ADTEK CPM-20 Series Operation Manual page 42

Register
Address
Name Format
IB Total
0880h
Odd HD
IB Total
0881h
Even HD
IB 2nd
Individual 0882h
Harmonic
IB 3rd
individual 0883h
harmonic
IB 4th
Individual 0884h
Harmonic
IB 5th
Individual 0885h
Harmonic
IB 6th
Individual 0888h
Harmonic
IB 7th
Individual 0887h
Harmonic
IB 8th
Individual 0888h
Harmonic
IB 9th
Individual 0889h
Harmonic
IB 10th
Individual 088Ah
Harmonic
IB 11th
Individual 088Bh
Harmonic
IB 12th
Individual 088Ch
Harmonic
IB 13th
Individual 088Dh
Harmonic
IB 14th
Individual 088Eh
Harmonic
IB 15th
Individual 088Fh
Harmonic
Data
Size Range
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
Unit R/W Default
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
41
Description
IB total odd HD
IB total evne HD
IB 2nd Individual Harmonic
IB 3rd Individual Harmonic
IB 4th Individual Harmonic
IB 5th Individual Harmonic
IB 6th Individual Harmonic
IB 7th Individual Harmonic
IB 8th Individual Harmonic
IB 9th Individual Harmonic
IB 10th Individual Harmonic
IB 11th Individual Harmonic
IB 12th Individual Harmonic
IB 13th Individual Harmonic
IB 14th Individual Harmonic
IB 15th Individual Harmonic
