WebRelay-10 Plus™ Users Manual
2.1 Mounting
WebRelay-10 Plus™ can be mounted to a standard (35mm by 7.55mm) DIN-Rail. Attach the module to the DIN-
Rail by placing the top hooks on the back of WebRelay-10 Plus™ to the DIN-Rail and then snapping the bottom
hooks into place. Remove from the DIN-Rail by depressing the latch-release on the mounting bracket.
See Appendix L: Mechanical Information for additional mechanical details.
Figure 2.1a - DIN-Rail Mount
Xytronix Research & Design, Inc.
Page 9
