4" BEGIN HERE Install 48" x 84" panel (1,9 cm) 1-1/2" from the top plate. 1-1/2" (3,8 cm) Use a 2x4 spacer for consistent measurement.
  • Page 34 10' WALL E PARTS REQUIRED: 3" (7,6 cm) x2 QS 2 x 4 x 32-1/2" (5,1 x 10,2 x 82,5 cm) 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) 2 x 4 x 80-1/2" (5,1 x 10,2 x 204,5 cm) BEGIN Arrange parts on edge on floor.
  • Page 35 10' WALL E PARTS REQUIRED: x164 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm ) 11-7/8" x 84" (30,2 x 213,4 cm) 3/4" BEGIN HERE Install 48" x 84" panel 1-1/2" (1,9 cm) (3,8 cm) 1-1/2" from the top plate. Use a 2x4 spacer for consistent measurement.
  • Page 36 12' WALL F PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) Assembled 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) Door Frame Unit 2 x 4 x 96"...
  • Page 37 12' WALL F PARTS REQUIRED: x166 2" (5,1 cm) 3" (7,6 cm) 23-7/8" x 84" Temporary Brace (60,6 x 213,4 cm ) 69" (75,3 cm) Door Stiffener 1-1/2" Flush (3,8 cm) 3/4" BEGIN HERE Install the left panel 1-1/2" (1,9 cm) from the top plate.
  • Page 38 12' WALL G PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) Assembled 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) Door Frame Unit 2 x 4 x 96"...
  • Page 39 12' WALL G PARTS REQUIRED: x150 2" (5,1 cm) 3" (7,6 cm) Temporary Brace 69" (75,3 cm) Door Stiffener 48 x 84" (121,9 x 213,4 cm ) 1-1/2" Flush (3,8 cm) 3/4" BEGIN HERE Install the left panel 1-1/2" (1,9 cm) from the top plate.
  • Page 40 12' WALL D, F or G INSTALLATION PARTS REQUIRED: 3" (7,6 cm) Temporary Brace 2 x 4 x 92-1/2" (5,1 x 10,2 x 235 cm) 3" (7,6 cm) 2" (5,1 cm) 1-1/2" BEGIN (3,8 cm) Center 10' wall on the 120" 3"...
  • Page 41 10' WALL B or E INSTALLATION PARTS REQUIRED 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) 3" (7,6 cm) Fig. B BEGIN Install 10' wall centered on fl oor. 1-1/2" (3,8 cm) overlap is to the top. 2"...
  • Page 42 (2nd) 12' WALL D or C INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) 1-1/2" BEGIN Fig. B Install the 12' wall centered on fl oor. (3,8 cm) 1-1/2" (3,8 cm) overlap is to the top. Secure wall with (1) 2"...
  • Page 43 10' WALL A or B INSTALLATION PARTS REQUIRED 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) 3" (7,6 cm) Fig. B BEGIN Place 10' wall on fl oor centered between 12' walls. 2" (5,1 cm) Screw Secure wall with 2"...
  • Page 44 WALL DOUBLERS INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 44-1/2" (5,1 x 10,2 x 113 cm) 2 x 4 x 92-1/2" (5,1 x 10,2 x 235 cm) 2 x 4 x 96"...
  • Page 45 RAFTERS PARTS REQUIRED: 3" (7,6 cm) 6 x 24" (15,2 x 60,9 cm) x144 2" (5,1 cm) Pre-assembled HINT: Use fl oor and walls to help Temporary Support 2 x 4 x 39" (5,1 x 10,2 x 99,1 cm) assemble rafters! Build (2) rafter assemblies with (1) gusset (Fig.
  • Page 46 RAFTER INSTALLATION PARTS REQUIRED: 3" (7,6 cm) Two-Gusset Assembled One-Gusset Assembled BEGIN Align rafters over the wall studs. Check that you have the measurements shown. Secure rafters with (2) 3" screws angled at each end (Fig. A, Fig. B). Secure gable end rafters with (1) 3" screw through top of rafter into doubler (Fig. C). Secure rafters on opposite side.
  • Page 47 GABLE HAY LOFT TRIM PARTS REQUIRED: 2" (5,1 cm) 3/4" (1,9 cm) 19/32" x 2-1/2" x 12-7/8" (1,6 x 7,6 x 32,7 cm) 19/32" x 3-1/2" X 21-3/4" (1,6 x 8,9 x 55,2 cm) 19/32" x 3-1/2" X 23-3/4" (1,6 x 8,9 x 60,3 cm) x1 LKA 19/32"...
  • Page 48 GABLE PANELS PARTS REQUIRED: 1-1/2" (3,8cm) x4 QL 2 x 4 x 39" (5,1 x 10,2 x 99,1 cm) Install gable panels with the primed side facing up. BEGIN BEGIN Orient parts QL on the fl at side, as shown. Measure and mark the center of the middle gable panel.
  • Page 49 GABLE INSTALLATION PARTS REQUIRED: 3" (7,6 cm) x114 2" (5,1 cm) Assembled BEGIN Measure 1-1/2" (3,8 cm) down from top plate doubler and mark at each side as shown. Set gable unit on top plate. Fasten with (1) 2" nail on each side. BE SURE GABLE IS CENTERED ON WALL BEFORE NAILING.
  • Page 50 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48 x 96" (121,9 x 243,8 cm) Roof panels may cause serious injury until securely fastened. Note: Install all roof panels with the rough side up (painted grid lines). BEGIN Place the 48"...
  • Page 51 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 47-7/8 x 48" (121,6 x 121,9 cm) Install a 48" x 47-7/8" roof panel flush to the Flush at installed panel and flush at peak (Fig. B). peak Fig. B Secure panel with (1) 2" nail in each corner. 2"...
  • Page 52 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 23-7/8" x 47-7/8" 11-7/8" x 96" (30,2 x 243,8 cm) (60,6 x 121,9 cm) 3/4" GAUGE BLOCK 23-7/8" x 96" 11-7/8" x 47-7/8" (60,6 x 243,8 cm) (59,7 x 121,9 cm) Next, install 23-7/8" x 48" and 23-7/8" x 96" roof panels with a 3/4" measurement on the rafter (Fig A) and flush to the installed panels (Fig.
  • Page 53 ROOF PANELS PARTS REQUIRED: x178 2" (5,1 cm) Secure all roof panels with 2" nails spaced 6" apart on edges and 12" apart inside panels. 6" (15,2 cm) Repeat all steps to install roof panels on the opposite side. FINISH Your roof panels are now installed.
  • Page 54 GABLE FASCIA PARTS REQUIRED: 2" (5,1 cm) 5/8 x 4 x 48-5/16 5/8 x 4 x 36" (1,6 x 10 x 123 cm) (1,6 x 10 x 91 cm) 5/8 x 4 x 48-5/16 5/8 x 4 x 36" (1,6 x 10 x 123 cm) (1,6 x 10 x 91 cm) BEGIN Install upper gable trim ZQR and ZQL fl ush to top of roof panels and fl ush at peak.
  • Page 55 DOORS PARTS REQUIRED: 1" (2,5 cm) #14 Screws LEFT Square Drive Bit RIGHT 5/4 x 3-1/2 x 72-3/8" (3,2 x 8,9 x 183,8 cm) ¸ BEGIN Arrange parts as shown on a flat surface. Align (6) hinges with pre-drilled holes in DJD and doors.
  • Page 56 DOORS PARTS REQUIRED: 3" (7,6 cm) 1" (2,5 cm) #14 Screws 3/16" (5 mm) Drill Bit Temporary Support Square Drive Bit Door Stiffener 69" (175,3 cm) Using holes in hinge as a guide, predrill (3) 3/16" holes 3/4" deep into door. Predrill (2) 3/16"...
  • Page 57 DOORS PARTS REQUIRED: 3" (7,6 cm) Temporary Support 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) 3" (7,6 cm) #14 Screws Temporary Spacer 3/8 x 3-1/2 x 83-1/4" (1 x 8,9 x 211,5 cm) (Not shown to scale) Install TP as a temporary support ledger board 3/8"...
  • Page 58 DOOR TRIM PARTS REQUIRED: 3/4" (1,9 cm) x11 2" (5,1 cm) Bagged seperately / special coating 5/4 x 3-1/2 x 24-5/8" (3,2 x 8,9 x 62,5 cm) 64" Metal Threshold 3/4" (1,9 cm) 5/4 x 3-1/2 x 74" (3,2 x 8,9 x 188 cm) BEGIN Secure door trim from inside using 3/4"...
  • Page 59 DOOR TRANSOM WINDOWS PARTS REQUIRED: 3/4" (1,9 cm) Transom Window ¸ BEGIN Apply high quality exterior-grade caulk behind frame near edge before installing to seal window. You must caulk completely around window frame and all exposed door panel edges and trim to validate your warranty.
  • Page 60 DOOR STIFFENERS PARTS REQUIRED: 2" (5,1 cm) 69" Door Stiffener (175,3 cm) BEGIN Center OO vertically on the left door in the door opening fl ush with the edge of door (Fig. A). Secure with (7) 2" screws through outside trim into OO (Fig. B) OO x2 Repeat steps to install OO on right door.

  • Page 61: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: Hex Wrench, Square Drive Bit 3/32" (3 mm) Drill Bit 3/4" (19 mm) Phillips Head Screw #8 x 2" (5,1 cm) Square Drive Screw Pre-assemble, test-fi t parts and mark (2) pilot hole locations, as shown. Remove parts and pre-drill (2) 3/32"...
  • Page 62 DOOR WEATHERSTRIPPING PARTS REQUIRED: 2" (5,1 cm) 1 x 4 x 69-1/4" (2,5 x 10,2 x 175,9 cm) BEGIN Install (2) NUC weatherstrips fl ush along inside of doors and fl ush to door header. Secure with 2” fi nishing nails, as shown (Fig. A). Fig.
  • Page 63 DOUBLE DOOR HARDWARE PARTS REQUIRED: 5/16" BIT (8 mm) 3/4" (1,9 cm) BEGIN Place upper bolt on OO in open position with bolt end 3/8" (9,5 mm) down from frame. Bolt is open when loop is contacting base (Fig A). Mark and pre-drill holes for screws.
  • Page 64 CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8" x 3-1/2" x 83-1/4" (1 x 8,9 x 211,5 cm) BEGIN Install gable end 83-1/4" corner trim under gable panel, (Fig. A) and fl ush to eave wall panel (Fig. B). Secure with 2"...
  • Page 65 COLLAR TIE INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 96" (2,5 x 7,6 x 243,8 cm) BEGIN Install (2) collar ties TP to the rafters with (3) 3" nails at each end (Fig. A). Install collar ties on the 2nd and 4th rafters from the door wall, as shown. Ensure collar ties are level.
  • Page 66 HOOKS & EYES PARTS REQUIRED: ¸ BEGIN Install hooks in wall and into wall framing (Fig.A). Swing door open to locate eye. Fig. A Hook Install hook into framing, if possible. FINISH You have installed your hooks & eyes.
  • Page 67 VENT (Not included in kit.) • Follow directions provided by manufacturer and these instructions. 1/2" (13 mm) 16" x 8" BEGIN Locate and mark for two vents in side walls as shown; (1) at top and (1) at bottom. Cut out marked openings. Caulk behind vent fl anges.
  • Page 68 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 69 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 70 SHINGLES continued... Install second row of shingles flush at top of first row's rain slots. Ensure 1" overhang or flush to drip edge at front, stagger each row. FRONT OF BACK OF SHED SHED Bend in roof 1" (2,5 cm) Notch Flush with rain slots.
  • Page 71 SHINGLES continued... After shingles are installed over bend, nail down overlap using two roofi ng nails per tab. (2) Nails per tab. Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below.
  • Page 72 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Hint: Use cut-off pieces first. Cut shingles into THREE pieces. 2" 2" (5 cm) (5 cm 2" 2" 2"...
  • Page 73 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10 cm) Trim cap off fl ush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Cut at top of rain slot.
  • Page 74 16922 10' x12' Order Form CATEGORY PART DESCRIPTION PART SIZE PART ITEM # BUILDING QTY. PART ID Side Wall Top Plate *LUM SPF 2X4X72 #2&BTR O 72000000000 Side Wall Btm "A" / Dblr "A" / Collar Tie LUM SPF 2X4X96 #2&BTR 12306 Back Wall T &...
  • Page 75 LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years. All Oriented Strand Board (OSB) is warranted for 2 years Siding and Trim is warranted for 10 years.

This manual is also suitable for:

16922

Table of Contents
