6 System Start Up

DANGER
Wear personal protective equipment and use dedicated insulated tools to avoid electric
shocks or short circuits.
WARNING
During Power-on procedure, power off the batteries immediately if any fault is detected. Recti-
fy the fault before proceeding with the procedure.
After batteries are used for system commissioning or batteries have discharged, charge the
batteries in time. Otherwise, batteries may be damaged due to overdischarge.
Battery overdischarge and damage may occur if batteries with low SOC are stored. Batteries
should be recharged in a timely manner.
NOTICE
Before the equipment is put into operation for the first time, ensure that the parameters are set
correctly by professional personnel. Incorrect parameter settings may result in noncompliance
with local grid connection requirements and affect the normal operations of the equipment.

6.1 Verification Before Power-On

Check items and acceptance criteria:
No. Check Item
1 Battery installation
2 Cables Routing
3 Cable tie
4 Grounding
5 Switch
6 Cable connection
7 Unused terminal and port
8 Installation environment

6.2 System Power-On

Step 1 Set the right DIP according to corresponding PCS brand. DIP setting as below:
The installation is correct and reliable.
Cables are routed properly as required by the customer.
Cable ties are evenly distributed, and noburr exists.
The PE cable is connected correctly,securely, and reliably.
The DC switch and all switches connected to the battery
are OFF.
The AC output power cable, DC input power cable,
battery cable, and signal cables are connected correctly,
securely, and reliably.
Unused terminals and ports are locked by watertight caps.
The installation space is proper, and the installation
environment is clean and tidy.
25
Acceptance Criteria
