Option 2: Assign A Temporary Ip Address To Configuration Computer - ControlByWeb WEBRelay-10+ User Manual

Type:
arp -s {new IP address} {serial number of the WebRelay-10 Plus™ }
Note: IP address format is xxx.xxx.xxx.xxx
Serial number format is ss:ss:ss:ss:ss:ss
For example, to set the WebRelay-10 Plus™ (with serial number 00-0C-C8-01-00-01 ) to 10.10.10.40
the following command would be used:
arp -s 10.10.10.40 00:0c:c8:01:00:01
Next, type:
ping -s 102 {new IP address}
For example, if the new IP address is 10.10.10.40, the following command would be used:
ping -s 102 10.10.10.40
Mac OS X:
Open a terminal.
Note: The terminal is in the "Utilities" directory, which is in the "Applications" directory.
Type:
sudo arp -s {new IP address} {serial number of the WebRelay-10 Plus™ }
Note: Administrator password is required.
IP address format is xxx.xxx.xxx.xxx
Serial number format is ss:ss:ss:ss:ss:ss
For example, to set a the WebRelay-10 Plus™ (with serial number 00-0C-C8-01-00-01 ) to
10.10.10.40 the following command would be used:
sudo arp -s 10.10.10.40 00:0c:c8:01:00:01
Next, type:
ping -s 102 {new IP address}
For example, if the new IP address is 10.10.10.40, the following command would be used:
ping -s 102 10.10.10.40

2.3.2 Option 2: Assign a temporary IP address to configuration computer

If the first option above is not used, you can use this option to communicate with the WebRelay-10 Plus™. By
default, the WebRelay-10 Plus™ comes from the factory with an IP address of 192.168.1.2. Communications
with the WebRelay-10 Plus™ may be established by assigning an IP address to the configuration computer
that is on the same network as the WebRelay-10 Plus™ (for example, the configuration computer could be
assigned to 192.168.1.50)
The following example is for those running the Windows operating system:
