• 9600 kbit/s

• 19200 kbit/s

• 38400 kbit/s

• 57600 kbit/s

• 115200 kbit/s (default)

If you are using a VBOX NTRIP Modem, this setting should be 115200 kbit/s. If you are using a Telemetry Radio

Module with a

Static Base

or 38400 kbit/s for a Satel grey boxed radio. Tap the button to change the setting.

The setting option will be retained after power cycles, coldstarts and firmware upgrades.

The RTK correction status of the unit can be seen within the GPS Status area of the Diagnostics Settings Menu and

is indicated by the colour of the

Diagnostics

The Diagnostics menu is the final screen within the Settings menu, it displays basic GNSSS receiver and VBOX

information.

Station, this setting should be either 115200 kbit/s for a Racelogic blue boxed radio

Satellite

icon.

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_RTK/

User_Guide_%E2%80%93_VBOX_Touch_RTK/06_Settings_VBOX_Touch_RTK
