UFM-H2O Series
Ultrasonic Flow Meter

Menu Instruction

There are 4 main menu options for the water meter
In then menu M-0, press the modifying key
will display sub menu M-02. Press
M-0 : Measured value display and working status, referred to as DISP
M00 Display instantaneous flow and positive cumulative flow
M01 Display instantaneous heat and positive / negative cumulative heat (heat meter)
M02 Display water pressure and water temperature (multi-function water meter)
M03 Display supply water temperature TI and return water temperature T2 (heat meter)
M04 Displays battery voltage and total signal strength and signal quality
M05 Displays total propagation time (microseconds) and propagation time difference (nanoseconds)
M06 Display date time week
M07 Auto Verification Window
M08 Manual Verification Window
M09 Display software version number and instrument serial number
M0A Show Full Screen
M-1 : Pipeline parameters and historical query, referred to as CHEC
M10 Enter the password to enter the submenu
M11 Display the number of sound channels, inner diameter and distance between probes
M12 Display sample time, damping coefficient, angle coefficient
M13 Show negative accumulation
M14 Query the daily net cumulative amount
M15 Query the monthly net cumulative amount
M17 Display total working time and failure working time
M18 Display production date (calibration writing), calibration job number (increase calibration level)
M-2 : Communication settings, referred to as COM
M21 Set date time week
M23 Set RS485 communication protocol
M24 Set RS485 , communication address
M25 RS485/MBUS communication baud rate verification
M26 Communication data display for debugging
M-3 : Flow Rate Setting and Modification, for short CORR
M32 Display current zero value, low flow excision value
M33 Set instrument coefficient
M34 Set low flow excision value
M35 Reset accumulator (modify cumulant)
M36 Display instantaneous flow rate and static state zero setting
M39 Set the scale of the meter's positive/negative cumulative flow retention
M3B Manually set the traffic type for the default display window M00
(Battery Operated)
will enter in the sub menu M-01, Press
will return to the main menu M-0.
