10 System Debug

Debug steps
Preparation
System Function
Monitor Function
Operation Trial
It is forbidden to turn on loads before turn on HV48100.
Remarks: Follow instruction manuals of other equipment for turn on
process other than HV48100.
Function Debug:
Communication: Check communication between HV48100 and
devices, if it's normal or alarm.
Power Conversion System: Before conjoint, it is a must that PCS
or Inverter System runs normally and parameters meet HV48100
requirement.
System Operation: Charge/Discharge, charging stop, discharging
stop, current limiting, etc.
Caution: Set up all parameters of PCS and EMS before turn on
HV48100.
Connect to console terminal of main control to check whether data of
HV48100 normally displays on the monitor system.
After the system debugged, run the system a period with low load for
trial operation, to test the high voltage DC system fits to requirement.
