ADTEK CPM-20 Series Operation Manual page 40

Register
Address
Name Format
UC Total
0840h
Odd HD
UC Total
0841h
Even HD
UC 2nd
Individual 0842h
Harmonic
UC 3rd
individual 0843h
harmonic
UC 4th
Individual 0844h
Harmonic
UC 5th
Individual 0845h
Harmonic
UC 6th
Individual 0846h
Harmonic
UC 7th
Individual 0847h
Harmonic
UC 8th
Individual 0848h
Harmonic
UC 9th
Individual 0849h
Harmonic
UC 10th
Individual 084Ah
Harmonic
UC 11th
Individual 084Bh
Harmonic
UC 12th
Individual 084Ch
Harmonic
UC 13th
Individual 084Dh
Harmonic
UC 14th
Individual 084Eh
Harmonic
UC 15th
Individual 084Fh
Harmonic
Data
Size Range
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
XXX.X 1 0~300.0
Unit R/W Default
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
% R
39
Description
VC or UCA total odd HD
VC or UCA total evne HD
VC or UCA 2nd Individual Harmonic
VC or UCA 3rd Individual Harmonic
VC or UCA 4th Individual Harmonic
VC or UCA 5th Individual Harmonic
VC or UCA 6th Individual Harmonic
VC or UCA 7th Individual Harmonic
VC or UCA 8th Individual Harmonic
VC or UCA 9th Individual Harmonic
VC or UCA 10th Individual Harmonic
VC or UCA 11th Individual Harmonic
VC or UCA 12th Individual Harmonic
VC or UCA 13th Individual Harmonic
VC or UCA 14th Individual Harmonic
VC or UCA 15th Individual Harmonic
