ADTEK CPM-20 Series Operation Manual page 38

Individual Harmonic
Register
Address
Name Format
UA Total
0800h
Odd HD
UA Total
0801h
Even HD
UA 2nd
Individual 0802h
Harmonic
UA 3rd
individual 0803h
harmonic
UA 4th
Individual 0804h
Harmonic
UA 5th
Individual 0805h
Harmonic
UA 6th
Individual 0806h
Harmonic
UA 7th
Individual 0807h
Harmonic
UA 8th
Individual 0808h
Harmonic
UA 9th
Individual 0809h
Harmonic
UA 10th
Individual 080Ah
Harmonic
UA 11th
Individual 080Bh
Harmonic
UA 12th
Individual 080Ch
Harmonic
UA 13th
Individual 080Dh
Harmonic
UA 14th
Individual 080Eh
Harmonic
UA 15th
Individual 080Fh
Harmonic
Data
Size Range
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
Unit R/W Default
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
37
Description
VA or UAB total odd HD
VA or UAB total evne HD
VA or UAB 2nd Individual Harmonic
VA or UAB 3rd Individual Harmonic
VA or UAB 4th Individual Harmonic
VA or UAB 5th Individual Harmonic
VA or UAB 6th Individual Harmonic
VA or UAB 7th Individual Harmonic
VA or UAB 8th Individual Harmonic
VA or UAB 9th Individual Harmonic
VA or UAB 10th Individual Harmonic
VA or UAB 11th Individual Harmonic
VA or UAB 12th Individual Harmonic
VA or UAB 13th Individual Harmonic
VA or UAB 14th Individual Harmonic
VA or UAB 15th Individual Harmonic
